0.56uF

Product Code	Data Sheet	Attributes
BLS 0.56 20 400	Data Sheet: BLS	Application: Electronic Lighting, High Frequency, High Voltage, Snubber and SCR commutating circuits, Switching spikes suppression in SMPS Capacitance (µF): 0.56 Tolerance: ±20% Voltage Rating - DC: 630V Voltage Rating - AC: 400V Operating Temperature: -40 °C to +105 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound double-sided metallized polyester film electrodes Dielectric Material: Polypropylene - Double Metallized Case: Retardant Case Dimension inches: Dimension mm: 16.0mm T x 25.5mm H x 32.0mm L
BLS 0.56 20 600	Data Sheet: BLS	Application: Electronic Lighting, High Frequency, High Voltage, Snubber and SCR commutating circuits, Switching spikes suppression in SMPS Capacitance (µF): 0.56 Tolerance: ±20% Voltage Rating - DC: 1200V Voltage Rating - AC: 600V Operating Temperature: -40 °C to +105 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound double-sided metallized polyester film electrodes Dielectric Material: Polypropylene - Double Metallized Case: Retardant Case Dimension inches: Dimension mm: 22.0mm T x 37.0mm H x 42.0mm L
BLS 0.56 20 650	Data Sheet: BLS	Application: Electronic Lighting, High Frequency, High Voltage, Snubber and SCR commutating circuits, Switching spikes suppression in SMPS Capacitance (µF): 0.56 Tolerance: ±20% Voltage Rating - DC: 1600V Voltage Rating - AC: 650V Operating Temperature: -40 °C to +105 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound double-sided metallized polyester film electrodes Dielectric Material: Polypropylene - Double Metallized Case: Retardant Case Dimension inches: Dimension mm: 26.0mm T x 39.0mm H x 42.0mm L
BLS 0.56 5 400	Data Sheet: BLS	Application: Electronic Lighting, High Frequency, High Voltage, Snubber and SCR commutating circuits, Switching spikes suppression in SMPS Capacitance (µF): 0.56 Tolerance: ±5% Voltage Rating - DC: 630V Voltage Rating - AC: 400V Operating Temperature: -40 °C to +105 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound double-sided metallized polyester film electrodes Dielectric Material: Polypropylene - Double Metallized Case: Retardant Case Dimension inches: Dimension mm: 16.0mm T x 25.5mm H x 32.0mm L
BLS 0.56 5 600	Data Sheet: BLS	Application: Electronic Lighting, High Frequency, High Voltage, Snubber and SCR commutating circuits, Switching spikes suppression in SMPS Capacitance (µF): 0.56 Tolerance: ±5% Voltage Rating - DC: 1200V Voltage Rating - AC: 600V Operating Temperature: -40 °C to +105 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound double-sided metallized polyester film electrodes Dielectric Material: Polypropylene - Double Metallized Case: Retardant Case Dimension inches: Dimension mm: 22.0mm T x 37.0mm H x 42.0mm L
BLS 0.56 5 650	Data Sheet: BLS	Application: Electronic Lighting, High Frequency, High Voltage, Snubber and SCR commutating circuits, Switching spikes suppression in SMPS Capacitance (µF): 0.56 Tolerance: ±5% Voltage Rating - DC: 1600V Voltage Rating - AC: 650V Operating Temperature: -40 °C to +105 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound double-sided metallized polyester film electrodes Dielectric Material: Polypropylene - Double Metallized Case: Retardant Case Dimension inches: Dimension mm: 26.0mm T x 39.0mm H x 42.0mm L
MPWC 0.56 10 250 / 275	Data Sheet: MPWC	Application: Class X-2 EMI Noise Suppression Capacitance (µF): 0.56 Tolerance: ±10% Voltage Rating - AC: 250V / 275V Operating Temperature: -40 °C to +85 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene, Polypropylene – Metallized Case: Preformed Case with Epoxy Fill Termination: Solid Wire Dimension inches: 0.394" T x 0.748" H x 1.200" L Dimension mm: 10.0mm T x 19.0mm H x 30.5mm L
MPWC 0.56 20 250 / 275	Data Sheet: MPWC	Application: Class X-2 EMI Noise Suppression Capacitance (µF): 0.56 Tolerance: ±20% Voltage Rating - AC: 250V / 275V Operating Temperature: -40 °C to +85 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene, Polypropylene – Metallized Case: Preformed Case with Epoxy Fill Termination: Solid Wire Dimension inches: 0.394" T x 0.748" H x 1.200" L Dimension mm: 10.0mm T x 19.0mm H x 30.5mm L
PXK (15.0 x 11.0 x 17.0) 0.56 10 305	Data Sheet: PXK	Application: Class X-2 EMI Noise Suppression Capacitance (µF): 0.56 Tolerance: ±10% Voltage Rating - DC: 305V Operating Temperature: -40 °C to +110 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Preformed Case with Epoxy Fill Dimension mm: 11.0mm T x 17.0mm H x 15.0mm W
PXK (18.0 x 11.0 x 18.5) 0.56 10 305	Data Sheet: PXK	Application: Class X-2 EMI Noise Suppression Capacitance (µF): 0.56 Tolerance: ±10% Voltage Rating - DC: 305V Operating Temperature: -40 °C to +110 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Preformed Case with Epoxy Fill Dimension mm: 11.0mm T x 18.5mm H x 18.0mm W
PXK (18.0 x 9.0 x 15.0) 0.56 10 305	Data Sheet: PXK	Application: Class X-2 EMI Noise Suppression Capacitance (µF): 0.56 Tolerance: ±10% Voltage Rating - DC: 305V Operating Temperature: -40 °C to +110 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Preformed Case with Epoxy Fill Dimension mm: 9.0mm T x 15.0mm H x 18.0mm W
PXK (26.5 x 10.0 x 19.0) 0.56 10 305	Data Sheet: PXK	Application: Class X-2 EMI Noise Suppression Capacitance (µF): 0.56 Tolerance: ±10% Voltage Rating - DC: 305V Operating Temperature: -40 °C to +110 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Preformed Case with Epoxy Fill Dimension mm: 10.0mm T x 19.0mm H x 26.5mm W
