4.7µF

Product Code	Data Sheet	Attributes
X333F 4.7 20 220	Data Sheet: X333F	Application: Power Supply, Pulse Current Capacitance (µF): 4.7 Tolerance: ±20% Voltage Rating - DC: 400V Voltage Rating - AC: 220V Operating Temperature: -55 °C to +90 °C ESR: 7 mOhms IPeak: 26 Irms (Arms): check data sheet Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.640" T x 1.813" H x 0.940" L Dimension mm: 16.3mm x 46.1mm x 23.9mm ESR kHz: 100kHz
X333F 4.7 20 240	Data Sheet: X333F	Application: Power Supply, Pulse Current Capacitance (µF): 4.7 Tolerance: ±20% Voltage Rating - DC: 600V Voltage Rating - AC: 240V Operating Temperature: -55 °C to +90 °C ESR: 9 mOhms IPeak: 31 Irms (Arms): check data sheet Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.990" T x 2.313" H x 1.330" L Dimension mm: 25.1mm x 58.8mm x 33.8mm ESR kHz: 100kHz
X333F 4.7 20 250	Data Sheet: X333F	Application: Power Supply, Pulse Current Capacitance (µF): 4.7 Tolerance: ±20% Voltage Rating - DC: 1000V Voltage Rating - AC: 250V Operating Temperature: -55 °C to +90 °C ESR: 9 mOhms IPeak: 38 Irms (Arms): check data sheet Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.175" T x 2.313" H x 1.575" L Dimension mm: 29.8mm x 58.8mm x 40.0mm ESR kHz: 100kHz
X333F 4.7 5 220	Data Sheet: X333F	Application: Power Supply, Pulse Current Capacitance (µF): 4.7 Tolerance: ±5% Voltage Rating - DC: 400V Voltage Rating - AC: 220V Operating Temperature: -55 °C to +90 °C ESR: 7 mOhms IPeak: 26 Irms (Arms): check data sheet Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.640" T x 1.813" H x 0.940" L Dimension mm: 16.3mm x 46.1mm x 23.9mm ESR kHz: 100kHz
X333F 4.7 5 240	Data Sheet: X333F	Application: Power Supply, Pulse Current Capacitance (µF): 4.7 Tolerance: ±5% Voltage Rating - DC: 600V Voltage Rating - AC: 240V Operating Temperature: -55 °C to +90 °C ESR: 9 mOhms IPeak: 31 Irms (Arms): check data sheet Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.990" T x 2.313" H x 1.330" L Dimension mm: 25.1mm x 58.8mm x 33.8mm ESR kHz: 100kHz
X333F 4.7 5 250	Data Sheet: X333F	Application: Power Supply, Pulse Current Capacitance (µF): 4.7 Tolerance: ±5% Voltage Rating - DC: 1000V Voltage Rating - AC: 250V Operating Temperature: -55 °C to +90 °C ESR: 9 mOhms IPeak: 38 Irms (Arms): check data sheet Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.175" T x 2.313" H x 1.575" L Dimension mm: 29.8mm x 58.8mm x 40.0mm ESR kHz: 100kHz
X368 4.7 10 250	Data Sheet: X368	Application: Power Supply, Pulse Current Capacitance (µF): 4.7 Tolerance: ±10% Voltage Rating - DC: 250V Operating Temperature: -40 °C to +85 °C IPeak: 5.6 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.457" H x 0.827" D Dimension mm: 37.0mm x 21.0mm
X368 4.7 20 250	Data Sheet: X368	Application: Power Supply, Pulse Current Capacitance (µF): 4.7 Tolerance: ±20% Voltage Rating - DC: 250V Operating Temperature: -40 °C to +85 °C IPeak: 5.6 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.457" H x 0.827" D Dimension mm: 37.0mm x 21.0mm
X368 4.7 5 250	Data Sheet: X368	Application: Power Supply, Pulse Current Capacitance (µF): 4.7 Tolerance: ±5% Voltage Rating - DC: 250V Operating Temperature: -40 °C to +85 °C IPeak: 5.6 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.457" H x 0.827" D Dimension mm: 37.0mm x 21.0mm
X620 4.7 10 100	Data Sheet: X620	Application: Filtering, General Purpose, Instrumentation Capacitance (µF): 4.7 Tolerance: ±10% Voltage Rating - DC: 100V Operating Temperature: -40 °C to +85 °C IPeak: 9.4 Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polyester film Mounting Type: Through Hole Dielectric Material: Polyester - Metallized Case: Epoxy Dipped Termination: Solid Wire Dimension inches: 0.315" T x 0.650" H x 1.024" L Dimension mm: 8.0mm x 16.5mm x 26.0mm
X620 4.7 10 250	Data Sheet: X620	Application: Filtering, General Purpose, Instrumentation Capacitance (µF): 4.7 Tolerance: ±10% Voltage Rating - DC: 250V Operating Temperature: -40 °C to +85 °C IPeak: 23.5 Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polyester film Mounting Type: Through Hole Dielectric Material: Polyester - Metallized Case: Epoxy Dipped Termination: Solid Wire Dimension inches: 0.492" T x 0.886" H x 1.024" L Dimension mm: 12.5mm x 22.5mm x 26.0mm
X620 4.7 20 100	Data Sheet: X620	Application: Filtering, General Purpose, Instrumentation Capacitance (µF): 4.7 Tolerance: ±20% Voltage Rating - DC: 100V Operating Temperature: -40 °C to +85 °C IPeak: 9.4 Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polyester film Mounting Type: Through Hole Dielectric Material: Polyester - Metallized Case: Epoxy Dipped Termination: Solid Wire Dimension inches: 0.315" T x 0.650" H x 1.024" L Dimension mm: 8.0mm x 16.5mm x 26.0mm
