0.022µF

Product Code	Data Sheet	Attributes
X368 0.022 20 400	Data Sheet: X368	Application: Power Supply, Pulse Current Capacitance (µF): 0.022 Tolerance: ±20% Voltage Rating - DC: 400V Operating Temperature: -40 °C to +85 °C IPeak: 0.3 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.551" H x 0.276" D Dimension mm: 14.0mm x 7.0mm
X368 0.022 20 630	Data Sheet: X368	Application: Power Supply, Pulse Current Capacitance (µF): 0.022 Tolerance: ±20% Voltage Rating - DC: 630V Operating Temperature: -40 °C to +85 °C IPeak: 0.4 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.551" H x 0.315" D Dimension mm: 14.0mm x 8.0mm
X368 0.022 5 250	Data Sheet: X368	Application: Power Supply, Pulse Current Capacitance (µF): 0.022 Tolerance: ±5% Voltage Rating - DC: 250V Operating Temperature: -40 °C to +85 °C IPeak: 0.2 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.551" H x 0.236" D Dimension mm: 14.0mm x 6.0mm
X368 0.022 5 400	Data Sheet: X368	Application: Power Supply, Pulse Current Capacitance (µF): 0.022 Tolerance: ±5% Voltage Rating - DC: 400V Operating Temperature: -40 °C to +85 °C IPeak: 0.3 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.551" H x 0.276" D Dimension mm: 14.0mm x 7.0mm
X368 0.022 5 630	Data Sheet: X368	Application: Power Supply, Pulse Current Capacitance (µF): 0.022 Tolerance: ±5% Voltage Rating - DC: 630V Operating Temperature: -40 °C to +85 °C IPeak: 0.4 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.551" H x 0.315" D Dimension mm: 14.0mm x 8.0mm
X375 0.022 1 10000	Data Sheet: X375	Application: Power Supply, Pulse Current Capacitance (µF): 0.022 Tolerance: ±1% Voltage Rating - DC: 10000V Voltage Rating - AC: Operating Temperature: -55 °C to +65 °C Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 2.407" H x 1.090" D Dimension mm: 61.1mm x 27.7mm
X375 0.022 1 16000	Data Sheet: X375	Application: Power Supply, Pulse Current Capacitance (µF): 0.022 Tolerance: ±1% Voltage Rating - DC: 16000V Voltage Rating - AC: Operating Temperature: -55 °C to +65 °C Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 3.219" H x 1.700" D Dimension mm: 81.8mm x 43.2mm
X375 0.022 1 2000	Data Sheet: X375	Application: Power Supply, Pulse Current Capacitance (µF): 0.022 Tolerance: ±1% Voltage Rating - DC: 2000V Voltage Rating - AC: Operating Temperature: -55 °C to +65 °C Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.284" H x 0.570" D Dimension mm: 32.6mm x 14.5mm
X375 0.022 1 4000	Data Sheet: X375	Application: Power Supply, Pulse Current Capacitance (µF): 0.022 Tolerance: ±1% Voltage Rating - DC: 4000V Voltage Rating - AC: Operating Temperature: -55 °C to +65 °C Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.914" H x 0.525" D Dimension mm: 48.6mm x 13.3mm
X375 0.022 1 6000	Data Sheet: X375	Application: Power Supply, Pulse Current Capacitance (µF): 0.022 Tolerance: ±1% Voltage Rating - DC: 6000V Voltage Rating - AC: Operating Temperature: -55 °C to +65 °C Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.664" H x 0.850" D Dimension mm: 42.3mm x 21.6mm
X375 0.022 1 8000	Data Sheet: X375	Application: Power Supply, Pulse Current Capacitance (µF): 0.022 Tolerance: ±1% Voltage Rating - DC: 8000V Voltage Rating - AC: Operating Temperature: -55 °C to +65 °C Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 2.034" H x 0.990" D Dimension mm: 51.7mm x 25.1mm
X375 0.022 10 10000	Data Sheet: X375	Application: Power Supply, Pulse Current Capacitance (µF): 0.022 Tolerance: ±10% Voltage Rating - DC: 10000V Voltage Rating - AC: Operating Temperature: -55 °C to +65 °C Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 2.407" H x 1.090" D Dimension mm: 61.1mm x 27.7mm
