0.15µF

Product Code	Data Sheet	Attributes
X368 0.15 5 630	Data Sheet: X368	Application: Power Supply, Pulse Current Capacitance (µF): 0.15 Tolerance: ±5% Voltage Rating - DC: 630V Operating Temperature: -40 °C to +85 °C IPeak: 1.5 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.984" H x 0.433" D Dimension mm: 25.0mm x 11.0mm
X375 0.15 1 2000	Data Sheet: X375	Application: Power Supply, Pulse Current Capacitance (µF): 0.15 Tolerance: ±1% Voltage Rating - DC: 2000V Voltage Rating - AC: Operating Temperature: -55 °C to +65 °C Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.914" H x 0.830" D Dimension mm: 48.6mm x 21.1mm
X375 0.15 1 4000	Data Sheet: X375	Application: Power Supply, Pulse Current Capacitance (µF): 0.15 Tolerance: ±1% Voltage Rating - DC: 4000V Voltage Rating - AC: Operating Temperature: -55 °C to +65 °C Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.914" H x 1.150" D Dimension mm: 48.6mm x 29.2mm
X375 0.15 1 6000	Data Sheet: X375	Application: Power Supply, Pulse Current Capacitance (µF): 0.15 Tolerance: ±1% Voltage Rating - DC: 6000V Voltage Rating - AC: Operating Temperature: -55 °C to +65 °C Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 2.664" H x 1.400" D Dimension mm: 67.7mm x 35.6mm
X375 0.15 10 2000	Data Sheet: X375	Application: Power Supply, Pulse Current Capacitance (µF): 0.15 Tolerance: ±10% Voltage Rating - DC: 2000V Voltage Rating - AC: Operating Temperature: -55 °C to +65 °C Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.914" H x 0.830" D Dimension mm: 48.6mm x 21.1mm
X375 0.15 10 4000	Data Sheet: X375	Application: Power Supply, Pulse Current Capacitance (µF): 0.15 Tolerance: ±10% Voltage Rating - DC: 4000V Voltage Rating - AC: Operating Temperature: -55 °C to +65 °C Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.914" H x 1.150" D Dimension mm: 48.6mm x 29.2mm
X375 0.15 10 6000	Data Sheet: X375	Application: Power Supply, Pulse Current Capacitance (µF): 0.15 Tolerance: ±10% Voltage Rating - DC: 6000V Voltage Rating - AC: Operating Temperature: -55 °C to +65 °C Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 2.664" H x 1.400" D Dimension mm: 67.7mm x 35.6mm
X375 0.15 2 2000	Data Sheet: X375	Application: Power Supply, Pulse Current Capacitance (µF): 0.15 Tolerance: ±2% Voltage Rating - DC: 2000V Voltage Rating - AC: Operating Temperature: -55 °C to +65 °C Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.914" H x 0.830" D Dimension mm: 48.6mm x 21.1mm
X375 0.15 2 4000	Data Sheet: X375	Application: Power Supply, Pulse Current Capacitance (µF): 0.15 Tolerance: ±2% Voltage Rating - DC: 4000V Voltage Rating - AC: Operating Temperature: -55 °C to +65 °C Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.914" H x 1.150" D Dimension mm: 48.6mm x 29.2mm
X375 0.15 2 6000	Data Sheet: X375	Application: Power Supply, Pulse Current Capacitance (µF): 0.15 Tolerance: ±2% Voltage Rating - DC: 6000V Voltage Rating - AC: Operating Temperature: -55 °C to +65 °C Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 2.664" H x 1.400" D Dimension mm: 67.7mm x 35.6mm
X375 0.15 20 2000	Data Sheet: X375	Application: Power Supply, Pulse Current Capacitance (µF): 0.15 Tolerance: ±20% Voltage Rating - DC: 2000V Voltage Rating - AC: Operating Temperature: -55 °C to +65 °C Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.914" H x 0.830" D Dimension mm: 48.6mm x 21.1mm
X375 0.15 20 4000	Data Sheet: X375	Application: Power Supply, Pulse Current Capacitance (µF): 0.15 Tolerance: ±20% Voltage Rating - DC: 4000V Voltage Rating - AC: Operating Temperature: -55 °C to +65 °C Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.914" H x 1.150" D Dimension mm: 48.6mm x 29.2mm
