25uF

Product Code	Data Sheet	Attributes
WME-RS 25 10 450	Data Sheet: WME-RS	Application: Filtering, Lighting, Motor Run Capacitance (µF): 25 Tolerance: ±10% Voltage Rating - AC: 450V Operating Temperature: -40 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Seamless Can Termination: 2-Tine, Quick Disconnect Dimension inches: 4.921" H x 1.760" D Dimension mm: 125.0mm x 44.7mm
WME-RS 25 3 260	Data Sheet: WME-RS	Application: Filtering, Lighting, Motor Run Capacitance (µF): 25 Tolerance: ±3% Voltage Rating - AC: 260V Operating Temperature: -40 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Seamless Can Termination: 2-Tine, Quick Disconnect Dimension inches: 3.937" H x 1.595" D Dimension mm: 100.0mm x 40.5mm
WME-RS 25 3 400	Data Sheet: WME-RS	Application: Filtering, Lighting, Motor Run Capacitance (µF): 25 Tolerance: ±3% Voltage Rating - AC: 400V Operating Temperature: -40 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Seamless Can Termination: 2-Tine, Quick Disconnect Dimension inches: 3.937" H x 1.760" D Dimension mm: 100.0mm x 44.7mm
WME-RS 25 3 450	Data Sheet: WME-RS	Application: Filtering, Lighting, Motor Run Capacitance (µF): 25 Tolerance: ±3% Voltage Rating - AC: 450V Operating Temperature: -40 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Seamless Can Termination: 2-Tine, Quick Disconnect Dimension inches: 4.921" H x 1.760" D Dimension mm: 125.0mm x 44.7mm
WME-RS 25 5 260	Data Sheet: WME-RS	Application: Filtering, Lighting, Motor Run Capacitance (µF): 25 Tolerance: ±5% Voltage Rating - AC: 260V Operating Temperature: -40 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Seamless Can Termination: 2-Tine, Quick Disconnect Dimension inches: 3.937" H x 1.595" D Dimension mm: 100.0mm x 40.5mm
WME-RS 25 5 400	Data Sheet: WME-RS	Application: Filtering, Lighting, Motor Run Capacitance (µF): 25 Tolerance: ±5% Voltage Rating - AC: 400V Operating Temperature: -40 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Seamless Can Termination: 2-Tine, Quick Disconnect Dimension inches: 3.937" H x 1.760" D Dimension mm: 100.0mm x 44.7mm
WME-RS 25 5 450	Data Sheet: WME-RS	Application: Filtering, Lighting, Motor Run Capacitance (µF): 25 Tolerance: ±5% Voltage Rating - AC: 450V Operating Temperature: -40 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Seamless Can Termination: 2-Tine, Quick Disconnect Dimension inches: 4.921" H x 1.760" D Dimension mm: 125.0mm x 44.7mm
WME-RS 25 6 260	Data Sheet: WME-RS	Application: Filtering, Lighting, Motor Run Capacitance (µF): 25 Tolerance: ±6% Voltage Rating - AC: 260V Operating Temperature: -40 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Seamless Can Termination: 2-Tine, Quick Disconnect Dimension inches: 3.937" H x 1.595" D Dimension mm: 100.0mm x 40.5mm
WME-RS 25 6 400	Data Sheet: WME-RS	Application: Filtering, Lighting, Motor Run Capacitance (µF): 25 Tolerance: ±6% Voltage Rating - AC: 400V Operating Temperature: -40 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Seamless Can Termination: 2-Tine, Quick Disconnect Dimension inches: 3.937" H x 1.760" D Dimension mm: 100.0mm x 44.7mm
WME-RS 25 6 450	Data Sheet: WME-RS	Application: Filtering, Lighting, Motor Run Capacitance (µF): 25 Tolerance: ±6% Voltage Rating - AC: 450V Operating Temperature: -40 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Seamless Can Termination: 2-Tine, Quick Disconnect Dimension inches: 4.921" H x 1.760" D Dimension mm: 125.0mm x 44.7mm
X300 25 10 200	Data Sheet: X300	Application: Power Supply Capacitance (µF): 25 Tolerance: ±10% Voltage Rating - DC: 200V Voltage Rating - AC: Operating Temperature: -55 °C to +85 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Self-Encased w/ PP or PE Termination: Solid Wire Dimension inches: 1.870" H x 1.495" D Dimension mm: 47.5mm x 38.0mm
X300 25 20 200	Data Sheet: X300	Application: Power Supply Capacitance (µF): 25 Tolerance: ±20% Voltage Rating - DC: 200V Voltage Rating - AC: Operating Temperature: -55 °C to +85 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Self-Encased w/ PP or PE Termination: Solid Wire Dimension inches: 1.870" H x 1.495" D Dimension mm: 47.5mm x 38.0mm
