12mFD

Product Code	Data Sheet	Attributes
WME-RS 12 5 260	Data Sheet: WME-RS	Application: Filtering, Lighting, Motor Run Capacitance (µF): 12 Tolerance: ±5% Voltage Rating - AC: 260V Operating Temperature: -40 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Seamless Can Termination: 2-Tine, Quick Disconnect Dimension inches: 2.953" H x 1.595" D Dimension mm: 75.0mm x 40.5mm
WME-RS 12 5 400	Data Sheet: WME-RS	Application: Filtering, Lighting, Motor Run Capacitance (µF): 12 Tolerance: ±5% Voltage Rating - AC: 400V Operating Temperature: -40 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Seamless Can Termination: 2-Tine, Quick Disconnect Dimension inches: 3.937" H x 1.595" D Dimension mm: 100.0mm x 40.5mm
WME-RS 12 5 450	Data Sheet: WME-RS	Application: Filtering, Lighting, Motor Run Capacitance (µF): 12 Tolerance: ±5% Voltage Rating - AC: 450V Operating Temperature: -40 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Seamless Can Termination: 2-Tine, Quick Disconnect Dimension inches: 3.937" H x 1.595" D Dimension mm: 100.0mm x 40.5mm
WME-RS 12 6 260	Data Sheet: WME-RS	Application: Filtering, Lighting, Motor Run Capacitance (µF): 12 Tolerance: ±6% Voltage Rating - AC: 260V Operating Temperature: -40 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Seamless Can Termination: 2-Tine, Quick Disconnect Dimension inches: 2.953" H x 1.595" D Dimension mm: 75.0mm x 40.5mm
WME-RS 12 6 400	Data Sheet: WME-RS	Application: Filtering, Lighting, Motor Run Capacitance (µF): 12 Tolerance: ±6% Voltage Rating - AC: 400V Operating Temperature: -40 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Seamless Can Termination: 2-Tine, Quick Disconnect Dimension inches: 3.937" H x 1.595" D Dimension mm: 100.0mm x 40.5mm
WME-RS 12 6 450	Data Sheet: WME-RS	Application: Filtering, Lighting, Motor Run Capacitance (µF): 12 Tolerance: ±6% Voltage Rating - AC: 450V Operating Temperature: -40 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Seamless Can Termination: 2-Tine, Quick Disconnect Dimension inches: 3.937" H x 1.595" D Dimension mm: 100.0mm x 40.5mm
X300 12 10 200	Data Sheet: X300	Application: Power Supply Capacitance (µF): 12 Tolerance: ±10% Voltage Rating - DC: 200V Voltage Rating - AC: Operating Temperature: -55 °C to +85 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Self-Encased w/ PP or PE Termination: Solid Wire Dimension inches: 1.574" H x 1.166" D Dimension mm: 40.0mm x 29.6mm
X300 12 20 200	Data Sheet: X300	Application: Power Supply Capacitance (µF): 12 Tolerance: ±20% Voltage Rating - DC: 200V Voltage Rating - AC: Operating Temperature: -55 °C to +85 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Self-Encased w/ PP or PE Termination: Solid Wire Dimension inches: 1.574" H x 1.166" D Dimension mm: 40.0mm x 29.6mm
X300 12 5 200	Data Sheet: X300	Application: Power Supply Capacitance (µF): 12 Tolerance: ±5% Voltage Rating - DC: 200V Voltage Rating - AC: Operating Temperature: -55 °C to +85 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Self-Encased w/ PP or PE Termination: Solid Wire Dimension inches: 1.574" H x 1.166" D Dimension mm: 40.0mm x 29.6mm
X345 12 10 220	Data Sheet: X345	Application: DC Filter, Sample Hold Capacitance (µF): 12 Tolerance: ±10% Voltage Rating - AC: 220V Operating Temperature: -25 °C to +75 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound combination of metallized polypropylene and polyester Dielectric Material: Polypropylene – Metallized and Polyester Case: Preformed Case with Epoxy Fill Termination: AMP187, AMP250, SOLID WIRE, DIN SOLDER TABS, AND STRANDED WIRE Dimension inches: 0.827" T x 1.220" H x 2.283" W Dimension mm: 21.0mm x 31.0mm x 58.0mm
X345 12 5 220	Data Sheet: X345	Application: DC Filter, Sample Hold Capacitance (µF): 12 Tolerance: ±5% Voltage Rating - AC: 220V Operating Temperature: -25 °C to +75 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound combination of metallized polypropylene and polyester Dielectric Material: Polypropylene – Metallized and Polyester Case: Preformed Case with Epoxy Fill Termination: AMP187, AMP250, SOLID WIRE, DIN SOLDER TABS, AND STRANDED WIRE Dimension inches: 0.827" T x 1.220" H x 2.283" W Dimension mm: 21.0mm x 31.0mm x 58.0mm
X347 12 10 100 / 250	Data Sheet: X347	Application: DC Filter, Sample Hold Capacitance (µF): 12 Tolerance: ±10% Voltage Rating - AC: 100V / 250V Operating Temperature: -25 °C to +85 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene – Metallized Case: Preformed Case with Epoxy Fill Termination: AMP187, AMP250, SOLID WIRE, DIN SOLDER TABS, AND STRANDED WIRE Dimension inches: 0.827" T x 1.220" H x 2.283" W Dimension mm: 21.0mm x 31.0mm x 58.0mm
