0.47µF

Product Code	Data Sheet	Attributes
X321 0.47 5 630	Data Sheet: X321	Application: Filtering, General Purpose, Instrumentation Capacitance (µF): 0.47 Tolerance: ±5% Voltage Rating - DC: 630V Operating Temperature: -40 °C to +85 °C IPeak: 3.3 Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Mounting Type: Through Hole Dielectric Material: Polypropylene - Metallized Case: Epoxy Dipped Termination: Solid Wire Dimension inches: 0.610" T x 0.965" H x 1.220" L Dimension mm: 15.5mm x 24.5mm x 31.0mm
X323 0.47 10 250	Data Sheet: X323	Application: Power Supply, Pulse Current Capacitance (µF): 0.47 Tolerance: ±10% Voltage Rating - DC: 250V Operating Temperature: -40 °C to +85 °C IPeak: 1.9 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.315" T x 0.984" H x 0.531" L Dimension mm: 8.0mm x 25.0mm x 13.5mm
X323 0.47 10 400	Data Sheet: X323	Application: Power Supply, Pulse Current Capacitance (µF): 0.47 Tolerance: ±10% Voltage Rating - DC: 400V Operating Temperature: -40 °C to +85 °C IPeak: 3.1 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.374" T x 1.260" H x 0.630" L Dimension mm: 9.5mm x 32.0mm x 16.0mm
X323 0.47 10 630	Data Sheet: X323	Application: Power Supply, Pulse Current Capacitance (µF): 0.47 Tolerance: ±10% Voltage Rating - DC: 630V Operating Temperature: -40 °C to +85 °C IPeak: 4.7 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.551" T x 1.260" H x 0.906" L Dimension mm: 14.0mm x 32.0mm x 23.0mm
X323 0.47 20 250	Data Sheet: X323	Application: Power Supply, Pulse Current Capacitance (µF): 0.47 Tolerance: ±20% Voltage Rating - DC: 250V Operating Temperature: -40 °C to +85 °C IPeak: 1.9 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.315" T x 0.984" H x 0.531" L Dimension mm: 8.0mm x 25.0mm x 13.5mm
X323 0.47 20 400	Data Sheet: X323	Application: Power Supply, Pulse Current Capacitance (µF): 0.47 Tolerance: ±20% Voltage Rating - DC: 400V Operating Temperature: -40 °C to +85 °C IPeak: 3.1 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.374" T x 1.260" H x 0.630" L Dimension mm: 9.5mm x 32.0mm x 16.0mm
X323 0.47 20 630	Data Sheet: X323	Application: Power Supply, Pulse Current Capacitance (µF): 0.47 Tolerance: ±20% Voltage Rating - DC: 630V Operating Temperature: -40 °C to +85 °C IPeak: 4.7 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.551" T x 1.260" H x 0.906" L Dimension mm: 14.0mm x 32.0mm x 23.0mm
X323 0.47 5 250	Data Sheet: X323	Application: Power Supply, Pulse Current Capacitance (µF): 0.47 Tolerance: ±5% Voltage Rating - DC: 250V Operating Temperature: -40 °C to +85 °C IPeak: 1.9 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.315" T x 0.984" H x 0.531" L Dimension mm: 8.0mm x 25.0mm x 13.5mm
X323 0.47 5 400	Data Sheet: X323	Application: Power Supply, Pulse Current Capacitance (µF): 0.47 Tolerance: ±5% Voltage Rating - DC: 400V Operating Temperature: -40 °C to +85 °C IPeak: 3.1 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.374" T x 1.260" H x 0.630" L Dimension mm: 9.5mm x 32.0mm x 16.0mm
X323 0.47 5 630	Data Sheet: X323	Application: Power Supply, Pulse Current Capacitance (µF): 0.47 Tolerance: ±5% Voltage Rating - DC: 630V Operating Temperature: -40 °C to +85 °C IPeak: 4.7 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.551" T x 1.260" H x 0.906" L Dimension mm: 14.0mm x 32.0mm x 23.0mm
X329(F) 0.47 10 250	Data Sheet: 329	Application: IGBT Snubber Capacitance (µF): 0.47 Tolerance: ±10% Voltage Rating - DC: 600V Voltage Rating - AC: 250V Operating Temperature: -40 °C to +85 °C ESR: 21.4 mOhms IPeak: 50 Irms (Arms): 3.5 Lifecycle @ Rated Temp & Voltage: 15,000 hrs Construction: metallized polypropylene film and foil Dielectric Material: Polypropylene – Metallized and Foil Case: Preformed Case with Epoxy Fill Termination: Slotted Tabs Dimension inches: 0.860" T x 1.113" H Dimension mm: 21.8mm x 28.3mm ESR kHz: 100kHz
X329(F) 0.47 10 500	Data Sheet: 329	Application: IGBT Snubber Capacitance (µF): 0.47 Tolerance: ±10% Voltage Rating - DC: 1200V Voltage Rating - AC: 500V Operating Temperature: -40 °C to +85 °C ESR: 8.8 mOhms IPeak: 129 Irms (Arms): 5.2 Lifecycle @ Rated Temp & Voltage: 15,000 hrs Construction: metallized polypropylene film and foil Dielectric Material: Polypropylene – Metallized and Foil Case: Preformed Case with Epoxy Fill Termination: Slotted Tabs Dimension inches: 0.860" T x 1.113" H Dimension mm: 21.8mm x 28.3mm ESR kHz: 100kHz
