0.22µF

Product Code	Data Sheet	Attributes
X323 0.22 5 400	Data Sheet: X323	Application: Power Supply, Pulse Current Capacitance (µF): 0.22 Tolerance: ±5% Voltage Rating - DC: 400V Operating Temperature: -40 °C to +85 °C IPeak: 1.4 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.315" T x 0.984" H x 0.551" L Dimension mm: 8.0mm x 25.0mm x 14.0mm
X323 0.22 5 630	Data Sheet: X323	Application: Power Supply, Pulse Current Capacitance (µF): 0.22 Tolerance: ±5% Voltage Rating - DC: 630V Operating Temperature: -40 °C to +85 °C IPeak: 2.2 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.354" T x 1.260" H x 0.610" L Dimension mm: 9.0mm x 32.0mm x 15.5mm
X329(F) 0.22 10 500	Data Sheet: 329	Application: IGBT Snubber Capacitance (µF): 0.22 Tolerance: ±10% Voltage Rating - DC: 1200V Voltage Rating - AC: 500V Operating Temperature: -40 °C to +85 °C ESR: 18.7 mOhms IPeak: 60 Irms (Arms): 2.9 Lifecycle @ Rated Temp & Voltage: 15,000 hrs Construction: metallized polypropylene film and foil Dielectric Material: Polypropylene – Metallized and Foil Case: Preformed Case with Epoxy Fill Termination: Slotted Tabs Dimension inches: 0.860" T x 1.113" H Dimension mm: 21.8mm x 28.3mm ESR kHz: 100kHz
X329(F) 0.22 5 500	Data Sheet: 329	Application: IGBT Snubber Capacitance (µF): 0.22 Tolerance: ±5% Voltage Rating - DC: 1200V Voltage Rating - AC: 500V Operating Temperature: -40 °C to +85 °C ESR: 18.7 mOhms IPeak: 60 Irms (Arms): 2.9 Lifecycle @ Rated Temp & Voltage: 15,000 hrs Construction: metallized polypropylene film and foil Dielectric Material: Polypropylene – Metallized and Foil Case: Preformed Case with Epoxy Fill Termination: Slotted Tabs Dimension inches: 0.860" T x 1.113" H Dimension mm: 21.8mm x 28.3mm ESR kHz: 100kHz
X329(S) 0.22 10 500	Data Sheet: 329	Application: IGBT Snubber Capacitance (µF): 0.22 Tolerance: ±10% Voltage Rating - DC: 1200V Voltage Rating - AC: 500V Operating Temperature: -40 °C to +85 °C ESR: 18.7 mOhms IPeak: 60 Irms (Arms): 2.9 Lifecycle @ Rated Temp & Voltage: 15,000 hrs Construction: metallized polypropylene film and foil Dielectric Material: Polypropylene – Metallized and Foil Case: Preformed Case with Epoxy Fill Termination: Slotted Tabs Dimension inches: 0.860" T x 1.113" H Dimension mm: 21.8mm x 28.3mm ESR kHz: 100kHz
X329(S) 0.22 5 500	Data Sheet: 329	Application: IGBT Snubber Capacitance (µF): 0.22 Tolerance: ±5% Voltage Rating - DC: 1200V Voltage Rating - AC: 500V Operating Temperature: -40 °C to +85 °C ESR: 18.7 mOhms IPeak: 60 Irms (Arms): 2.9 Lifecycle @ Rated Temp & Voltage: 15,000 hrs Construction: metallized polypropylene film and foil Dielectric Material: Polypropylene – Metallized and Foil Case: Preformed Case with Epoxy Fill Termination: Slotted Tabs Dimension inches: 0.860" T x 1.113" H Dimension mm: 21.8mm x 28.3mm ESR kHz: 100kHz
X329(W) 0.22 10 500	Data Sheet: 329	Application: IGBT Snubber Capacitance (µF): 0.22 Tolerance: ±10% Voltage Rating - DC: 1200V Voltage Rating - AC: 500V Operating Temperature: -40 °C to +85 °C ESR: 18.7 mOhms IPeak: 60 Irms (Arms): 2.9 Lifecycle @ Rated Temp & Voltage: 15,000 hrs Construction: metallized polypropylene film and foil Dielectric Material: Polypropylene – Metallized and Foil Case: Preformed Case with Epoxy Fill Termination: Slotted Tabs Dimension inches: 0.860" T x 1.113" H Dimension mm: 21.8mm x 28.3mm ESR kHz: 100kHz
X329(W) 0.22 5 500	Data Sheet: 329	Application: IGBT Snubber Capacitance (µF): 0.22 Tolerance: ±5% Voltage Rating - DC: 1200V Voltage Rating - AC: 500V Operating Temperature: -40 °C to +85 °C ESR: 18.7 mOhms IPeak: 60 Irms (Arms): 2.9 Lifecycle @ Rated Temp & Voltage: 15,000 hrs Construction: metallized polypropylene film and foil Dielectric Material: Polypropylene – Metallized and Foil Case: Preformed Case with Epoxy Fill Termination: Slotted Tabs Dimension inches: 0.860" T x 1.113" H Dimension mm: 21.8mm x 28.3mm ESR kHz: 100kHz
X333F 0.22 1 220	Data Sheet: X333F	Application: Power Supply, Pulse Current Capacitance (µF): 0.22 Tolerance: ±1% Voltage Rating - DC: 400V Voltage Rating - AC: 220V Operating Temperature: -55 °C to +90 °C ESR: 42 mOhms IPeak: 2.8 Irms (Arms): check data sheet Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.240" T x 1.313" H x 0.470" L Dimension mm: 6.1mm x 33.4mm x 11.9mm ESR kHz: 100kHz
X333F 0.22 1 240	Data Sheet: X333F	Application: Power Supply, Pulse Current Capacitance (µF): 0.22 Tolerance: ±1% Voltage Rating - DC: 600V Voltage Rating - AC: 240V Operating Temperature: -55 °C to +90 °C ESR: 25 mOhms IPeak: 3.9 Irms (Arms): check data sheet Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.380" T x 1.313" H x 0.610" L Dimension mm: 9.7mm x 33.4mm x 15.5mm ESR kHz: 100kHz
X333F 0.22 1 250	Data Sheet: X333F	Application: Power Supply, Pulse Current Capacitance (µF): 0.22 Tolerance: ±1% Voltage Rating - DC: 1000V Voltage Rating - AC: 250V Operating Temperature: -55 °C to +90 °C ESR: 20 mOhms IPeak: 4 Irms (Arms): check data sheet Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.380" T x 1.313" H x 0.610" L Dimension mm: 9.7mm x 33.4mm x 15.5mm ESR kHz: 100kHz
X333F 0.22 10 220	Data Sheet: X333F	Application: Power Supply, Pulse Current Capacitance (µF): 0.22 Tolerance: ±10% Voltage Rating - DC: 400V Voltage Rating - AC: 220V Operating Temperature: -55 °C to +90 °C ESR: 42 mOhms IPeak: 2.8 Irms (Arms): check data sheet Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.240" T x 1.313" H x 0.470" L Dimension mm: 6.1mm x 33.4mm x 11.9mm ESR kHz: 100kHz
