5µF

Product Code	Image	Data Sheet	Attributes
X362 5 5 400		Data Sheet: X362	Application: Power Supply, Pulse Current Capacitance (µF): 5 Tolerance: ±5% Voltage Rating - DC: 400V Operating Temperature: -55 °C to +105 °C IPeak: 30 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.920" T x 1.950" H x 1.090" L Dimension mm: 23.4mm x 49.5mm x 27.7mm
X363 5 1 100		Data Sheet: X363	Application: Power Supply, Pulse Current Capacitance (µF): 5 Tolerance: ±1% Voltage Rating - DC: 100V Operating Temperature: -55 °C to +105 °C IPeak: 27.5 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.344" H x 0.766" D Dimension mm: 34.1mm x 19.5mm
X363 5 1 200		Data Sheet: X363	Application: Power Supply, Pulse Current Capacitance (µF): 5 Tolerance: ±1% Voltage Rating - DC: 200V Operating Temperature: -55 °C to +105 °C IPeak: 25 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.844" H x 0.969" D Dimension mm: 46.8mm x 24.6mm
X363 5 1 400		Data Sheet: X363	Application: Power Supply, Pulse Current Capacitance (µF): 5 Tolerance: ±1% Voltage Rating - DC: 400V Operating Temperature: -55 °C to +105 °C IPeak: 25 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 2.344" H x 1.109" D Dimension mm: 59.5mm x 28.2mm
X363 5 10 100		Data Sheet: X363	Application: Power Supply, Pulse Current Capacitance (µF): 5 Tolerance: ±10% Voltage Rating - DC: 100V Operating Temperature: -55 °C to +105 °C IPeak: 27.5 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.344" H x 0.766" D Dimension mm: 34.1mm x 19.5mm
X363 5 10 200		Data Sheet: X363	Application: Power Supply, Pulse Current Capacitance (µF): 5 Tolerance: ±10% Voltage Rating - DC: 200V Operating Temperature: -55 °C to +105 °C IPeak: 25 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.844" H x 0.969" D Dimension mm: 46.8mm x 24.6mm
X363 5 10 400		Data Sheet: X363	Application: Power Supply, Pulse Current Capacitance (µF): 5 Tolerance: ±10% Voltage Rating - DC: 400V Operating Temperature: -55 °C to +105 °C IPeak: 25 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 2.344" H x 1.109" D Dimension mm: 59.5mm x 28.2mm
X363 5 2 100		Data Sheet: X363	Application: Power Supply, Pulse Current Capacitance (µF): 5 Tolerance: ±2% Voltage Rating - DC: 100V Operating Temperature: -55 °C to +105 °C IPeak: 27.5 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.344" H x 0.766" D Dimension mm: 34.1mm x 19.5mm
X363 5 2 200		Data Sheet: X363	Application: Power Supply, Pulse Current Capacitance (µF): 5 Tolerance: ±2% Voltage Rating - DC: 200V Operating Temperature: -55 °C to +105 °C IPeak: 25 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.844" H x 0.969" D Dimension mm: 46.8mm x 24.6mm
X363 5 2 400		Data Sheet: X363	Application: Power Supply, Pulse Current Capacitance (µF): 5 Tolerance: ±2% Voltage Rating - DC: 400V Operating Temperature: -55 °C to +105 °C IPeak: 25 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 2.344" H x 1.109" D Dimension mm: 59.5mm x 28.2mm
X363 5 20 100		Data Sheet: X363	Application: Power Supply, Pulse Current Capacitance (µF): 5 Tolerance: ±20% Voltage Rating - DC: 100V Operating Temperature: -55 °C to +105 °C IPeak: 27.5 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.344" H x 0.766" D Dimension mm: 34.1mm x 19.5mm
X363 5 20 200		Data Sheet: X363	Application: Power Supply, Pulse Current Capacitance (µF): 5 Tolerance: ±20% Voltage Rating - DC: 200V Operating Temperature: -55 °C to +105 °C IPeak: 25 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.844" H x 0.969" D Dimension mm: 46.8mm x 24.6mm

Showing 97–108 of 204 results
