0.22µF

Product Code	Data Sheet	Attributes
X362 0.22 1 200	Data Sheet: X362	Application: Power Supply, Pulse Current Capacitance (µF): 0.22 Tolerance: ±1% Voltage Rating - DC: 200V Operating Temperature: -55 °C to +105 °C IPeak: 3.5 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.280" T x 0.830" H x 0.380" L Dimension mm: 7.1mm x 21.1mm x 9.7mm
X362 0.22 1 400	Data Sheet: X362	Application: Power Supply, Pulse Current Capacitance (µF): 0.22 Tolerance: ±1% Voltage Rating - DC: 400V Operating Temperature: -55 °C to +105 °C IPeak: 4.6 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.380" T x 0.830" H x 0.480" L Dimension mm: 9.7mm x 21.1mm x 12.2mm
X362 0.22 10 100	Data Sheet: X362	Application: Power Supply, Pulse Current Capacitance (µF): 0.22 Tolerance: ±10% Voltage Rating - DC: 100V Operating Temperature: -55 °C to +105 °C IPeak: 4.6 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.270" T x 0.580" H x 0.370" L Dimension mm: 6.9mm x 14.7mm x 9.4mm
X362 0.22 10 200	Data Sheet: X362	Application: Power Supply, Pulse Current Capacitance (µF): 0.22 Tolerance: ±10% Voltage Rating - DC: 200V Operating Temperature: -55 °C to +105 °C IPeak: 3.5 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.280" T x 0.830" H x 0.380" L Dimension mm: 7.1mm x 21.1mm x 9.7mm
X362 0.22 10 400	Data Sheet: X362	Application: Power Supply, Pulse Current Capacitance (µF): 0.22 Tolerance: ±10% Voltage Rating - DC: 400V Operating Temperature: -55 °C to +105 °C IPeak: 4.6 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.380" T x 0.830" H x 0.480" L Dimension mm: 9.7mm x 21.1mm x 12.2mm
X362 0.22 2 100	Data Sheet: X362	Application: Power Supply, Pulse Current Capacitance (µF): 0.22 Tolerance: ±2% Voltage Rating - DC: 100V Operating Temperature: -55 °C to +105 °C IPeak: 4.6 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.270" T x 0.580" H x 0.370" L Dimension mm: 6.9mm x 14.7mm x 9.4mm
X362 0.22 2 200	Data Sheet: X362	Application: Power Supply, Pulse Current Capacitance (µF): 0.22 Tolerance: ±2% Voltage Rating - DC: 200V Operating Temperature: -55 °C to +105 °C IPeak: 3.5 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.280" T x 0.830" H x 0.380" L Dimension mm: 7.1mm x 21.1mm x 9.7mm
X362 0.22 2 400	Data Sheet: X362	Application: Power Supply, Pulse Current Capacitance (µF): 0.22 Tolerance: ±2% Voltage Rating - DC: 400V Operating Temperature: -55 °C to +105 °C IPeak: 4.6 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.380" T x 0.830" H x 0.480" L Dimension mm: 9.7mm x 21.1mm x 12.2mm
X362 0.22 20 100	Data Sheet: X362	Application: Power Supply, Pulse Current Capacitance (µF): 0.22 Tolerance: ±20% Voltage Rating - DC: 100V Operating Temperature: -55 °C to +105 °C IPeak: 4.6 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.270" T x 0.580" H x 0.370" L Dimension mm: 6.9mm x 14.7mm x 9.4mm
X362 0.22 20 200	Data Sheet: X362	Application: Power Supply, Pulse Current Capacitance (µF): 0.22 Tolerance: ±20% Voltage Rating - DC: 200V Operating Temperature: -55 °C to +105 °C IPeak: 3.5 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.280" T x 0.830" H x 0.380" L Dimension mm: 7.1mm x 21.1mm x 9.7mm
X362 0.22 20 400	Data Sheet: X362	Application: Power Supply, Pulse Current Capacitance (µF): 0.22 Tolerance: ±20% Voltage Rating - DC: 400V Operating Temperature: -55 °C to +105 °C IPeak: 4.6 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.380" T x 0.830" H x 0.480" L Dimension mm: 9.7mm x 21.1mm x 12.2mm
X362 0.22 5 100	Data Sheet: X362	Application: Power Supply, Pulse Current Capacitance (µF): 0.22 Tolerance: ±5% Voltage Rating - DC: 100V Operating Temperature: -55 °C to +105 °C IPeak: 4.6 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.270" T x 0.580" H x 0.370" L Dimension mm: 6.9mm x 14.7mm x 9.4mm
