3mFD

Product Code	Data Sheet	Attributes
X335L 3 20 240	Data Sheet: X335L	Application: Power Supply, Pulse Current Capacitance (µF): 3 Tolerance: ±20% Voltage Rating - DC: 400V Voltage Rating - AC: 240V Operating Temperature: -55 °C to +90 °C ESR: 15 mOhms IPeak: 30 Irms (Arms): check data sheet Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solder Lugs Dimension inches: 1.906" H x 1.166" D Dimension mm: 48.4mm x 29.6mm ESR kHz: 100kHz
X335L 3 20 67	Data Sheet: X335L	Application: Power Supply, Pulse Current Capacitance (µF): 3 Tolerance: ±20% Voltage Rating - DC: 100V Voltage Rating - AC: 67V Operating Temperature: -55 °C to +90 °C ESR: 15 mOhms IPeak: 19 Irms (Arms): check data sheet Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solder Lugs Dimension inches: 1.156" H x 0.794" D Dimension mm: 29.4mm x 20.2mm ESR kHz: 100kHz
X335L 3 5 135	Data Sheet: X335L	Application: Power Supply, Pulse Current Capacitance (µF): 3 Tolerance: ±5% Voltage Rating - DC: 200V Voltage Rating - AC: 135V Operating Temperature: -55 °C to +90 °C ESR: 15 mOhms IPeak: 23 Irms (Arms): check data sheet Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solder Lugs Dimension inches: 1.625" H x 0.824" D Dimension mm: 41.3mm x 20.9mm ESR kHz: 100kHz
X335L 3 5 240	Data Sheet: X335L	Application: Power Supply, Pulse Current Capacitance (µF): 3 Tolerance: ±5% Voltage Rating - DC: 400V Voltage Rating - AC: 240V Operating Temperature: -55 °C to +90 °C ESR: 15 mOhms IPeak: 30 Irms (Arms): check data sheet Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solder Lugs Dimension inches: 1.906" H x 1.166" D Dimension mm: 48.4mm x 29.6mm ESR kHz: 100kHz
X335L 3 5 67	Data Sheet: X335L	Application: Power Supply, Pulse Current Capacitance (µF): 3 Tolerance: ±5% Voltage Rating - DC: 100V Voltage Rating - AC: 67V Operating Temperature: -55 °C to +90 °C ESR: 15 mOhms IPeak: 19 Irms (Arms): check data sheet Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solder Lugs Dimension inches: 1.156" H x 0.794" D Dimension mm: 29.4mm x 20.2mm ESR kHz: 100kHz
X345 3 10 220	Data Sheet: X345	Application: DC Filter, Sample Hold Capacitance (µF): 3 Tolerance: ±10% Voltage Rating - AC: 220V Operating Temperature: -25 °C to +75 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound combination of metallized polypropylene and polyester Dielectric Material: Polypropylene – Metallized and Polyester Case: Preformed Case with Epoxy Fill Termination: AMP187, AMP250, SOLID WIRE, DIN SOLDER TABS, AND STRANDED WIRE Dimension inches: 0.669" T x 1.063" H x 1.220" W Dimension mm: 17.0mm x 27.0mm x 31.0mm
X345 3 5 220	Data Sheet: X345	Application: DC Filter, Sample Hold Capacitance (µF): 3 Tolerance: ±5% Voltage Rating - AC: 220V Operating Temperature: -25 °C to +75 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound combination of metallized polypropylene and polyester Dielectric Material: Polypropylene – Metallized and Polyester Case: Preformed Case with Epoxy Fill Termination: AMP187, AMP250, SOLID WIRE, DIN SOLDER TABS, AND STRANDED WIRE Dimension inches: 0.669" T x 1.063" H x 1.220" W Dimension mm: 17.0mm x 27.0mm x 31.0mm
X347 3 10 100 / 250	Data Sheet: X347	Application: DC Filter, Sample Hold Capacitance (µF): 3 Tolerance: ±10% Voltage Rating - AC: 100V / 250V Operating Temperature: -25 °C to +85 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene – Metallized Case: Preformed Case with Epoxy Fill Termination: AMP187, AMP250, SOLID WIRE, DIN SOLDER TABS, AND STRANDED WIRE Dimension inches: 0.669" T x 1.063" H x 1.220" W Dimension mm: 17.0mm x 27.0mm x 31.0mm
X347 3 10 350	Data Sheet: X347	Application: DC Filter, Sample Hold Capacitance (µF): 3 Tolerance: ±10% Voltage Rating - AC: 350V Operating Temperature: -25 °C to +85 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene – Metallized Case: Preformed Case with Epoxy Fill Termination: AMP187, AMP250, SOLID WIRE, DIN SOLDER TABS, AND STRANDED WIRE Dimension inches: 0.827" T x 1.220" H x 1.496" W Dimension mm: 21.0mm x 31.0mm x 38.0mm
X347 3 10 400	Data Sheet: X347	Application: DC Filter, Sample Hold Capacitance (µF): 3 Tolerance: ±10% Voltage Rating - AC: 400V Operating Temperature: -25 °C to +85 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene – Metallized Case: Preformed Case with Epoxy Fill Termination: AMP187, AMP250, SOLID WIRE, DIN SOLDER TABS, AND STRANDED WIRE Dimension inches: 0.827" T x 1.220" H x 1.890" W Dimension mm: 21.0mm x 31.0mm x 48.0mm
X347 3 10 450	Data Sheet: X347	Application: DC Filter, Sample Hold Capacitance (µF): 3 Tolerance: ±10% Voltage Rating - AC: 450V Operating Temperature: -25 °C to +85 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene – Metallized Case: Preformed Case with Epoxy Fill Termination: AMP187, AMP250, SOLID WIRE, DIN SOLDER TABS, AND STRANDED WIRE Dimension inches: 0.827" T x 1.220" H x 2.283" W Dimension mm: 21.0mm x 31.0mm x 58.0mm
X347 3 5 100 / 250	Data Sheet: X347	Application: DC Filter, Sample Hold Capacitance (µF): 3 Tolerance: ±5% Voltage Rating - AC: 100V / 250V Operating Temperature: -25 °C to +85 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene – Metallized Case: Preformed Case with Epoxy Fill Termination: AMP187, AMP250, SOLID WIRE, DIN SOLDER TABS, AND STRANDED WIRE Dimension inches: 0.669" T x 1.063" H x 1.220" W Dimension mm: 17.0mm x 27.0mm x 31.0mm
