0.68µF

Product Code	Data Sheet	Attributes
X368 0.68 5 630	Data Sheet: X368	Application: Power Supply, Pulse Current Capacitance (µF): 0.68 Tolerance: ±5% Voltage Rating - DC: 630V Operating Temperature: -40 °C to +85 °C IPeak: 2.7 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.457" H x 0.728" D Dimension mm: 37.0mm x 18.5mm
X375 0.68 1 2000	Data Sheet: X375	Application: Power Supply, Pulse Current Capacitance (µF): 0.68 Tolerance: ±1% Voltage Rating - DC: 2000V Voltage Rating - AC: Operating Temperature: -55 °C to +65 °C Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.914" H x 1.550" D Dimension mm: 48.6mm x 39.4mm
X375 0.68 10 2000	Data Sheet: X375	Application: Power Supply, Pulse Current Capacitance (µF): 0.68 Tolerance: ±10% Voltage Rating - DC: 2000V Voltage Rating - AC: Operating Temperature: -55 °C to +65 °C Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.914" H x 1.550" D Dimension mm: 48.6mm x 39.4mm
X375 0.68 2 2000	Data Sheet: X375	Application: Power Supply, Pulse Current Capacitance (µF): 0.68 Tolerance: ±2% Voltage Rating - DC: 2000V Voltage Rating - AC: Operating Temperature: -55 °C to +65 °C Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.914" H x 1.550" D Dimension mm: 48.6mm x 39.4mm
X375 0.68 20 2000	Data Sheet: X375	Application: Power Supply, Pulse Current Capacitance (µF): 0.68 Tolerance: ±20% Voltage Rating - DC: 2000V Voltage Rating - AC: Operating Temperature: -55 °C to +65 °C Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.914" H x 1.550" D Dimension mm: 48.6mm x 39.4mm
X375 0.68 5 2000	Data Sheet: X375	Application: Power Supply, Pulse Current Capacitance (µF): 0.68 Tolerance: ±5% Voltage Rating - DC: 2000V Voltage Rating - AC: Operating Temperature: -55 °C to +65 °C Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.914" H x 1.550" D Dimension mm: 48.6mm x 39.4mm
X620 0.68 10 100	Data Sheet: X620	Application: Filtering, General Purpose, Instrumentation Capacitance (µF): 0.68 Tolerance: ±10% Voltage Rating - DC: 100V Operating Temperature: -40 °C to +85 °C IPeak: 4.1 Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polyester film Mounting Type: Through Hole Dielectric Material: Polyester - Metallized Case: Epoxy Dipped Termination: Solid Wire Dimension inches: 0.256" T x 0.413" H x 0.492" L Dimension mm: 6.5mm x 10.5mm x 12.5mm
X620 0.68 10 250	Data Sheet: X620	Application: Filtering, General Purpose, Instrumentation Capacitance (µF): 0.68 Tolerance: ±10% Voltage Rating - DC: 250V Operating Temperature: -40 °C to +85 °C IPeak: 4.8 Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polyester film Mounting Type: Through Hole Dielectric Material: Polyester - Metallized Case: Epoxy Dipped Termination: Solid Wire Dimension inches: 0.276" T x 0.531" H x 0.728" L Dimension mm: 7.0mm x 13.5mm x 18.5mm
X620 0.68 10 400	Data Sheet: X620	Application: Filtering, General Purpose, Instrumentation Capacitance (µF): 0.68 Tolerance: ±10% Voltage Rating - DC: 400V Operating Temperature: -40 °C to +85 °C IPeak: 5.4 Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polyester film Mounting Type: Through Hole Dielectric Material: Polyester - Metallized Case: Epoxy Dipped Termination: Solid Wire Dimension inches: 0.295" T x 0.669" H x 1.024" L Dimension mm: 7.5mm x 17.0mm x 26.0mm
X620 0.68 10 630	Data Sheet: X620	Application: Filtering, General Purpose, Instrumentation Capacitance (µF): 0.68 Tolerance: ±10% Voltage Rating - DC: 630V Operating Temperature: -40 °C to +85 °C IPeak: 8.2 Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polyester film Mounting Type: Through Hole Dielectric Material: Polyester - Metallized Case: Epoxy Dipped Termination: Solid Wire Dimension inches: 0.472" T x 0.866" H x 1.024" L Dimension mm: 12.0mm x 22.0mm x 26.0mm
X620 0.68 20 100	Data Sheet: X620	Application: Filtering, General Purpose, Instrumentation Capacitance (µF): 0.68 Tolerance: ±20% Voltage Rating - DC: 100V Operating Temperature: -40 °C to +85 °C IPeak: 4.1 Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polyester film Mounting Type: Through Hole Dielectric Material: Polyester - Metallized Case: Epoxy Dipped Termination: Solid Wire Dimension inches: 0.256" T x 0.413" H x 0.492" L Dimension mm: 6.5mm x 10.5mm x 12.5mm
X620 0.68 20 250	Data Sheet: X620	Application: Filtering, General Purpose, Instrumentation Capacitance (µF): 0.68 Tolerance: ±20% Voltage Rating - DC: 250V Operating Temperature: -40 °C to +85 °C IPeak: 4.8 Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polyester film Mounting Type: Through Hole Dielectric Material: Polyester - Metallized Case: Epoxy Dipped Termination: Solid Wire Dimension inches: 0.276" T x 0.531" H x 0.728" L Dimension mm: 7.0mm x 13.5mm x 18.5mm
