25µF

Product Code	Data Sheet	Attributes
X300 25 5 200	Data Sheet: X300	Application: Power Supply Capacitance (µF): 25 Tolerance: ±5% Voltage Rating - DC: 200V Voltage Rating - AC: Operating Temperature: -55 °C to +85 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Self-Encased w/ PP or PE Termination: Solid Wire Dimension inches: 1.870" H x 1.495" D Dimension mm: 47.5mm x 38.0mm
X347 25 10 100 / 250	Data Sheet: X347	Application: DC Filter, Sample Hold Capacitance (µF): 25 Tolerance: ±10% Voltage Rating - AC: 100V / 250V Operating Temperature: -25 °C to +85 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene – Metallized Case: Preformed Case with Epoxy Fill Termination: AMP187, AMP250, SOLID WIRE, DIN SOLDER TABS, AND STRANDED WIRE Dimension inches: 1.142" T x 1.614" H x 2.283" W Dimension mm: 29.0mm x 41.0mm x 58.0mm
X347 25 5 100 / 250	Data Sheet: X347	Application: DC Filter, Sample Hold Capacitance (µF): 25 Tolerance: ±5% Voltage Rating - AC: 100V / 250V Operating Temperature: -25 °C to +85 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene – Metallized Case: Preformed Case with Epoxy Fill Termination: AMP187, AMP250, SOLID WIRE, DIN SOLDER TABS, AND STRANDED WIRE Dimension inches: 1.142" T x 1.614" H x 2.283" W Dimension mm: 29.0mm x 41.0mm x 58.0mm
X349 25 10 250	Data Sheet: X349	Application: DC Filter, Sample Hold Capacitance (µF): 25 Tolerance: ±10% Voltage Rating - AC: 250V Operating Temperature: -25 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene – Metallized Case: Preformed Case with Epoxy Fill Termination: AMP187, AMP250, SOLID WIRE, DIN SOLDER TABS, AND STRANDED WIRE Dimension inches: 1.378" T x 1.969" H x 2.283" W Dimension mm: 35.0mm x 50.0mm x 58.0mm
X349 25 5 250	Data Sheet: X349	Application: DC Filter, Sample Hold Capacitance (µF): 25 Tolerance: ±5% Voltage Rating - AC: 250V Operating Temperature: -25 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene – Metallized Case: Preformed Case with Epoxy Fill Termination: AMP187, AMP250, SOLID WIRE, DIN SOLDER TABS, AND STRANDED WIRE Dimension inches: 1.378" T x 1.969" H x 2.283" W Dimension mm: 35.0mm x 50.0mm x 58.0mm
X386D 25 10 370	Data Sheet: X386D	Application: Filtering, Lighting, Motor Run Capacitance (µF): 25 Tolerance: ±10% Voltage Rating - AC: 370V Operating Temperature: -40 °C to +70 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Oil Filled, Seamless Can Termination: 4-Tine, Quick Disconnect Dimension inches: 4.250" H x 2.000" D Dimension mm: 108.0mm x 50.8mm CAP (µF) - Secondary: 5
X386D 25 10 440	Data Sheet: X386D	Application: Filtering, Lighting, Motor Run Capacitance (µF): 25 Tolerance: ±10% Voltage Rating - AC: 440V Operating Temperature: -40 °C to +70 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Oil Filled, Seamless Can Termination: 4-Tine, Quick Disconnect Dimension inches: 4.250" H x 2.500" D Dimension mm: 108.0mm x 63.5mm CAP (µF) - Secondary: 5
X386D 25 3 370	Data Sheet: X386D	Application: Filtering, Lighting, Motor Run Capacitance (µF): 25 Tolerance: ±3% Voltage Rating - AC: 370V Operating Temperature: -40 °C to +70 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Oil Filled, Seamless Can Termination: 4-Tine, Quick Disconnect Dimension inches: 4.250" H x 2.000" D Dimension mm: 108.0mm x 50.8mm CAP (µF) - Secondary: 5
X386D 25 3 440	Data Sheet: X386D	Application: Filtering, Lighting, Motor Run Capacitance (µF): 25 Tolerance: ±3% Voltage Rating - AC: 440V Operating Temperature: -40 °C to +70 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Oil Filled, Seamless Can Termination: 4-Tine, Quick Disconnect Dimension inches: 4.250" H x 2.500" D Dimension mm: 108.0mm x 63.5mm CAP (µF) - Secondary: 5
X386D 25 5 370	Data Sheet: X386D	Application: Filtering, Lighting, Motor Run Capacitance (µF): 25 Tolerance: ±5% Voltage Rating - AC: 370V Operating Temperature: -40 °C to +70 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Oil Filled, Seamless Can Termination: 4-Tine, Quick Disconnect Dimension inches: 4.250" H x 2.000" D Dimension mm: 108.0mm x 50.8mm CAP (µF) - Secondary: 5
X386D 25 5 440	Data Sheet: X386D	Application: Filtering, Lighting, Motor Run Capacitance (µF): 25 Tolerance: ±5% Voltage Rating - AC: 440V Operating Temperature: -40 °C to +70 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Oil Filled, Seamless Can Termination: 4-Tine, Quick Disconnect Dimension inches: 4.250" H x 2.500" D Dimension mm: 108.0mm x 63.5mm CAP (µF) - Secondary: 5
X386D 25 6 370	Data Sheet: X386D	Application: Filtering, Lighting, Motor Run Capacitance (µF): 25 Tolerance: ±6% Voltage Rating - AC: 370V Operating Temperature: -40 °C to +70 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Oil Filled, Seamless Can Termination: 4-Tine, Quick Disconnect Dimension inches: 4.250" H x 2.000" D Dimension mm: 108.0mm x 50.8mm CAP (µF) - Secondary: 5
