260 VAC

Product Code	Data Sheet	Attributes
WME-RS 14 6 260	Data Sheet: WME-RS	Application: Filtering, Lighting, Motor Run Capacitance (µF): 14 Tolerance: ±6% Voltage Rating - AC: 260V Operating Temperature: -40 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Seamless Can Termination: 2-Tine, Quick Disconnect Dimension inches: 2.953" H x 1.595" D Dimension mm: 75.0mm x 40.5mm
WME-RS 15 10 260	Data Sheet: WME-RS	Application: Filtering, Lighting, Motor Run Capacitance (µF): 15 Tolerance: ±10% Voltage Rating - AC: 260V Operating Temperature: -40 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Seamless Can Termination: 2-Tine, Quick Disconnect Dimension inches: 2.953" H x 1.595" D Dimension mm: 75.0mm x 40.5mm
WME-RS 15 3 260	Data Sheet: WME-RS	Application: Filtering, Lighting, Motor Run Capacitance (µF): 15 Tolerance: ±3% Voltage Rating - AC: 260V Operating Temperature: -40 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Seamless Can Termination: 2-Tine, Quick Disconnect Dimension inches: 2.953" H x 1.595" D Dimension mm: 75.0mm x 40.5mm
WME-RS 15 5 260	Data Sheet: WME-RS	Application: Filtering, Lighting, Motor Run Capacitance (µF): 15 Tolerance: ±5% Voltage Rating - AC: 260V Operating Temperature: -40 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Seamless Can Termination: 2-Tine, Quick Disconnect Dimension inches: 2.953" H x 1.595" D Dimension mm: 75.0mm x 40.5mm
WME-RS 15 6 260	Data Sheet: WME-RS	Application: Filtering, Lighting, Motor Run Capacitance (µF): 15 Tolerance: ±6% Voltage Rating - AC: 260V Operating Temperature: -40 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Seamless Can Termination: 2-Tine, Quick Disconnect Dimension inches: 2.953" H x 1.595" D Dimension mm: 75.0mm x 40.5mm
WME-RS 16 10 260	Data Sheet: WME-RS	Application: Filtering, Lighting, Motor Run Capacitance (µF): 16 Tolerance: ±10% Voltage Rating - AC: 260V Operating Temperature: -40 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Seamless Can Termination: 2-Tine, Quick Disconnect Dimension inches: 2.953" H x 1.595" D Dimension mm: 75.0mm x 40.5mm
WME-RS 16 3 260	Data Sheet: WME-RS	Application: Filtering, Lighting, Motor Run Capacitance (µF): 16 Tolerance: ±3% Voltage Rating - AC: 260V Operating Temperature: -40 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Seamless Can Termination: 2-Tine, Quick Disconnect Dimension inches: 2.953" H x 1.595" D Dimension mm: 75.0mm x 40.5mm
WME-RS 16 5 260	Data Sheet: WME-RS	Application: Filtering, Lighting, Motor Run Capacitance (µF): 16 Tolerance: ±5% Voltage Rating - AC: 260V Operating Temperature: -40 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Seamless Can Termination: 2-Tine, Quick Disconnect Dimension inches: 2.953" H x 1.595" D Dimension mm: 75.0mm x 40.5mm
WME-RS 16 6 260	Data Sheet: WME-RS	Application: Filtering, Lighting, Motor Run Capacitance (µF): 16 Tolerance: ±6% Voltage Rating - AC: 260V Operating Temperature: -40 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Seamless Can Termination: 2-Tine, Quick Disconnect Dimension inches: 2.953" H x 1.595" D Dimension mm: 75.0mm x 40.5mm
WME-RS 18 10 260	Data Sheet: WME-RS	Application: Filtering, Lighting, Motor Run Capacitance (µF): 18 Tolerance: ±10% Voltage Rating - AC: 260V Operating Temperature: -40 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Seamless Can Termination: 2-Tine, Quick Disconnect Dimension inches: 2.953" H x 1.595" D Dimension mm: 75.0mm x 40.5mm
WME-RS 18 3 260	Data Sheet: WME-RS	Application: Filtering, Lighting, Motor Run Capacitance (µF): 18 Tolerance: ±3% Voltage Rating - AC: 260V Operating Temperature: -40 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Seamless Can Termination: 2-Tine, Quick Disconnect Dimension inches: 2.953" H x 1.595" D Dimension mm: 75.0mm x 40.5mm
WME-RS 18 5 260	Data Sheet: WME-RS	Application: Filtering, Lighting, Motor Run Capacitance (µF): 18 Tolerance: ±5% Voltage Rating - AC: 260V Operating Temperature: -40 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Seamless Can Termination: 2-Tine, Quick Disconnect Dimension inches: 2.953" H x 1.595" D Dimension mm: 75.0mm x 40.5mm
