0.82µF

Product Code	Data Sheet	Attributes
X362 0.82 1 100	Data Sheet: X362	Application: Power Supply, Pulse Current Capacitance (µF): 0.82 Tolerance: ±1% Voltage Rating - DC: 100V Operating Temperature: -55 °C to +105 °C IPeak: 9 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.370" T x 0.830" H x 0.470" L Dimension mm: 9.4mm x 21.1mm x 11.9mm
X362 0.82 1 200	Data Sheet: X362	Application: Power Supply, Pulse Current Capacitance (µF): 0.82 Tolerance: ±1% Voltage Rating - DC: 200V Operating Temperature: -55 °C to +105 °C IPeak: 8.2 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.370" T x 1.220" H x 0.540" L Dimension mm: 9.4mm x 31.0mm x 13.7mm
X362 0.82 1 400	Data Sheet: X362	Application: Power Supply, Pulse Current Capacitance (µF): 0.82 Tolerance: ±1% Voltage Rating - DC: 400V Operating Temperature: -55 °C to +105 °C IPeak: 7.4 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.500" T x 1.200" H x 0.660" L Dimension mm: 12.7mm x 30.5mm x 16.8mm
X362 0.82 10 100	Data Sheet: X362	Application: Power Supply, Pulse Current Capacitance (µF): 0.82 Tolerance: ±10% Voltage Rating - DC: 100V Operating Temperature: -55 °C to +105 °C IPeak: 9 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.370" T x 0.830" H x 0.470" L Dimension mm: 9.4mm x 21.1mm x 11.9mm
X362 0.82 10 200	Data Sheet: X362	Application: Power Supply, Pulse Current Capacitance (µF): 0.82 Tolerance: ±10% Voltage Rating - DC: 200V Operating Temperature: -55 °C to +105 °C IPeak: 8.2 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.370" T x 1.220" H x 0.540" L Dimension mm: 9.4mm x 31.0mm x 13.7mm
X362 0.82 10 400	Data Sheet: X362	Application: Power Supply, Pulse Current Capacitance (µF): 0.82 Tolerance: ±10% Voltage Rating - DC: 400V Operating Temperature: -55 °C to +105 °C IPeak: 7.4 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.500" T x 1.200" H x 0.660" L Dimension mm: 12.7mm x 30.5mm x 16.8mm
X362 0.82 2 100	Data Sheet: X362	Application: Power Supply, Pulse Current Capacitance (µF): 0.82 Tolerance: ±2% Voltage Rating - DC: 100V Operating Temperature: -55 °C to +105 °C IPeak: 9 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.370" T x 0.830" H x 0.470" L Dimension mm: 9.4mm x 21.1mm x 11.9mm
X362 0.82 2 200	Data Sheet: X362	Application: Power Supply, Pulse Current Capacitance (µF): 0.82 Tolerance: ±2% Voltage Rating - DC: 200V Operating Temperature: -55 °C to +105 °C IPeak: 8.2 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.370" T x 1.220" H x 0.540" L Dimension mm: 9.4mm x 31.0mm x 13.7mm
X362 0.82 2 400	Data Sheet: X362	Application: Power Supply, Pulse Current Capacitance (µF): 0.82 Tolerance: ±2% Voltage Rating - DC: 400V Operating Temperature: -55 °C to +105 °C IPeak: 7.4 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.500" T x 1.200" H x 0.660" L Dimension mm: 12.7mm x 30.5mm x 16.8mm
X362 0.82 20 100	Data Sheet: X362	Application: Power Supply, Pulse Current Capacitance (µF): 0.82 Tolerance: ±20% Voltage Rating - DC: 100V Operating Temperature: -55 °C to +105 °C IPeak: 9 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.370" T x 0.830" H x 0.470" L Dimension mm: 9.4mm x 21.1mm x 11.9mm
X362 0.82 20 200	Data Sheet: X362	Application: Power Supply, Pulse Current Capacitance (µF): 0.82 Tolerance: ±20% Voltage Rating - DC: 200V Operating Temperature: -55 °C to +105 °C IPeak: 8.2 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.370" T x 1.220" H x 0.540" L Dimension mm: 9.4mm x 31.0mm x 13.7mm
X362 0.82 20 400	Data Sheet: X362	Application: Power Supply, Pulse Current Capacitance (µF): 0.82 Tolerance: ±20% Voltage Rating - DC: 400V Operating Temperature: -55 °C to +105 °C IPeak: 7.4 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.500" T x 1.200" H x 0.660" L Dimension mm: 12.7mm x 30.5mm x 16.8mm
