4000V

Product Code	Data Sheet	Attributes
X375 0.22 2 4000	Data Sheet: X375	Application: Power Supply, Pulse Current Capacitance (µF): 0.22 Tolerance: ±2% Voltage Rating - DC: 4000V Voltage Rating - AC: Operating Temperature: -55 °C to +65 °C Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.914" H x 1.350" D Dimension mm: 48.6mm x 34.3mm
X375 0.22 20 4000	Data Sheet: X375	Application: Power Supply, Pulse Current Capacitance (µF): 0.22 Tolerance: ±20% Voltage Rating - DC: 4000V Voltage Rating - AC: Operating Temperature: -55 °C to +65 °C Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.914" H x 1.350" D Dimension mm: 48.6mm x 34.3mm
X375 0.22 5 4000	Data Sheet: X375	Application: Power Supply, Pulse Current Capacitance (µF): 0.22 Tolerance: ±5% Voltage Rating - DC: 4000V Voltage Rating - AC: Operating Temperature: -55 °C to +65 °C Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.914" H x 1.350" D Dimension mm: 48.6mm x 34.3mm
X375 0.33 1 4000	Data Sheet: X375	Application: Power Supply, Pulse Current Capacitance (µF): 0.33 Tolerance: ±1% Voltage Rating - DC: 4000V Voltage Rating - AC: Operating Temperature: -55 °C to +65 °C Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.914" H x 1.550" D Dimension mm: 48.6mm x 39.4mm
X375 0.33 10 4000	Data Sheet: X375	Application: Power Supply, Pulse Current Capacitance (µF): 0.33 Tolerance: ±10% Voltage Rating - DC: 4000V Voltage Rating - AC: Operating Temperature: -55 °C to +65 °C Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.914" H x 1.550" D Dimension mm: 48.6mm x 39.4mm
X375 0.33 2 4000	Data Sheet: X375	Application: Power Supply, Pulse Current Capacitance (µF): 0.33 Tolerance: ±2% Voltage Rating - DC: 4000V Voltage Rating - AC: Operating Temperature: -55 °C to +65 °C Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.914" H x 1.550" D Dimension mm: 48.6mm x 39.4mm
X375 0.33 20 4000	Data Sheet: X375	Application: Power Supply, Pulse Current Capacitance (µF): 0.33 Tolerance: ±20% Voltage Rating - DC: 4000V Voltage Rating - AC: Operating Temperature: -55 °C to +65 °C Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.914" H x 1.550" D Dimension mm: 48.6mm x 39.4mm
X375 0.33 5 4000	Data Sheet: X375	Application: Power Supply, Pulse Current Capacitance (µF): 0.33 Tolerance: ±5% Voltage Rating - DC: 4000V Voltage Rating - AC: Operating Temperature: -55 °C to +65 °C Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.914" H x 1.550" D Dimension mm: 48.6mm x 39.4mm
X675 0.001 10 4000	Data Sheet: X675	Application: Power Supply, Pulse Current Capacitance (µF): 0.001 Tolerance: ±10% Voltage Rating - DC: 4000V Voltage Rating - AC: Operating Temperature: -55 °C to +65 °C IPeak: 0.2 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polyester film Dielectric Material: Polyester – Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.284" H x 0.275" D Dimension mm: 32.6mm x 7.0mm
X675 0.001 20 4000	Data Sheet: X675	Application: Power Supply, Pulse Current Capacitance (µF): 0.001 Tolerance: ±20% Voltage Rating - DC: 4000V Voltage Rating - AC: Operating Temperature: -55 °C to +65 °C IPeak: 0.2 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polyester film Dielectric Material: Polyester – Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.284" H x 0.275" D Dimension mm: 32.6mm x 7.0mm
X675 0.001 5 4000	Data Sheet: X675	Application: Power Supply, Pulse Current Capacitance (µF): 0.001 Tolerance: ±5% Voltage Rating - DC: 4000V Voltage Rating - AC: Operating Temperature: -55 °C to +65 °C IPeak: 0.2 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polyester film Dielectric Material: Polyester – Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.284" H x 0.275" D Dimension mm: 32.6mm x 7.0mm
X675 0.0015 10 4000	Data Sheet: X675	Application: Power Supply, Pulse Current Capacitance (µF): 0.0015 Tolerance: ±10% Voltage Rating - DC: 4000V Voltage Rating - AC: Operating Temperature: -55 °C to +65 °C IPeak: 0.3 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polyester film Dielectric Material: Polyester – Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.284" H x 0.300" D Dimension mm: 32.6mm x 7.6mm
