25µF

Product Code	Data Sheet	Attributes
HCG 25 +10 to -5 600	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 25 Tolerance: +10% to -5% Voltage Rating - AC: 600V Operating Temperature: -40 °C to +70 °C ESR: 6.6 mOhms Vsurge: 1290 ISurge: 1.1 IPeak: 0.1 Irms (Arms): 6 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Gel Termination: Threaded Stud/Insert Dimension inches: 4.410" H x 2.953" D Dimension mm: 112.0mm x 75.0mm ESR kHz: 60Hz
HCG 25 10 600	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 25 Tolerance: ±10% Voltage Rating - AC: 600V Operating Temperature: -40 °C to +70 °C ESR: 6.6 mOhms Vsurge: 1290 ISurge: 1.1 IPeak: 0.1 Irms (Arms): 6 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Gel Termination: Threaded Stud/Insert Dimension inches: 4.410" H x 2.953" D Dimension mm: 112.0mm x 75.0mm ESR kHz: 60Hz
HCG 25 3 600	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 25 Tolerance: ±3% Voltage Rating - AC: 600V Operating Temperature: -40 °C to +70 °C ESR: 6.6 mOhms Vsurge: 1290 ISurge: 1.1 IPeak: 0.1 Irms (Arms): 6 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Gel Termination: Threaded Stud/Insert Dimension inches: 4.410" H x 2.953" D Dimension mm: 112.0mm x 75.0mm ESR kHz: 60Hz
HCG 25 5 600	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 25 Tolerance: ±5% Voltage Rating - AC: 600V Operating Temperature: -40 °C to +70 °C ESR: 6.6 mOhms Vsurge: 1290 ISurge: 1.1 IPeak: 0.1 Irms (Arms): 6 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Gel Termination: Threaded Stud/Insert Dimension inches: 4.410" H x 2.953" D Dimension mm: 112.0mm x 75.0mm ESR kHz: 60Hz
HCO 25 +10 to -5 600	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 25 Tolerance: +10% to -5% Voltage Rating - AC: 600V Operating Temperature: -40 °C to +70 °C ESR: 6.6 mOhms Vsurge: 1290 ISurge: 1.1 IPeak: 0.1 Irms (Arms): 6 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 4.410" H x 2.953" D Dimension mm: 112.0mm x 75.0mm ESR kHz: 60Hz
HCO 25 10 600	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 25 Tolerance: ±10% Voltage Rating - AC: 600V Operating Temperature: -40 °C to +70 °C ESR: 6.6 mOhms Vsurge: 1290 ISurge: 1.1 IPeak: 0.1 Irms (Arms): 6 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 4.410" H x 2.953" D Dimension mm: 112.0mm x 75.0mm ESR kHz: 60Hz
HCO 25 3 600	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 25 Tolerance: ±3% Voltage Rating - AC: 600V Operating Temperature: -40 °C to +70 °C ESR: 6.6 mOhms Vsurge: 1290 ISurge: 1.1 IPeak: 0.1 Irms (Arms): 6 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 4.410" H x 2.953" D Dimension mm: 112.0mm x 75.0mm ESR kHz: 60Hz
HCO 25 5 600	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 25 Tolerance: ±5% Voltage Rating - AC: 600V Operating Temperature: -40 °C to +70 °C ESR: 6.6 mOhms Vsurge: 1290 ISurge: 1.1 IPeak: 0.1 Irms (Arms): 6 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 4.410" H x 2.953" D Dimension mm: 112.0mm x 75.0mm ESR kHz: 60Hz
PXK (58.0 x 35.0 x 50.0) 25 10 305	Data Sheet: PXK	Application: Class X-2 EMI Noise Suppression Capacitance (µF): 25 Tolerance: ±10% Voltage Rating - DC: 305V Operating Temperature: -40 °C to +110 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Preformed Case with Epoxy Fill Dimension mm: 35.0mm T x 50.0mm H x 58.0mm W
PXK (58.0 x 35.0 x 60.0) 25 10 305	Data Sheet: PXK	Application: Class X-2 EMI Noise Suppression Capacitance (µF): 25 Tolerance: ±10% Voltage Rating - DC: 305V Operating Temperature: -40 °C to +110 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Preformed Case with Epoxy Fill Dimension mm: 35.0mm T x 60.0mm H x 58.0mm W
WME-RS 25 10 260	Data Sheet: WME-RS	Application: Filtering, Lighting, Motor Run Capacitance (µF): 25 Tolerance: ±10% Voltage Rating - AC: 260V Operating Temperature: -40 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Seamless Can Termination: 2-Tine, Quick Disconnect Dimension inches: 3.937" H x 1.595" D Dimension mm: 100.0mm x 40.5mm
WME-RS 25 10 400	Data Sheet: WME-RS	Application: Filtering, Lighting, Motor Run Capacitance (µF): 25 Tolerance: ±10% Voltage Rating - AC: 400V Operating Temperature: -40 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Seamless Can Termination: 2-Tine, Quick Disconnect Dimension inches: 3.937" H x 1.760" D Dimension mm: 100.0mm x 44.7mm
