30µF

Product Code	Image	Data Sheet	Attributes
X300 30 10 200		Data Sheet: X300	Application: Power Supply Capacitance (µF): 30 Tolerance: ±10% Voltage Rating - DC: 200V Voltage Rating - AC: Operating Temperature: -55 °C to +85 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Self-Encased w/ PP or PE Termination: Solid Wire Dimension inches: 1.870" H x 1.630" D Dimension mm: 47.5mm x 41.4mm
X300 30 20 200		Data Sheet: X300	Application: Power Supply Capacitance (µF): 30 Tolerance: ±20% Voltage Rating - DC: 200V Voltage Rating - AC: Operating Temperature: -55 °C to +85 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Self-Encased w/ PP or PE Termination: Solid Wire Dimension inches: 1.870" H x 1.630" D Dimension mm: 47.5mm x 41.4mm
X300 30 5 200		Data Sheet: X300	Application: Power Supply Capacitance (µF): 30 Tolerance: ±5% Voltage Rating - DC: 200V Voltage Rating - AC: Operating Temperature: -55 °C to +85 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Self-Encased w/ PP or PE Termination: Solid Wire Dimension inches: 1.870" H x 1.630" D Dimension mm: 47.5mm x 41.4mm
X335 30 1 63		Data Sheet: X335	Application: Power Supply, Pulse Current Capacitance (µF): 30 Tolerance: ±1% Voltage Rating - DC: 100V Voltage Rating - AC: 63V Operating Temperature: -55 °C to +90 °C ESR: 8 mOhms IPeak: 78 Irms (Arms): Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 2.344" H x 1.325" D Dimension mm: 59.5mm x 33.7mm ESR kHz: 100kHz
X335 30 10 63		Data Sheet: X335	Application: Power Supply, Pulse Current Capacitance (µF): 30 Tolerance: ±10% Voltage Rating - DC: 100V Voltage Rating - AC: 63V Operating Temperature: -55 °C to +90 °C ESR: 8 mOhms IPeak: 78 Irms (Arms): Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 2.344" H x 1.325" D Dimension mm: 59.5mm x 33.7mm ESR kHz: 100kHz
X335 30 2 63		Data Sheet: X335	Application: Power Supply, Pulse Current Capacitance (µF): 30 Tolerance: ±2% Voltage Rating - DC: 100V Voltage Rating - AC: 63V Operating Temperature: -55 °C to +90 °C ESR: 8 mOhms IPeak: 78 Irms (Arms): Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 2.344" H x 1.325" D Dimension mm: 59.5mm x 33.7mm ESR kHz: 100kHz
X335 30 20 63		Data Sheet: X335	Application: Power Supply, Pulse Current Capacitance (µF): 30 Tolerance: ±20% Voltage Rating - DC: 100V Voltage Rating - AC: 63V Operating Temperature: -55 °C to +90 °C ESR: 8 mOhms IPeak: 78 Irms (Arms): Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 2.344" H x 1.325" D Dimension mm: 59.5mm x 33.7mm ESR kHz: 100kHz
X335 30 5 63		Data Sheet: X335	Application: Power Supply, Pulse Current Capacitance (µF): 30 Tolerance: ±5% Voltage Rating - DC: 100V Voltage Rating - AC: 63V Operating Temperature: -55 °C to +90 °C ESR: 8 mOhms IPeak: 78 Irms (Arms): Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 2.344" H x 1.325" D Dimension mm: 59.5mm x 33.7mm ESR kHz: 100kHz
X335L 30 1 67		Data Sheet: X335L	Application: Power Supply, Pulse Current Capacitance (µF): 30 Tolerance: ±1% Voltage Rating - DC: 100V Voltage Rating - AC: 67V Operating Temperature: -55 °C to +90 °C ESR: 8 mOhms IPeak: 78 Irms (Arms): check data sheet Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solder Lugs Dimension inches: 2.406" H x 1.280" D Dimension mm: 61.1mm x 32.5mm ESR kHz: 100kHz
X335L 30 10 67		Data Sheet: X335L	Application: Power Supply, Pulse Current Capacitance (µF): 30 Tolerance: ±10% Voltage Rating - DC: 100V Voltage Rating - AC: 67V Operating Temperature: -55 °C to +90 °C ESR: 8 mOhms IPeak: 78 Irms (Arms): check data sheet Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solder Lugs Dimension inches: 2.406" H x 1.280" D Dimension mm: 61.1mm x 32.5mm ESR kHz: 100kHz
X335L 30 2 67		Data Sheet: X335L	Application: Power Supply, Pulse Current Capacitance (µF): 30 Tolerance: ±2% Voltage Rating - DC: 100V Voltage Rating - AC: 67V Operating Temperature: -55 °C to +90 °C ESR: 8 mOhms IPeak: 78 Irms (Arms): check data sheet Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solder Lugs Dimension inches: 2.406" H x 1.280" D Dimension mm: 61.1mm x 32.5mm ESR kHz: 100kHz
X335L 30 20 67		Data Sheet: X335L	Application: Power Supply, Pulse Current Capacitance (µF): 30 Tolerance: ±20% Voltage Rating - DC: 100V Voltage Rating - AC: 67V Operating Temperature: -55 °C to +90 °C ESR: 8 mOhms IPeak: 78 Irms (Arms): check data sheet Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solder Lugs Dimension inches: 2.406" H x 1.280" D Dimension mm: 61.1mm x 32.5mm ESR kHz: 100kHz

Showing 13–24 of 99 results
