±6% tolerance

Product Code	Data Sheet	Attributes
WME-RS 16 6 260	Data Sheet: WME-RS	Application: Filtering, Lighting, Motor Run Capacitance (µF): 16 Tolerance: ±6% Voltage Rating - AC: 260V Operating Temperature: -40 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Seamless Can Termination: 2-Tine, Quick Disconnect Dimension inches: 2.953" H x 1.595" D Dimension mm: 75.0mm x 40.5mm
WME-RS 16 6 400	Data Sheet: WME-RS	Application: Filtering, Lighting, Motor Run Capacitance (µF): 16 Tolerance: ±6% Voltage Rating - AC: 400V Operating Temperature: -40 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Seamless Can Termination: 2-Tine, Quick Disconnect Dimension inches: 3.937" H x 1.595" D Dimension mm: 100.0mm x 40.5mm
WME-RS 16 6 450	Data Sheet: WME-RS	Application: Filtering, Lighting, Motor Run Capacitance (µF): 16 Tolerance: ±6% Voltage Rating - AC: 450V Operating Temperature: -40 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Seamless Can Termination: 2-Tine, Quick Disconnect Dimension inches: 3.937" H x 1.595" D Dimension mm: 100.0mm x 40.5mm
WME-RS 18 6 260	Data Sheet: WME-RS	Application: Filtering, Lighting, Motor Run Capacitance (µF): 18 Tolerance: ±6% Voltage Rating - AC: 260V Operating Temperature: -40 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Seamless Can Termination: 2-Tine, Quick Disconnect Dimension inches: 2.953" H x 1.595" D Dimension mm: 75.0mm x 40.5mm
WME-RS 18 6 400	Data Sheet: WME-RS	Application: Filtering, Lighting, Motor Run Capacitance (µF): 18 Tolerance: ±6% Voltage Rating - AC: 400V Operating Temperature: -40 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Seamless Can Termination: 2-Tine, Quick Disconnect Dimension inches: 3.937" H x 1.595" D Dimension mm: 100.0mm x 40.5mm
WME-RS 18 6 450	Data Sheet: WME-RS	Application: Filtering, Lighting, Motor Run Capacitance (µF): 18 Tolerance: ±6% Voltage Rating - AC: 450V Operating Temperature: -40 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Seamless Can Termination: 2-Tine, Quick Disconnect Dimension inches: 3.937" H x 1.760" D Dimension mm: 100.0mm x 44.7mm
WME-RS 20 6 260	Data Sheet: WME-RS	Application: Filtering, Lighting, Motor Run Capacitance (µF): 20 Tolerance: ±6% Voltage Rating - AC: 260V Operating Temperature: -40 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Seamless Can Termination: 2-Tine, Quick Disconnect Dimension inches: 3.937" H x 1.595" D Dimension mm: 100.0mm x 40.5mm
WME-RS 20 6 400	Data Sheet: WME-RS	Application: Filtering, Lighting, Motor Run Capacitance (µF): 20 Tolerance: ±6% Voltage Rating - AC: 400V Operating Temperature: -40 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Seamless Can Termination: 2-Tine, Quick Disconnect Dimension inches: 3.937" H x 1.760" D Dimension mm: 100.0mm x 44.7mm
WME-RS 20 6 450	Data Sheet: WME-RS	Application: Filtering, Lighting, Motor Run Capacitance (µF): 20 Tolerance: ±6% Voltage Rating - AC: 450V Operating Temperature: -40 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Seamless Can Termination: 2-Tine, Quick Disconnect Dimension inches: 3.937" H x 1.760" D Dimension mm: 100.0mm x 44.7mm
WME-RS 22 6 260	Data Sheet: WME-RS	Application: Filtering, Lighting, Motor Run Capacitance (µF): 22 Tolerance: ±6% Voltage Rating - AC: 260V Operating Temperature: -40 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Seamless Can Termination: 2-Tine, Quick Disconnect Dimension inches: 3.937" H x 1.595" D Dimension mm: 100.0mm x 40.5mm
WME-RS 22 6 400	Data Sheet: WME-RS	Application: Filtering, Lighting, Motor Run Capacitance (µF): 22 Tolerance: ±6% Voltage Rating - AC: 400V Operating Temperature: -40 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Seamless Can Termination: 2-Tine, Quick Disconnect Dimension inches: 3.937" H x 1.760" D Dimension mm: 100.0mm x 44.7mm
WME-RS 22 6 450	Data Sheet: WME-RS	Application: Filtering, Lighting, Motor Run Capacitance (µF): 22 Tolerance: ±6% Voltage Rating - AC: 450V Operating Temperature: -40 °C to +80 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Seamless Can Termination: 2-Tine, Quick Disconnect Dimension inches: 4.921" H x 1.760" D Dimension mm: 125.0mm x 44.7mm
