+10% to -5% tolerance

Product Code	Data Sheet	Attributes
HCO 210 +10 to -5 600	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 210 Tolerance: +10% to -5% Voltage Rating - AC: 600V Operating Temperature: -40 °C to +70 °C ESR: 1.8 mOhms Vsurge: 1290 ISurge: 5 IPeak: 1 Irms (Arms): 48 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 8.000" H x 4.567" D Dimension mm: 203.0mm x 116.0mm ESR kHz: 60Hz
HCO 25 +10 to -5 600	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 25 Tolerance: +10% to -5% Voltage Rating - AC: 600V Operating Temperature: -40 °C to +70 °C ESR: 6.6 mOhms Vsurge: 1290 ISurge: 1.1 IPeak: 0.1 Irms (Arms): 6 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 4.410" H x 2.953" D Dimension mm: 112.0mm x 75.0mm ESR kHz: 60Hz
HCO 260 +10 to -5 400	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 260 Tolerance: +10% to -5% Voltage Rating - AC: 400V Operating Temperature: -40 °C to +70 °C ESR: 3.8 mOhms Vsurge: 860 ISurge: 5 IPeak: 0.8 Irms (Arms): 40 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 7.000" H x 3.937" D Dimension mm: 178.0mm x 100.0mm ESR kHz: 60Hz
HCO 260 +10 to -5 690	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 260 Tolerance: +10% to -5% Voltage Rating - AC: 690V Operating Temperature: -40 °C to +70 °C ESR: 1.8 mOhms Vsurge: 1484 ISurge: 5 IPeak: 1.4 Irms (Arms): 68 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 9.650" H x 5.354" D Dimension mm: 245.0mm x 136.0mm ESR kHz: 60Hz
HCO 265 +10 to -5 525	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 265 Tolerance: +10% to -5% Voltage Rating - AC: 525V Operating Temperature: -40 °C to +70 °C ESR: 4 mOhms Vsurge: 1129 ISurge: 4.5 IPeak: 1 Irms (Arms): 52 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 8.000" H x 4.567" D Dimension mm: 203.0mm x 116.0mm ESR kHz: 60Hz
HCO 300 +10 to -5 600	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 300 Tolerance: +10% to -5% Voltage Rating - AC: 600V Operating Temperature: -40 °C to +70 °C ESR: 1.8 mOhms Vsurge: 1290 ISurge: 5 IPeak: 1.4 Irms (Arms): 68 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 9.650" H x 5.354" D Dimension mm: 245.0mm x 136.0mm ESR kHz: 60Hz
HCO 325 +10 to -5 250	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 325 Tolerance: +10% to -5% Voltage Rating - AC: 250V Operating Temperature: -40 °C to +70 °C ESR: 2.9 mOhms Vsurge: 538 ISurge: 5 IPeak: 0.6 Irms (Arms): 31 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 6.000" H x 3.346" D Dimension mm: 152.0mm x 85.0mm ESR kHz: 60Hz
HCO 340 +10 to -5 480	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 340 Tolerance: +10% to -5% Voltage Rating - AC: 480V Operating Temperature: -40 °C to +70 °C ESR: 3.3 mOhms Vsurge: 1023 ISurge: 5 IPeak: 1.2 Irms (Arms): 62 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 8.000" H x 4.567" D Dimension mm: 203.0mm x 116.0mm ESR kHz: 60Hz
HCO 340 +10 to -5 525	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 340 Tolerance: +10% to -5% Voltage Rating - AC: 525V Operating Temperature: -40 °C to +70 °C ESR: 4.1 mOhms Vsurge: 1129 ISurge: 4.5 IPeak: 1.4 Irms (Arms): 68 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 9.650" H x 5.354" D Dimension mm: 245.0mm x 136.0mm ESR kHz: 60Hz
HCO 38 +10 to -5 525	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 38 Tolerance: +10% to -5% Voltage Rating - AC: 525V Operating Temperature: -40 °C to +70 °C ESR: 12 mOhms Vsurge: 1129 ISurge: 1.6 IPeak: 0.2 Irms (Arms): 7.6 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 4.250" H x 2.953" D Dimension mm: 108.0mm x 75.0mm ESR kHz: 60Hz
HCO 40 +10 to -5 690	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 40 Tolerance: +10% to -5% Voltage Rating - AC: 690V Operating Temperature: -40 °C to +70 °C ESR: 5.3 mOhms Vsurge: 1484 ISurge: 1.4 IPeak: 0.2 Irms (Arms): 11 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 6.000" H x 3.346" D Dimension mm: 152.0mm x 85.0mm ESR kHz: 60Hz
HCO 450 +10 to -5 400	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 450 Tolerance: +10% to -5% Voltage Rating - AC: 400V Operating Temperature: -40 °C to +70 °C ESR: 2.7 mOhms Vsurge: 860 ISurge: 5 IPeak: 1.4 Irms (Arms): 70 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 8.000" H x 4.567" D Dimension mm: 203.0mm x 116.0mm ESR kHz: 60Hz
