0.47µF

Product Code	Data Sheet	Attributes
X368 0.47 20 630	Data Sheet: X368	Application: Power Supply, Pulse Current Capacitance (µF): 0.47 Tolerance: ±20% Voltage Rating - DC: 630V Operating Temperature: -40 °C to +85 °C IPeak: 2.8 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.260" H x 0.669" D Dimension mm: 32.0mm x 17.0mm
X368 0.47 5 250	Data Sheet: X368	Application: Power Supply, Pulse Current Capacitance (µF): 0.47 Tolerance: ±5% Voltage Rating - DC: 250V Operating Temperature: -40 °C to +85 °C IPeak: 1.9 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.984" H x 0.413" D Dimension mm: 25.0mm x 10.5mm
X368 0.47 5 400	Data Sheet: X368	Application: Power Supply, Pulse Current Capacitance (µF): 0.47 Tolerance: ±5% Voltage Rating - DC: 400V Operating Temperature: -40 °C to +85 °C IPeak: 1.9 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.260" H x 0.472" D Dimension mm: 32.0mm x 12.0mm
X368 0.47 5 630	Data Sheet: X368	Application: Power Supply, Pulse Current Capacitance (µF): 0.47 Tolerance: ±5% Voltage Rating - DC: 630V Operating Temperature: -40 °C to +85 °C IPeak: 2.8 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.260" H x 0.669" D Dimension mm: 32.0mm x 17.0mm
X375 0.47 1 2000	Data Sheet: X375	Application: Power Supply, Pulse Current Capacitance (µF): 0.47 Tolerance: ±1% Voltage Rating - DC: 2000V Voltage Rating - AC: Operating Temperature: -55 °C to +65 °C Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.914" H x 1.300" D Dimension mm: 48.6mm x 33.0mm
X375 0.47 10 2000	Data Sheet: X375	Application: Power Supply, Pulse Current Capacitance (µF): 0.47 Tolerance: ±10% Voltage Rating - DC: 2000V Voltage Rating - AC: Operating Temperature: -55 °C to +65 °C Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.914" H x 1.300" D Dimension mm: 48.6mm x 33.0mm
X375 0.47 2 2000	Data Sheet: X375	Application: Power Supply, Pulse Current Capacitance (µF): 0.47 Tolerance: ±2% Voltage Rating - DC: 2000V Voltage Rating - AC: Operating Temperature: -55 °C to +65 °C Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.914" H x 1.300" D Dimension mm: 48.6mm x 33.0mm
X375 0.47 20 2000	Data Sheet: X375	Application: Power Supply, Pulse Current Capacitance (µF): 0.47 Tolerance: ±20% Voltage Rating - DC: 2000V Voltage Rating - AC: Operating Temperature: -55 °C to +65 °C Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.914" H x 1.300" D Dimension mm: 48.6mm x 33.0mm
X375 0.47 5 2000	Data Sheet: X375	Application: Power Supply, Pulse Current Capacitance (µF): 0.47 Tolerance: ±5% Voltage Rating - DC: 2000V Voltage Rating - AC: Operating Temperature: -55 °C to +65 °C Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.914" H x 1.300" D Dimension mm: 48.6mm x 33.0mm
X620 0.47 10 250	Data Sheet: X620	Application: Filtering, General Purpose, Instrumentation Capacitance (µF): 0.47 Tolerance: ±10% Voltage Rating - DC: 250V Operating Temperature: -40 °C to +85 °C IPeak: 3.3 Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polyester film Mounting Type: Through Hole Dielectric Material: Polyester - Metallized Case: Epoxy Dipped Termination: Solid Wire Dimension inches: 0.236" T x 0.492" H x 0.728" L Dimension mm: 6.0mm x 12.5mm x 18.5mm
X620 0.47 10 400	Data Sheet: X620	Application: Filtering, General Purpose, Instrumentation Capacitance (µF): 0.47 Tolerance: ±10% Voltage Rating - DC: 400V Operating Temperature: -40 °C to +85 °C IPeak: 4.7 Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polyester film Mounting Type: Through Hole Dielectric Material: Polyester - Metallized Case: Epoxy Dipped Termination: Solid Wire Dimension inches: 0.335" T x 0.650" H x 0.728" L Dimension mm: 8.5mm x 16.5mm x 18.5mm
X620 0.47 10 630	Data Sheet: X620	Application: Filtering, General Purpose, Instrumentation Capacitance (µF): 0.47 Tolerance: ±10% Voltage Rating - DC: 630V Operating Temperature: -40 °C to +85 °C IPeak: 5.6 Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polyester film Mounting Type: Through Hole Dielectric Material: Polyester - Metallized Case: Epoxy Dipped Termination: Solid Wire Dimension inches: 0.413" T x 0.728" H x 1.024" L Dimension mm: 10.5mm x 18.5mm x 26.0mm
