0.33µF

Product Code	Data Sheet	Attributes
668 0.33 10 200	Data Sheet: 668	Application: Power Supply, Pulse Current Capacitance (µF): 0.33 Tolerance: ±10% Voltage Rating - DC: 200V Operating Temperature: -40 °C to +85 °C Lifecycle @ Rated Temp & Voltage: 15,000 hrs Construction: non-inductive wound polyester film and foil Dielectric Material: Polyester and Foil Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.260" H x 0.453" D Dimension mm: 32.0mm x 11.5mm
668 0.33 20 100	Data Sheet: 668	Application: Power Supply, Pulse Current Capacitance (µF): 0.33 Tolerance: ±20% Voltage Rating - DC: 100V Operating Temperature: -40 °C to +85 °C Lifecycle @ Rated Temp & Voltage: 15,000 hrs Construction: non-inductive wound polyester film and foil Dielectric Material: Polyester and Foil Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.260" H x 0.413" D Dimension mm: 32.0mm x 10.5mm
668 0.33 20 200	Data Sheet: 668	Application: Power Supply, Pulse Current Capacitance (µF): 0.33 Tolerance: ±20% Voltage Rating - DC: 200V Operating Temperature: -40 °C to +85 °C Lifecycle @ Rated Temp & Voltage: 15,000 hrs Construction: non-inductive wound polyester film and foil Dielectric Material: Polyester and Foil Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.260" H x 0.453" D Dimension mm: 32.0mm x 11.5mm
668 0.33 5 100	Data Sheet: 668	Application: Power Supply, Pulse Current Capacitance (µF): 0.33 Tolerance: ±5% Voltage Rating - DC: 100V Operating Temperature: -40 °C to +85 °C Lifecycle @ Rated Temp & Voltage: 15,000 hrs Construction: non-inductive wound polyester film and foil Dielectric Material: Polyester and Foil Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.260" H x 0.413" D Dimension mm: 32.0mm x 10.5mm
668 0.33 5 200	Data Sheet: 668	Application: Power Supply, Pulse Current Capacitance (µF): 0.33 Tolerance: ±5% Voltage Rating - DC: 200V Operating Temperature: -40 °C to +85 °C Lifecycle @ Rated Temp & Voltage: 15,000 hrs Construction: non-inductive wound polyester film and foil Dielectric Material: Polyester and Foil Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.260" H x 0.453" D Dimension mm: 32.0mm x 11.5mm
BLS 0.33 10 400	Data Sheet: BLS	Application: Electronic Lighting, High Frequency, High Voltage, Snubber and SCR commutating circuits, Switching spikes suppression in SMPS Capacitance (µF): 0.33 Tolerance: ±10% Voltage Rating - DC: 630V Voltage Rating - AC: 400V Operating Temperature: -40 °C to +105 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound double-sided metallized polyester film electrodes Dielectric Material: Polypropylene - Double Metallized Case: Retardant Case Dimension inches: Dimension mm: 23.0mm T x 23.0mm H x 26.5mm L
BLS 0.33 10 600	Data Sheet: BLS	Application: Electronic Lighting, High Frequency, High Voltage, Snubber and SCR commutating circuits, Switching spikes suppression in SMPS Capacitance (µF): 0.33 Tolerance: ±10% Voltage Rating - DC: 1200V Voltage Rating - AC: 600V Operating Temperature: -40 °C to +105 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound double-sided metallized polyester film electrodes Dielectric Material: Polypropylene - Double Metallized Case: Retardant Case Dimension inches: Dimension mm: 18.0mm T x 30.0mm H x 42.0mm L
BLS 0.33 10 650	Data Sheet: BLS	Application: Electronic Lighting, High Frequency, High Voltage, Snubber and SCR commutating circuits, Switching spikes suppression in SMPS Capacitance (µF): 0.33 Tolerance: ±10% Voltage Rating - DC: 1600V Voltage Rating - AC: 650V Operating Temperature: -40 °C to +105 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound double-sided metallized polyester film electrodes Dielectric Material: Polypropylene - Double Metallized Case: Retardant Case Dimension inches: Dimension mm: 20.5mm T x 34.0mm H x 42.0mm L
BLS 0.33 10 700	Data Sheet: BLS	Application: Electronic Lighting, High Frequency, High Voltage, Snubber and SCR commutating circuits, Switching spikes suppression in SMPS Capacitance (µF): 0.33 Tolerance: ±10% Voltage Rating - DC: 2000V Voltage Rating - AC: 700V Operating Temperature: -40 °C to +105 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound double-sided metallized polyester film electrodes Dielectric Material: Polypropylene - Double Metallized Case: Retardant Case Dimension inches: Dimension mm: 26.0mm T x 39.0mm H x 42.0mm L
BLS 0.33 20 400	Data Sheet: BLS	Application: Electronic Lighting, High Frequency, High Voltage, Snubber and SCR commutating circuits, Switching spikes suppression in SMPS Capacitance (µF): 0.33 Tolerance: ±20% Voltage Rating - DC: 630V Voltage Rating - AC: 400V Operating Temperature: -40 °C to +105 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound double-sided metallized polyester film electrodes Dielectric Material: Polypropylene - Double Metallized Case: Retardant Case Dimension inches: Dimension mm: 23.0mm T x 23.0mm H x 26.5mm L
BLS 0.33 20 600	Data Sheet: BLS	Application: Electronic Lighting, High Frequency, High Voltage, Snubber and SCR commutating circuits, Switching spikes suppression in SMPS Capacitance (µF): 0.33 Tolerance: ±20% Voltage Rating - DC: 1200V Voltage Rating - AC: 600V Operating Temperature: -40 °C to +105 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound double-sided metallized polyester film electrodes Dielectric Material: Polypropylene - Double Metallized Case: Retardant Case Dimension inches: Dimension mm: 18.0mm T x 30.0mm H x 42.0mm L
BLS 0.33 20 650	Data Sheet: BLS	Application: Electronic Lighting, High Frequency, High Voltage, Snubber and SCR commutating circuits, Switching spikes suppression in SMPS Capacitance (µF): 0.33 Tolerance: ±20% Voltage Rating - DC: 1600V Voltage Rating - AC: 650V Operating Temperature: -40 °C to +105 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound double-sided metallized polyester film electrodes Dielectric Material: Polypropylene - Double Metallized Case: Retardant Case Dimension inches: Dimension mm: 20.5mm T x 34.0mm H x 42.0mm L
