1.5µF

Product Code	Data Sheet	Attributes
X663F 1.5 10 600	Data Sheet: X663F	Application: Power Supply, Pulse Current Capacitance (µF): 1.5 Tolerance: ±10% Voltage Rating - DC: 600V Operating Temperature: -55 °C to +85 °C IPeak: 14.3 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polyester film Dielectric Material: Polyester – Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.922" T x 1.844" H x 1.438" L Dimension mm: 23.4mm x 46.8mm x 36.5mm
X663F 1.5 20 100 / 200	Data Sheet: X663F	Application: Power Supply, Pulse Current Capacitance (µF): 1.5 Tolerance: ±20% Voltage Rating - DC: 100V / 200V Operating Temperature: -55 °C to +85 °C IPeak: 7.5 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polyester film Dielectric Material: Polyester – Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.453" T x 1.344" H x 0.641" L Dimension mm: 11.5mm x 34.1mm x 16.3mm
X663F 1.5 20 400	Data Sheet: X663F	Application: Power Supply, Pulse Current Capacitance (µF): 1.5 Tolerance: ±20% Voltage Rating - DC: 400V Operating Temperature: -55 °C to +85 °C IPeak: 9.8 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polyester film Dielectric Material: Polyester – Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.625" T x 1.844" H x 1.188" L Dimension mm: 15.9mm x 46.8mm x 30.2mm
X663F 1.5 20 50	Data Sheet: X663F	Application: Power Supply, Pulse Current Capacitance (µF): 1.5 Tolerance: ±20% Voltage Rating - DC: 50V Operating Temperature: -55 °C to +85 °C IPeak: 6 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polyester film Dielectric Material: Polyester – Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.328" T x 1.032" H x 0.531" L Dimension mm: 8.3mm x 26.2mm x 13.5mm
X663F 1.5 20 600	Data Sheet: X663F	Application: Power Supply, Pulse Current Capacitance (µF): 1.5 Tolerance: ±20% Voltage Rating - DC: 600V Operating Temperature: -55 °C to +85 °C IPeak: 14.3 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polyester film Dielectric Material: Polyester – Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.922" T x 1.844" H x 1.438" L Dimension mm: 23.4mm x 46.8mm x 36.5mm
X663F 1.5 5 100 / 200	Data Sheet: X663F	Application: Power Supply, Pulse Current Capacitance (µF): 1.5 Tolerance: ±5% Voltage Rating - DC: 100V / 200V Operating Temperature: -55 °C to +85 °C IPeak: 7.5 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polyester film Dielectric Material: Polyester – Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.453" T x 1.344" H x 0.641" L Dimension mm: 11.5mm x 34.1mm x 16.3mm
X663F 1.5 5 400	Data Sheet: X663F	Application: Power Supply, Pulse Current Capacitance (µF): 1.5 Tolerance: ±5% Voltage Rating - DC: 400V Operating Temperature: -55 °C to +85 °C IPeak: 9.8 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polyester film Dielectric Material: Polyester – Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.625" T x 1.844" H x 1.188" L Dimension mm: 15.9mm x 46.8mm x 30.2mm
X663F 1.5 5 50	Data Sheet: X663F	Application: Power Supply, Pulse Current Capacitance (µF): 1.5 Tolerance: ±5% Voltage Rating - DC: 50V Operating Temperature: -55 °C to +85 °C IPeak: 6 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polyester film Dielectric Material: Polyester – Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.328" T x 1.032" H x 0.531" L Dimension mm: 8.3mm x 26.2mm x 13.5mm
X663F 1.5 5 600	Data Sheet: X663F	Application: Power Supply, Pulse Current Capacitance (µF): 1.5 Tolerance: ±5% Voltage Rating - DC: 600V Operating Temperature: -55 °C to +85 °C IPeak: 14.3 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polyester film Dielectric Material: Polyester – Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.922" T x 1.844" H x 1.438" L Dimension mm: 23.4mm x 46.8mm x 36.5mm
X665 1.5 10 100	Data Sheet: X665	Application: Power Supply, Pulse Current Capacitance (µF): 1.5 Tolerance: ±10% Voltage Rating - DC: 100V Operating Temperature: -55 °C to +85 °C IPeak: 7.5 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polyester film Dielectric Material: Polyester – Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.700" H x 0.360" D Dimension mm: 17.8mm x 9.1mm
X665 1.5 10 250	Data Sheet: X665	Application: Power Supply, Pulse Current Capacitance (µF): 1.5 Tolerance: ±10% Voltage Rating - DC: 250V Operating Temperature: -55 °C to +85 °C IPeak: 9 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polyester film Dielectric Material: Polyester – Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.000" H x 0.510" D Dimension mm: 25.4mm x 13.0mm
X665 1.5 10 400	Data Sheet: X665	Application: Power Supply, Pulse Current Capacitance (µF): 1.5 Tolerance: ±10% Voltage Rating - DC: 400V Operating Temperature: -55 °C to +85 °C IPeak: 7.5 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polyester film Dielectric Material: Polyester – Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.500" H x 0.640" D Dimension mm: 38.1mm x 16.3mm
