X637

Product Code	Image	Data Sheet	Attributes
X637 5 10 220		Data Sheet: X637	Application: Power Supply, Pulse Current Capacitance (µF): 5 Tolerance: ±10% Voltage Rating - AC: 220V Operating Temperature: -55 °C to +85 °C IPeak: 21 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polyester film Dielectric Material: Polyester – Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.614" T x 1.354" H x 0.923" L Dimension mm: 15.6mm x 1.354" x 23.4mm
X637 5 10 250		Data Sheet: X637	Application: Power Supply, Pulse Current Capacitance (µF): 5 Tolerance: ±10% Voltage Rating - AC: 250V Operating Temperature: -55 °C to +85 °C IPeak: 16.5 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polyester film Dielectric Material: Polyester – Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.590" T x 1.794" H x 0.964" L Dimension mm: 15.0mm x 1.794" x 24.5mm
X637 5 20 220		Data Sheet: X637	Application: Power Supply, Pulse Current Capacitance (µF): 5 Tolerance: ±20% Voltage Rating - AC: 220V Operating Temperature: -55 °C to +85 °C IPeak: 21 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polyester film Dielectric Material: Polyester – Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.614" T x 1.354" H x 0.923" L Dimension mm: 15.6mm x 1.354" x 23.4mm
X637 5 20 250		Data Sheet: X637	Application: Power Supply, Pulse Current Capacitance (µF): 5 Tolerance: ±20% Voltage Rating - AC: 250V Operating Temperature: -55 °C to +85 °C IPeak: 16.5 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polyester film Dielectric Material: Polyester – Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.590" T x 1.794" H x 0.964" L Dimension mm: 15.0mm x 1.794" x 24.5mm
X637 5 5 220		Data Sheet: X637	Application: Power Supply, Pulse Current Capacitance (µF): 5 Tolerance: ±5% Voltage Rating - AC: 220V Operating Temperature: -55 °C to +85 °C IPeak: 21 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polyester film Dielectric Material: Polyester – Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.614" T x 1.354" H x 0.923" L Dimension mm: 15.6mm x 1.354" x 23.4mm
X637 5 5 250		Data Sheet: X637	Application: Power Supply, Pulse Current Capacitance (µF): 5 Tolerance: ±5% Voltage Rating - AC: 250V Operating Temperature: -55 °C to +85 °C IPeak: 16.5 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polyester film Dielectric Material: Polyester – Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.590" T x 1.794" H x 0.964" L Dimension mm: 15.0mm x 1.794" x 24.5mm
X637 6 10 220		Data Sheet: X637	Application: Power Supply, Pulse Current Capacitance (µF): 6 Tolerance: ±10% Voltage Rating - AC: 220V Operating Temperature: -55 °C to +85 °C IPeak: 18 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polyester film Dielectric Material: Polyester – Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.551" T x 1.794" H x 0.866" L Dimension mm: 14.0mm x 1.794" x 22.0mm
X637 6 10 250		Data Sheet: X637	Application: Power Supply, Pulse Current Capacitance (µF): 6 Tolerance: ±10% Voltage Rating - AC: 250V Operating Temperature: -55 °C to +85 °C IPeak: 19.8 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polyester film Dielectric Material: Polyester – Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.688" T x 1.794" H x 1.060" L Dimension mm: 17.5mm x 1.794" x 26.9mm
X637 6 20 220		Data Sheet: X637	Application: Power Supply, Pulse Current Capacitance (µF): 6 Tolerance: ±20% Voltage Rating - AC: 220V Operating Temperature: -55 °C to +85 °C IPeak: 18 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polyester film Dielectric Material: Polyester – Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.551" T x 1.794" H x 0.866" L Dimension mm: 14.0mm x 1.794" x 22.0mm
X637 6 20 250		Data Sheet: X637	Application: Power Supply, Pulse Current Capacitance (µF): 6 Tolerance: ±20% Voltage Rating - AC: 250V Operating Temperature: -55 °C to +85 °C IPeak: 19.8 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polyester film Dielectric Material: Polyester – Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.688" T x 1.794" H x 1.060" L Dimension mm: 17.5mm x 1.794" x 26.9mm
X637 6 5 220		Data Sheet: X637	Application: Power Supply, Pulse Current Capacitance (µF): 6 Tolerance: ±5% Voltage Rating - AC: 220V Operating Temperature: -55 °C to +85 °C IPeak: 18 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polyester film Dielectric Material: Polyester – Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.551" T x 1.794" H x 0.866" L Dimension mm: 14.0mm x 1.794" x 22.0mm
X637 6 5 250		Data Sheet: X637	Application: Power Supply, Pulse Current Capacitance (µF): 6 Tolerance: ±5% Voltage Rating - AC: 250V Operating Temperature: -55 °C to +85 °C IPeak: 19.8 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polyester film Dielectric Material: Polyester – Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.688" T x 1.794" H x 1.060" L Dimension mm: 17.5mm x 1.794" x 26.9mm

Showing 121–132 of 150 results
