260 VAC

Product Code	Data Sheet	Attributes
WME-RS 25 6 260	Data Sheet: WME-RS	Application: Filtering, Lighting, Motor Run Capacitance (µF): 25 Tolerance: ±6% Voltage Rating - AC: 260V Operating Temperature: -40 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Seamless Can Termination: 2-Tine, Quick Disconnect Dimension inches: 3.937" H x 1.595" D Dimension mm: 100.0mm x 40.5mm
WME-RS 27 10 260	Data Sheet: WME-RS	Application: Filtering, Lighting, Motor Run Capacitance (µF): 27 Tolerance: ±10% Voltage Rating - AC: 260V Operating Temperature: -40 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Seamless Can Termination: 2-Tine, Quick Disconnect Dimension inches: 3.937" H x 1.595" D Dimension mm: 100.0mm x 40.5mm
WME-RS 27 3 260	Data Sheet: WME-RS	Application: Filtering, Lighting, Motor Run Capacitance (µF): 27 Tolerance: ±3% Voltage Rating - AC: 260V Operating Temperature: -40 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Seamless Can Termination: 2-Tine, Quick Disconnect Dimension inches: 3.937" H x 1.595" D Dimension mm: 100.0mm x 40.5mm
WME-RS 27 5 260	Data Sheet: WME-RS	Application: Filtering, Lighting, Motor Run Capacitance (µF): 27 Tolerance: ±5% Voltage Rating - AC: 260V Operating Temperature: -40 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Seamless Can Termination: 2-Tine, Quick Disconnect Dimension inches: 3.937" H x 1.595" D Dimension mm: 100.0mm x 40.5mm
WME-RS 27 6 260	Data Sheet: WME-RS	Application: Filtering, Lighting, Motor Run Capacitance (µF): 27 Tolerance: ±6% Voltage Rating - AC: 260V Operating Temperature: -40 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Seamless Can Termination: 2-Tine, Quick Disconnect Dimension inches: 3.937" H x 1.595" D Dimension mm: 100.0mm x 40.5mm
WME-RS 30 10 260	Data Sheet: WME-RS	Application: Filtering, Lighting, Motor Run Capacitance (µF): 30 Tolerance: ±10% Voltage Rating - AC: 260V Operating Temperature: -40 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Seamless Can Termination: 2-Tine, Quick Disconnect Dimension inches: 3.937" H x 1.595" D Dimension mm: 100.0mm x 40.5mm
WME-RS 30 3 260	Data Sheet: WME-RS	Application: Filtering, Lighting, Motor Run Capacitance (µF): 30 Tolerance: ±3% Voltage Rating - AC: 260V Operating Temperature: -40 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Seamless Can Termination: 2-Tine, Quick Disconnect Dimension inches: 3.937" H x 1.595" D Dimension mm: 100.0mm x 40.5mm
WME-RS 30 5 260	Data Sheet: WME-RS	Application: Filtering, Lighting, Motor Run Capacitance (µF): 30 Tolerance: ±5% Voltage Rating - AC: 260V Operating Temperature: -40 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Seamless Can Termination: 2-Tine, Quick Disconnect Dimension inches: 3.937" H x 1.595" D Dimension mm: 100.0mm x 40.5mm
WME-RS 30 6 260	Data Sheet: WME-RS	Application: Filtering, Lighting, Motor Run Capacitance (µF): 30 Tolerance: ±6% Voltage Rating - AC: 260V Operating Temperature: -40 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Seamless Can Termination: 2-Tine, Quick Disconnect Dimension inches: 3.937" H x 1.595" D Dimension mm: 100.0mm x 40.5mm
WME-RS 35 10 260	Data Sheet: WME-RS	Application: Filtering, Lighting, Motor Run Capacitance (µF): 35 Tolerance: ±10% Voltage Rating - AC: 260V Operating Temperature: -40 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Seamless Can Termination: 2-Tine, Quick Disconnect Dimension inches: 3.937" H x 1.760" D Dimension mm: 100.0mm x 44.7mm
WME-RS 35 3 260	Data Sheet: WME-RS	Application: Filtering, Lighting, Motor Run Capacitance (µF): 35 Tolerance: ±3% Voltage Rating - AC: 260V Operating Temperature: -40 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Seamless Can Termination: 2-Tine, Quick Disconnect Dimension inches: 3.937" H x 1.760" D Dimension mm: 100.0mm x 44.7mm
WME-RS 35 5 260	Data Sheet: WME-RS	Application: Filtering, Lighting, Motor Run Capacitance (µF): 35 Tolerance: ±5% Voltage Rating - AC: 260V Operating Temperature: -40 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Seamless Can Termination: 2-Tine, Quick Disconnect Dimension inches: 3.937" H x 1.760" D Dimension mm: 100.0mm x 44.7mm
