440 VAC

Product Code	Data Sheet	Attributes
X386D 45 10 440	Data Sheet: X386D	Application: Filtering, Lighting, Motor Run Capacitance (µF): 45 Tolerance: ±10% Voltage Rating - AC: 440V Operating Temperature: -40 °C to +70 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Oil Filled, Seamless Can Termination: 4-Tine, Quick Disconnect Dimension inches: 5.250" H x 2.500" D Dimension mm: 133.4mm x 63.5mm CAP (µF) - Secondary: 5
X386D 45 3 440	Data Sheet: X386D	Application: Filtering, Lighting, Motor Run Capacitance (µF): 45 Tolerance: ±3% Voltage Rating - AC: 440V Operating Temperature: -40 °C to +70 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Oil Filled, Seamless Can Termination: 4-Tine, Quick Disconnect Dimension inches: 5.250" H x 2.500" D Dimension mm: 133.4mm x 63.5mm CAP (µF) - Secondary: 5
X386D 45 5 440	Data Sheet: X386D	Application: Filtering, Lighting, Motor Run Capacitance (µF): 45 Tolerance: ±5% Voltage Rating - AC: 440V Operating Temperature: -40 °C to +70 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Oil Filled, Seamless Can Termination: 4-Tine, Quick Disconnect Dimension inches: 5.250" H x 2.500" D Dimension mm: 133.4mm x 63.5mm CAP (µF) - Secondary: 5
X386D 45 6 440	Data Sheet: X386D	Application: Filtering, Lighting, Motor Run Capacitance (µF): 45 Tolerance: ±6% Voltage Rating - AC: 440V Operating Temperature: -40 °C to +70 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Oil Filled, Seamless Can Termination: 4-Tine, Quick Disconnect Dimension inches: 5.250" H x 2.500" D Dimension mm: 133.4mm x 63.5mm CAP (µF) - Secondary: 5
X386S 1 10 440	Data Sheet: X386S	Application: Filtering, Lighting, Motor Run Capacitance (µF): 1 Tolerance: ±10% Voltage Rating - AC: 440V Operating Temperature: -40 °C to +70 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Oil Filled, Seamless Can Termination: 4-Tine, Quick Disconnect Dimension inches: 2.875" H x 1.750" D Dimension mm: 73.0mm x 44.5mm
X386S 1 3 440	Data Sheet: X386S	Application: Filtering, Lighting, Motor Run Capacitance (µF): 1 Tolerance: ±3% Voltage Rating - AC: 440V Operating Temperature: -40 °C to +70 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Oil Filled, Seamless Can Termination: 4-Tine, Quick Disconnect Dimension inches: 2.875" H x 1.750" D Dimension mm: 73.0mm x 44.5mm
X386S 1 5 440	Data Sheet: X386S	Application: Filtering, Lighting, Motor Run Capacitance (µF): 1 Tolerance: ±5% Voltage Rating - AC: 440V Operating Temperature: -40 °C to +70 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Oil Filled, Seamless Can Termination: 4-Tine, Quick Disconnect Dimension inches: 2.875" H x 1.750" D Dimension mm: 73.0mm x 44.5mm
X386S 1 6 440	Data Sheet: X386S	Application: Filtering, Lighting, Motor Run Capacitance (µF): 1 Tolerance: ±6% Voltage Rating - AC: 440V Operating Temperature: -40 °C to +70 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Oil Filled, Seamless Can Termination: 4-Tine, Quick Disconnect Dimension inches: 2.875" H x 1.750" D Dimension mm: 73.0mm x 44.5mm
X386S 10 10 440	Data Sheet: X386S	Application: Filtering, Lighting, Motor Run Capacitance (µF): 10 Tolerance: ±10% Voltage Rating - AC: 440V Operating Temperature: -40 °C to +70 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Oil Filled, Seamless Can Termination: 4-Tine, Quick Disconnect Dimension inches: 2.875" H x 1.750" D Dimension mm: 73.0mm x 44.5mm
X386S 10 3 440	Data Sheet: X386S	Application: Filtering, Lighting, Motor Run Capacitance (µF): 10 Tolerance: ±3% Voltage Rating - AC: 440V Operating Temperature: -40 °C to +70 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Oil Filled, Seamless Can Termination: 4-Tine, Quick Disconnect Dimension inches: 2.875" H x 1.750" D Dimension mm: 73.0mm x 44.5mm
X386S 10 5 440	Data Sheet: X386S	Application: Filtering, Lighting, Motor Run Capacitance (µF): 10 Tolerance: ±5% Voltage Rating - AC: 440V Operating Temperature: -40 °C to +70 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Oil Filled, Seamless Can Termination: 4-Tine, Quick Disconnect Dimension inches: 2.875" H x 1.750" D Dimension mm: 73.0mm x 44.5mm
X386S 10 6 440	Data Sheet: X386S	Application: Filtering, Lighting, Motor Run Capacitance (µF): 10 Tolerance: ±6% Voltage Rating - AC: 440V Operating Temperature: -40 °C to +70 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Oil Filled, Seamless Can Termination: 4-Tine, Quick Disconnect Dimension inches: 2.875" H x 1.750" D Dimension mm: 73.0mm x 44.5mm
