3uF

Product Code	Data Sheet	Attributes
REA99 3 20 100	Data Sheet: REA99	Application: General Purpose Capacitance (µF): 3 Tolerance: ±20% Voltage Rating - DC: 100V Voltage Rating - AC: Operating Temperature: -55 °C to +125 °C IPeak: 10.5 Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polyphenylene sulfide Dielectric Material: Polyphenylene Sulfide - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.344" H x 0.641" D Dimension mm: 34.1mm x 16.3mm
REA99 3 20 200	Data Sheet: REA99	Application: General Purpose Capacitance (µF): 3 Tolerance: ±20% Voltage Rating - DC: 200V Voltage Rating - AC: Operating Temperature: -55 °C to +125 °C IPeak: 13.5 Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polyphenylene sulfide Dielectric Material: Polyphenylene Sulfide - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.594" H x 0.812" D Dimension mm: 40.5mm x 20.6mm
REA99 3 20 400	Data Sheet: REA99	Application: General Purpose Capacitance (µF): 3 Tolerance: ±20% Voltage Rating - DC: 400V Voltage Rating - AC: Operating Temperature: -55 °C to +125 °C IPeak: 16.5 Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polyphenylene sulfide Dielectric Material: Polyphenylene Sulfide - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 2.407" H x 1.250" D Dimension mm: 61.1mm x 31.8mm
REA99 3 20 50	Data Sheet: REA99	Application: General Purpose Capacitance (µF): 3 Tolerance: ±20% Voltage Rating - DC: 50V Voltage Rating - AC: Operating Temperature: -55 °C to +125 °C IPeak: 10.5 Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polyphenylene sulfide Dielectric Material: Polyphenylene Sulfide - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.907" H x 0.469" D Dimension mm: 23.0mm x 11.9mm
REA99 3 5 100	Data Sheet: REA99	Application: General Purpose Capacitance (µF): 3 Tolerance: ±5% Voltage Rating - DC: 100V Voltage Rating - AC: Operating Temperature: -55 °C to +125 °C IPeak: 10.5 Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polyphenylene sulfide Dielectric Material: Polyphenylene Sulfide - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.344" H x 0.641" D Dimension mm: 34.1mm x 16.3mm
REA99 3 5 200	Data Sheet: REA99	Application: General Purpose Capacitance (µF): 3 Tolerance: ±5% Voltage Rating - DC: 200V Voltage Rating - AC: Operating Temperature: -55 °C to +125 °C IPeak: 13.5 Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polyphenylene sulfide Dielectric Material: Polyphenylene Sulfide - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.594" H x 0.812" D Dimension mm: 40.5mm x 20.6mm
REA99 3 5 400	Data Sheet: REA99	Application: General Purpose Capacitance (µF): 3 Tolerance: ±5% Voltage Rating - DC: 400V Voltage Rating - AC: Operating Temperature: -55 °C to +125 °C IPeak: 16.5 Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polyphenylene sulfide Dielectric Material: Polyphenylene Sulfide - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 2.407" H x 1.250" D Dimension mm: 61.1mm x 31.8mm
REA99 3 5 50	Data Sheet: REA99	Application: General Purpose Capacitance (µF): 3 Tolerance: ±5% Voltage Rating - DC: 50V Voltage Rating - AC: Operating Temperature: -55 °C to +125 °C IPeak: 10.5 Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polyphenylene sulfide Dielectric Material: Polyphenylene Sulfide - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.907" H x 0.469" D Dimension mm: 23.0mm x 11.9mm
X300 3 10 200	Data Sheet: X300	Application: Power Supply Capacitance (µF): 3 Tolerance: ±10% Voltage Rating - DC: 200V Voltage Rating - AC: Operating Temperature: -55 °C to +85 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Self-Encased w/ PP or PE Termination: Solid Wire Dimension inches: 1.574" H x 0.630" D Dimension mm: 40.0mm x 16.0mm
X300 3 20 200	Data Sheet: X300	Application: Power Supply Capacitance (µF): 3 Tolerance: ±20% Voltage Rating - DC: 200V Voltage Rating - AC: Operating Temperature: -55 °C to +85 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Self-Encased w/ PP or PE Termination: Solid Wire Dimension inches: 1.574" H x 0.630" D Dimension mm: 40.0mm x 16.0mm
X300 3 5 200	Data Sheet: X300	Application: Power Supply Capacitance (µF): 3 Tolerance: ±5% Voltage Rating - DC: 200V Voltage Rating - AC: Operating Temperature: -55 °C to +85 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Self-Encased w/ PP or PE Termination: Solid Wire Dimension inches: 1.574" H x 0.630" D Dimension mm: 40.0mm x 16.0mm
X329(F) 3 10 250	Data Sheet: 329	Application: IGBT Snubber Capacitance (µF): 3 Tolerance: ±10% Voltage Rating - DC: 600V Voltage Rating - AC: 250V Operating Temperature: -40 °C to +85 °C ESR: 5.7 mOhms IPeak: 191 Irms (Arms): 9.3 Lifecycle @ Rated Temp & Voltage: 15,000 hrs Construction: metallized polypropylene film and foil Dielectric Material: Polypropylene – Metallized and Foil Case: Preformed Case with Epoxy Fill Termination: Slotted Tabs Dimension inches: 1.160" T x 1.463" H Dimension mm: 29.5mm x 37.2mm ESR kHz: 100kHz
