3uF

Product Code	Data Sheet	Attributes
X329(F) 3 10 500	Data Sheet: 329	Application: IGBT Snubber Capacitance (µF): 3 Tolerance: ±10% Voltage Rating - DC: 1200V Voltage Rating - AC: 500V Operating Temperature: -40 °C to +85 °C ESR: 2.9 mOhms IPeak: 823 Irms (Arms): 23.3 Lifecycle @ Rated Temp & Voltage: 15,000 hrs Construction: metallized polypropylene film and foil Dielectric Material: Polypropylene – Metallized and Foil Case: Preformed Case with Epoxy Fill Termination: Slotted Tabs Dimension inches: 1.760" T x 2.263" H Dimension mm: 44.7mm x 57.5mm ESR kHz: 100kHz
X329(F) 3 5 250	Data Sheet: 329	Application: IGBT Snubber Capacitance (µF): 3 Tolerance: ±5% Voltage Rating - DC: 600V Voltage Rating - AC: 250V Operating Temperature: -40 °C to +85 °C ESR: 5.7 mOhms IPeak: 191 Irms (Arms): 9.3 Lifecycle @ Rated Temp & Voltage: 15,000 hrs Construction: metallized polypropylene film and foil Dielectric Material: Polypropylene – Metallized and Foil Case: Preformed Case with Epoxy Fill Termination: Slotted Tabs Dimension inches: 1.160" T x 1.463" H Dimension mm: 29.5mm x 37.2mm ESR kHz: 100kHz
X329(F) 3 5 500	Data Sheet: 329	Application: IGBT Snubber Capacitance (µF): 3 Tolerance: ±5% Voltage Rating - DC: 1200V Voltage Rating - AC: 500V Operating Temperature: -40 °C to +85 °C ESR: 2.9 mOhms IPeak: 823 Irms (Arms): 23.3 Lifecycle @ Rated Temp & Voltage: 15,000 hrs Construction: metallized polypropylene film and foil Dielectric Material: Polypropylene – Metallized and Foil Case: Preformed Case with Epoxy Fill Termination: Slotted Tabs Dimension inches: 1.760" T x 2.263" H Dimension mm: 44.7mm x 57.5mm ESR kHz: 100kHz
X329(S) 3 10 250	Data Sheet: 329	Application: IGBT Snubber Capacitance (µF): 3 Tolerance: ±10% Voltage Rating - DC: 600V Voltage Rating - AC: 250V Operating Temperature: -40 °C to +85 °C ESR: 5.7 mOhms IPeak: 191 Irms (Arms): 9.3 Lifecycle @ Rated Temp & Voltage: 15,000 hrs Construction: metallized polypropylene film and foil Dielectric Material: Polypropylene – Metallized and Foil Case: Preformed Case with Epoxy Fill Termination: Slotted Tabs Dimension inches: 1.160" T x 1.463" H Dimension mm: 29.5mm x 37.2mm ESR kHz: 100kHz
X329(S) 3 10 500	Data Sheet: 329	Application: IGBT Snubber Capacitance (µF): 3 Tolerance: ±10% Voltage Rating - DC: 1200V Voltage Rating - AC: 500V Operating Temperature: -40 °C to +85 °C ESR: 2.9 mOhms IPeak: 823 Irms (Arms): 23.3 Lifecycle @ Rated Temp & Voltage: 15,000 hrs Construction: metallized polypropylene film and foil Dielectric Material: Polypropylene – Metallized and Foil Case: Preformed Case with Epoxy Fill Termination: Slotted Tabs Dimension inches: 1.760" T x 2.263" H Dimension mm: 44.7mm x 57.5mm ESR kHz: 100kHz
X329(S) 3 5 250	Data Sheet: 329	Application: IGBT Snubber Capacitance (µF): 3 Tolerance: ±5% Voltage Rating - DC: 600V Voltage Rating - AC: 250V Operating Temperature: -40 °C to +85 °C ESR: 5.7 mOhms IPeak: 191 Irms (Arms): 9.3 Lifecycle @ Rated Temp & Voltage: 15,000 hrs Construction: metallized polypropylene film and foil Dielectric Material: Polypropylene – Metallized and Foil Case: Preformed Case with Epoxy Fill Termination: Slotted Tabs Dimension inches: 1.160" T x 1.463" H Dimension mm: 29.5mm x 37.2mm ESR kHz: 100kHz
