1600V

Product Code	Data Sheet	Attributes
BLS 0.0033 10 650	Data Sheet: BLS	Application: Electronic Lighting, High Frequency, High Voltage, Snubber and SCR commutating circuits, Switching spikes suppression in SMPS Capacitance (µF): 0.0033 Tolerance: ±10% Voltage Rating - DC: 1600V Voltage Rating - AC: 650V Operating Temperature: -40 °C to +105 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound double-sided metallized polyester film electrodes Dielectric Material: Polypropylene - Double Metallized Case: Retardant Case Dimension inches: Dimension mm: 5.0mm T x 11.0mm H x 18.0mm L
BLS 0.0033 20 650	Data Sheet: BLS	Application: Electronic Lighting, High Frequency, High Voltage, Snubber and SCR commutating circuits, Switching spikes suppression in SMPS Capacitance (µF): 0.0033 Tolerance: ±20% Voltage Rating - DC: 1600V Voltage Rating - AC: 650V Operating Temperature: -40 °C to +105 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound double-sided metallized polyester film electrodes Dielectric Material: Polypropylene - Double Metallized Case: Retardant Case Dimension inches: Dimension mm: 5.0mm T x 11.0mm H x 18.0mm L
BLS 0.0033 5 650	Data Sheet: BLS	Application: Electronic Lighting, High Frequency, High Voltage, Snubber and SCR commutating circuits, Switching spikes suppression in SMPS Capacitance (µF): 0.0033 Tolerance: ±5% Voltage Rating - DC: 1600V Voltage Rating - AC: 650V Operating Temperature: -40 °C to +105 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound double-sided metallized polyester film electrodes Dielectric Material: Polypropylene - Double Metallized Case: Retardant Case Dimension inches: Dimension mm: 5.0mm T x 11.0mm H x 18.0mm L
BLS 0.0047 10 650	Data Sheet: BLS	Application: Electronic Lighting, High Frequency, High Voltage, Snubber and SCR commutating circuits, Switching spikes suppression in SMPS Capacitance (µF): 0.0047 Tolerance: ±10% Voltage Rating - DC: 1600V Voltage Rating - AC: 650V Operating Temperature: -40 °C to +105 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound double-sided metallized polyester film electrodes Dielectric Material: Polypropylene - Double Metallized Case: Retardant Case Dimension inches: Dimension mm: 6.0mm T x 12.0mm H x 18.0mm L
BLS 0.0047 20 650	Data Sheet: BLS	Application: Electronic Lighting, High Frequency, High Voltage, Snubber and SCR commutating circuits, Switching spikes suppression in SMPS Capacitance (µF): 0.0047 Tolerance: ±20% Voltage Rating - DC: 1600V Voltage Rating - AC: 650V Operating Temperature: -40 °C to +105 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound double-sided metallized polyester film electrodes Dielectric Material: Polypropylene - Double Metallized Case: Retardant Case Dimension inches: Dimension mm: 6.0mm T x 12.0mm H x 18.0mm L
BLS 0.0047 5 650	Data Sheet: BLS	Application: Electronic Lighting, High Frequency, High Voltage, Snubber and SCR commutating circuits, Switching spikes suppression in SMPS Capacitance (µF): 0.0047 Tolerance: ±5% Voltage Rating - DC: 1600V Voltage Rating - AC: 650V Operating Temperature: -40 °C to +105 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound double-sided metallized polyester film electrodes Dielectric Material: Polypropylene - Double Metallized Case: Retardant Case Dimension inches: Dimension mm: 6.0mm T x 12.0mm H x 18.0mm L
BLS 0.0056 10 650	Data Sheet: BLS	Application: Electronic Lighting, High Frequency, High Voltage, Snubber and SCR commutating circuits, Switching spikes suppression in SMPS Capacitance (µF): 0.0056 Tolerance: ±10% Voltage Rating - DC: 1600V Voltage Rating - AC: 650V Operating Temperature: -40 °C to +105 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound double-sided metallized polyester film electrodes Dielectric Material: Polypropylene - Double Metallized Case: Retardant Case Dimension inches: Dimension mm: 6.0mm T x 12.0mm H x 18.0mm L
BLS 0.0056 20 650	Data Sheet: BLS	Application: Electronic Lighting, High Frequency, High Voltage, Snubber and SCR commutating circuits, Switching spikes suppression in SMPS Capacitance (µF): 0.0056 Tolerance: ±20% Voltage Rating - DC: 1600V Voltage Rating - AC: 650V Operating Temperature: -40 °C to +105 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound double-sided metallized polyester film electrodes Dielectric Material: Polypropylene - Double Metallized Case: Retardant Case Dimension inches: Dimension mm: 6.0mm T x 12.0mm H x 18.0mm L
BLS 0.0056 5 650	Data Sheet: BLS	Application: Electronic Lighting, High Frequency, High Voltage, Snubber and SCR commutating circuits, Switching spikes suppression in SMPS Capacitance (µF): 0.0056 Tolerance: ±5% Voltage Rating - DC: 1600V Voltage Rating - AC: 650V Operating Temperature: -40 °C to +105 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound double-sided metallized polyester film electrodes Dielectric Material: Polypropylene - Double Metallized Case: Retardant Case Dimension inches: Dimension mm: 6.0mm T x 12.0mm H x 18.0mm L
BLS 0.0068 10 650	Data Sheet: BLS	Application: Electronic Lighting, High Frequency, High Voltage, Snubber and SCR commutating circuits, Switching spikes suppression in SMPS Capacitance (µF): 0.0068 Tolerance: ±10% Voltage Rating - DC: 1600V Voltage Rating - AC: 650V Operating Temperature: -40 °C to +105 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound double-sided metallized polyester film electrodes Dielectric Material: Polypropylene - Double Metallized Case: Retardant Case Dimension inches: Dimension mm: 7.5mm T x 13.5mm H x 18.0mm L
BLS 0.0068 20 650	Data Sheet: BLS	Application: Electronic Lighting, High Frequency, High Voltage, Snubber and SCR commutating circuits, Switching spikes suppression in SMPS Capacitance (µF): 0.0068 Tolerance: ±20% Voltage Rating - DC: 1600V Voltage Rating - AC: 650V Operating Temperature: -40 °C to +105 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound double-sided metallized polyester film electrodes Dielectric Material: Polypropylene - Double Metallized Case: Retardant Case Dimension inches: Dimension mm: 7.5mm T x 13.5mm H x 18.0mm L
BLS 0.0068 5 650	Data Sheet: BLS	Application: Electronic Lighting, High Frequency, High Voltage, Snubber and SCR commutating circuits, Switching spikes suppression in SMPS Capacitance (µF): 0.0068 Tolerance: ±5% Voltage Rating - DC: 1600V Voltage Rating - AC: 650V Operating Temperature: -40 °C to +105 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound double-sided metallized polyester film electrodes Dielectric Material: Polypropylene - Double Metallized Case: Retardant Case Dimension inches: Dimension mm: 7.5mm T x 13.5mm H x 18.0mm L
