8µF

Product Code	Data Sheet	Attributes
REA99 8 5 100	Data Sheet: REA99	Application: General Purpose Capacitance (µF): 8 Tolerance: ±5% Voltage Rating - DC: 100V Voltage Rating - AC: Operating Temperature: -55 °C to +125 °C IPeak: 16 Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polyphenylene sulfide Dielectric Material: Polyphenylene Sulfide - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.907" H x 0.766" D Dimension mm: 48.4mm x 19.5mm
REA99 8 5 200	Data Sheet: REA99	Application: General Purpose Capacitance (µF): 8 Tolerance: ±5% Voltage Rating - DC: 200V Voltage Rating - AC: Operating Temperature: -55 °C to +125 °C IPeak: 24 Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polyphenylene sulfide Dielectric Material: Polyphenylene Sulfide - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 2.407" H x 1.016" D Dimension mm: 61.1mm x 25.8mm
REA99 8 5 50	Data Sheet: REA99	Application: General Purpose Capacitance (µF): 8 Tolerance: ±5% Voltage Rating - DC: 50V Voltage Rating - AC: Operating Temperature: -55 °C to +125 °C IPeak: 16 Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polyphenylene sulfide Dielectric Material: Polyphenylene Sulfide - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.344" H x 0.594" D Dimension mm: 34.1mm x 15.1mm
X300 8 10 200	Data Sheet: X300	Application: Power Supply Capacitance (µF): 8 Tolerance: ±10% Voltage Rating - DC: 200V Voltage Rating - AC: Operating Temperature: -55 °C to +85 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Self-Encased w/ PP or PE Termination: Solid Wire Dimension inches: 1.574" H x 0.967" D Dimension mm: 40.0mm x 24.6mm
X300 8 20 200	Data Sheet: X300	Application: Power Supply Capacitance (µF): 8 Tolerance: ±20% Voltage Rating - DC: 200V Voltage Rating - AC: Operating Temperature: -55 °C to +85 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Self-Encased w/ PP or PE Termination: Solid Wire Dimension inches: 1.574" H x 0.967" D Dimension mm: 40.0mm x 24.6mm
X300 8 5 200	Data Sheet: X300	Application: Power Supply Capacitance (µF): 8 Tolerance: ±5% Voltage Rating - DC: 200V Voltage Rating - AC: Operating Temperature: -55 °C to +85 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Self-Encased w/ PP or PE Termination: Solid Wire Dimension inches: 1.574" H x 0.967" D Dimension mm: 40.0mm x 24.6mm
X329(F) 8 10 250	Data Sheet: 329	Application: IGBT Snubber Capacitance (µF): 8 Tolerance: ±10% Voltage Rating - DC: 600V Voltage Rating - AC: 250V Operating Temperature: -40 °C to +85 °C ESR: 2.9 mOhms IPeak: 508 Irms (Arms): 20.7 Lifecycle @ Rated Temp & Voltage: 15,000 hrs Construction: metallized polypropylene film and foil Dielectric Material: Polypropylene – Metallized and Foil Case: Preformed Case with Epoxy Fill Termination: Slotted Tabs Dimension inches: 1.460" T x 1.863" H Dimension mm: 37.1mm x 47.3mm ESR kHz: 100kHz
X329(F) 8 5 250	Data Sheet: 329	Application: IGBT Snubber Capacitance (µF): 8 Tolerance: ±5% Voltage Rating - DC: 600V Voltage Rating - AC: 250V Operating Temperature: -40 °C to +85 °C ESR: 2.9 mOhms IPeak: 508 Irms (Arms): 20.7 Lifecycle @ Rated Temp & Voltage: 15,000 hrs Construction: metallized polypropylene film and foil Dielectric Material: Polypropylene – Metallized and Foil Case: Preformed Case with Epoxy Fill Termination: Slotted Tabs Dimension inches: 1.460" T x 1.863" H Dimension mm: 37.1mm x 47.3mm ESR kHz: 100kHz
X329(S) 8 10 250	Data Sheet: 329	Application: IGBT Snubber Capacitance (µF): 8 Tolerance: ±10% Voltage Rating - DC: 600V Voltage Rating - AC: 250V Operating Temperature: -40 °C to +85 °C ESR: 2.9 mOhms IPeak: 508 Irms (Arms): 20.7 Lifecycle @ Rated Temp & Voltage: 15,000 hrs Construction: metallized polypropylene film and foil Dielectric Material: Polypropylene – Metallized and Foil Case: Preformed Case with Epoxy Fill Termination: Slotted Tabs Dimension inches: 1.460" T x 1.863" H Dimension mm: 37.1mm x 47.3mm ESR kHz: 100kHz
X329(S) 8 5 250	Data Sheet: 329	Application: IGBT Snubber Capacitance (µF): 8 Tolerance: ±5% Voltage Rating - DC: 600V Voltage Rating - AC: 250V Operating Temperature: -40 °C to +85 °C ESR: 2.9 mOhms IPeak: 508 Irms (Arms): 20.7 Lifecycle @ Rated Temp & Voltage: 15,000 hrs Construction: metallized polypropylene film and foil Dielectric Material: Polypropylene – Metallized and Foil Case: Preformed Case with Epoxy Fill Termination: Slotted Tabs Dimension inches: 1.460" T x 1.863" H Dimension mm: 37.1mm x 47.3mm ESR kHz: 100kHz
X329(W) 8 10 250	Data Sheet: 329	Application: IGBT Snubber Capacitance (µF): 8 Tolerance: ±10% Voltage Rating - DC: 600V Voltage Rating - AC: 250V Operating Temperature: -40 °C to +85 °C ESR: 2.9 mOhms IPeak: 508 Irms (Arms): 20.7 Lifecycle @ Rated Temp & Voltage: 15,000 hrs Construction: metallized polypropylene film and foil Dielectric Material: Polypropylene – Metallized and Foil Case: Preformed Case with Epoxy Fill Termination: Slotted Tabs Dimension inches: 1.460" T x 1.863" H Dimension mm: 37.1mm x 47.3mm ESR kHz: 100kHz
X329(W) 8 5 250	Data Sheet: 329	Application: IGBT Snubber Capacitance (µF): 8 Tolerance: ±5% Voltage Rating - DC: 600V Voltage Rating - AC: 250V Operating Temperature: -40 °C to +85 °C ESR: 2.9 mOhms IPeak: 508 Irms (Arms): 20.7 Lifecycle @ Rated Temp & Voltage: 15,000 hrs Construction: metallized polypropylene film and foil Dielectric Material: Polypropylene – Metallized and Foil Case: Preformed Case with Epoxy Fill Termination: Slotted Tabs Dimension inches: 1.460" T x 1.863" H Dimension mm: 37.1mm x 47.3mm ESR kHz: 100kHz