X329(S) 3 5 500	Data Sheet: 329	Application: IGBT Snubber Capacitance (µF): 3 Tolerance: ±5% Voltage Rating - DC: 1200V Voltage Rating - AC: 500V Operating Temperature: -40 °C to +85 °C ESR: 2.9 mOhms IPeak: 823 Irms (Arms): 23.3 Lifecycle @ Rated Temp & Voltage: 15,000 hrs Construction: metallized polypropylene film and foil Dielectric Material: Polypropylene – Metallized and Foil Case: Preformed Case with Epoxy Fill Termination: Slotted Tabs Dimension inches: 1.760" T x 2.263" H Dimension mm: 44.7mm x 57.5mm ESR kHz: 100kHz
X329(W) 3 10 250	Data Sheet: 329	Application: IGBT Snubber Capacitance (µF): 3 Tolerance: ±10% Voltage Rating - DC: 600V Voltage Rating - AC: 250V Operating Temperature: -40 °C to +85 °C ESR: 5.7 mOhms IPeak: 191 Irms (Arms): 9.3 Lifecycle @ Rated Temp & Voltage: 15,000 hrs Construction: metallized polypropylene film and foil Dielectric Material: Polypropylene – Metallized and Foil Case: Preformed Case with Epoxy Fill Termination: Slotted Tabs Dimension inches: 1.160" T x 1.463" H Dimension mm: 29.5mm x 37.2mm ESR kHz: 100kHz
X329(W) 3 10 500	Data Sheet: 329	Application: IGBT Snubber Capacitance (µF): 3 Tolerance: ±10% Voltage Rating - DC: 1200V Voltage Rating - AC: 500V Operating Temperature: -40 °C to +85 °C ESR: 2.9 mOhms IPeak: 823 Irms (Arms): 23.3 Lifecycle @ Rated Temp & Voltage: 15,000 hrs Construction: metallized polypropylene film and foil Dielectric Material: Polypropylene – Metallized and Foil Case: Preformed Case with Epoxy Fill Termination: Slotted Tabs Dimension inches: 1.760" T x 2.263" H Dimension mm: 44.7mm x 57.5mm ESR kHz: 100kHz
X329(W) 3 5 250	Data Sheet: 329	Application: IGBT Snubber Capacitance (µF): 3 Tolerance: ±5% Voltage Rating - DC: 600V Voltage Rating - AC: 250V Operating Temperature: -40 °C to +85 °C ESR: 5.7 mOhms IPeak: 191 Irms (Arms): 9.3 Lifecycle @ Rated Temp & Voltage: 15,000 hrs Construction: metallized polypropylene film and foil Dielectric Material: Polypropylene – Metallized and Foil Case: Preformed Case with Epoxy Fill Termination: Slotted Tabs Dimension inches: 1.160" T x 1.463" H Dimension mm: 29.5mm x 37.2mm ESR kHz: 100kHz
X329(W) 3 5 500	Data Sheet: 329	Application: IGBT Snubber Capacitance (µF): 3 Tolerance: ±5% Voltage Rating - DC: 1200V Voltage Rating - AC: 500V Operating Temperature: -40 °C to +85 °C ESR: 2.9 mOhms IPeak: 823 Irms (Arms): 23.3 Lifecycle @ Rated Temp & Voltage: 15,000 hrs Construction: metallized polypropylene film and foil Dielectric Material: Polypropylene – Metallized and Foil Case: Preformed Case with Epoxy Fill Termination: Slotted Tabs Dimension inches: 1.760" T x 2.263" H Dimension mm: 44.7mm x 57.5mm ESR kHz: 100kHz
X335 3 1 135	Data Sheet: X335	Application: Power Supply, Pulse Current Capacitance (µF): 3 Tolerance: ±1% Voltage Rating - DC: 200V Voltage Rating - AC: 135V Operating Temperature: -55 °C to +90 °C ESR: 15 mOhms IPeak: 23 Irms (Arms): Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.594" H x 0.828" D Dimension mm: 40.5mm x 21.0mm ESR kHz: 100kHz
