1µF

Product Code	Image	Data Sheet	Attributes
X347 1 5 100 / 250		Data Sheet: X347	Application: DC Filter, Sample Hold Capacitance (µF): 1 Tolerance: ±5% Voltage Rating - AC: 100V / 250V Operating Temperature: -25 °C to +85 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene – Metallized Case: Preformed Case with Epoxy Fill Termination: AMP187, AMP250, SOLID WIRE, DIN SOLDER TABS, AND STRANDED WIRE Dimension inches: 0.433" T x 0.807" H x 1.063" W Dimension mm: 11.0mm x 20.5mm x 27.0mm
X347 1 5 350		Data Sheet: X347	Application: DC Filter, Sample Hold Capacitance (µF): 1 Tolerance: ±5% Voltage Rating - AC: 350V Operating Temperature: -25 °C to +85 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene – Metallized Case: Preformed Case with Epoxy Fill Termination: AMP187, AMP250, SOLID WIRE, DIN SOLDER TABS, AND STRANDED WIRE Dimension inches: 0.571" T x 0.925" H x 1.220" W Dimension mm: 14.5mm x 23.5mm x 31.0mm
X347 1 5 400		Data Sheet: X347	Application: DC Filter, Sample Hold Capacitance (µF): 1 Tolerance: ±5% Voltage Rating - AC: 400V Operating Temperature: -25 °C to +85 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene – Metallized Case: Preformed Case with Epoxy Fill Termination: AMP187, AMP250, SOLID WIRE, DIN SOLDER TABS, AND STRANDED WIRE Dimension inches: 0.669" T x 1.063" H x 1.220" W Dimension mm: 17.0mm x 27.0mm x 31.0mm
X347 1 5 450		Data Sheet: X347	Application: DC Filter, Sample Hold Capacitance (µF): 1 Tolerance: ±5% Voltage Rating - AC: 450V Operating Temperature: -25 °C to +85 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene – Metallized Case: Preformed Case with Epoxy Fill Termination: AMP187, AMP250, SOLID WIRE, DIN SOLDER TABS, AND STRANDED WIRE Dimension inches: 0.709" T x 1.063" H x 1.457" W Dimension mm: 18.0mm x 27.0mm x 37.0mm
X349 1 10 350		Data Sheet: X349	Application: DC Filter, Sample Hold Capacitance (µF): 1 Tolerance: ±10% Voltage Rating - AC: 350V Operating Temperature: -25 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene – Metallized Case: Preformed Case with Epoxy Fill Termination: AMP187, AMP250, SOLID WIRE, DIN SOLDER TABS, AND STRANDED WIRE Dimension inches: 0.571" T x 0.925" H x 1.220" W Dimension mm: 14.5mm x 23.5mm x 31.0mm
X349 1 10 400		Data Sheet: X349	Application: DC Filter, Sample Hold Capacitance (µF): 1 Tolerance: ±10% Voltage Rating - AC: 400V Operating Temperature: -25 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene – Metallized Case: Preformed Case with Epoxy Fill Termination: AMP187, AMP250, SOLID WIRE, DIN SOLDER TABS, AND STRANDED WIRE Dimension inches: 0.669" T x 1.063" H x 1.220" W Dimension mm: 17.0mm x 27.0mm x 31.0mm
X349 1 10 450		Data Sheet: X349	Application: DC Filter, Sample Hold Capacitance (µF): 1 Tolerance: ±10% Voltage Rating - AC: 450V Operating Temperature: -25 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene – Metallized Case: Preformed Case with Epoxy Fill Termination: AMP187, AMP250, SOLID WIRE, DIN SOLDER TABS, AND STRANDED WIRE Dimension inches: 0.709" T x 1.063" H x 1.457" W Dimension mm: 18.0mm x 27.0mm x 37.0mm
X349 1 5 350		Data Sheet: X349	Application: DC Filter, Sample Hold Capacitance (µF): 1 Tolerance: ±5% Voltage Rating - AC: 350V Operating Temperature: -25 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene – Metallized Case: Preformed Case with Epoxy Fill Termination: AMP187, AMP250, SOLID WIRE, DIN SOLDER TABS, AND STRANDED WIRE Dimension inches: 0.571" T x 0.925" H x 1.220" W Dimension mm: 14.5mm x 23.5mm x 31.0mm
X349 1 5 400		Data Sheet: X349	Application: DC Filter, Sample Hold Capacitance (µF): 1 Tolerance: ±5% Voltage Rating - AC: 400V Operating Temperature: -25 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene – Metallized Case: Preformed Case with Epoxy Fill Termination: AMP187, AMP250, SOLID WIRE, DIN SOLDER TABS, AND STRANDED WIRE Dimension inches: 0.669" T x 1.063" H x 1.220" W Dimension mm: 17.0mm x 27.0mm x 31.0mm
X349 1 5 450		Data Sheet: X349	Application: DC Filter, Sample Hold Capacitance (µF): 1 Tolerance: ±5% Voltage Rating - AC: 450V Operating Temperature: -25 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene – Metallized Case: Preformed Case with Epoxy Fill Termination: AMP187, AMP250, SOLID WIRE, DIN SOLDER TABS, AND STRANDED WIRE Dimension inches: 0.709" T x 1.063" H x 1.457" W Dimension mm: 18.0mm x 27.0mm x 37.0mm
X362 1 1 100		Data Sheet: X362	Application: Power Supply, Pulse Current Capacitance (µF): 1 Tolerance: ±1% Voltage Rating - DC: 100V Operating Temperature: -55 °C to +105 °C IPeak: 6 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.260" T x 1.200" H x 0.430" L Dimension mm: 6.6mm x 30.5mm x 10.9mm
X362 1 1 200		Data Sheet: X362	Application: Power Supply, Pulse Current Capacitance (µF): 1 Tolerance: ±1% Voltage Rating - DC: 200V Operating Temperature: -55 °C to +105 °C IPeak: 10 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.410" T x 1.220" H x 0.580" L Dimension mm: 10.4mm x 31.0mm x 14.7mm

Showing 193–204 of 385 results
