X637

Product Code	Image	Data Sheet	Attributes
X637 3 10 220		Data Sheet: X637	Application: Power Supply, Pulse Current Capacitance (µF): 3 Tolerance: ±10% Voltage Rating - AC: 220V Operating Temperature: -55 °C to +85 °C IPeak: 12.6 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polyester film Dielectric Material: Polyester – Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.456" T x 1.354" H x 0.765" L Dimension mm: 11.6mm x 1.354" x 19.4mm
X637 3 10 250		Data Sheet: X637	Application: Power Supply, Pulse Current Capacitance (µF): 3 Tolerance: ±10% Voltage Rating - AC: 250V Operating Temperature: -55 °C to +85 °C IPeak: 15 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polyester film Dielectric Material: Polyester – Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.564" T x 1.354" H x 0.873" L Dimension mm: 14.3mm x 1.354" x 22.2mm
X637 3 20 220		Data Sheet: X637	Application: Power Supply, Pulse Current Capacitance (µF): 3 Tolerance: ±20% Voltage Rating - AC: 220V Operating Temperature: -55 °C to +85 °C IPeak: 12.6 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polyester film Dielectric Material: Polyester – Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.456" T x 1.354" H x 0.765" L Dimension mm: 11.6mm x 1.354" x 19.4mm
X637 3 20 250		Data Sheet: X637	Application: Power Supply, Pulse Current Capacitance (µF): 3 Tolerance: ±20% Voltage Rating - AC: 250V Operating Temperature: -55 °C to +85 °C IPeak: 15 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polyester film Dielectric Material: Polyester – Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.564" T x 1.354" H x 0.873" L Dimension mm: 14.3mm x 1.354" x 22.2mm
X637 3 5 220		Data Sheet: X637	Application: Power Supply, Pulse Current Capacitance (µF): 3 Tolerance: ±5% Voltage Rating - AC: 220V Operating Temperature: -55 °C to +85 °C IPeak: 12.6 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polyester film Dielectric Material: Polyester – Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.456" T x 1.354" H x 0.765" L Dimension mm: 11.6mm x 1.354" x 19.4mm
X637 3 5 250		Data Sheet: X637	Application: Power Supply, Pulse Current Capacitance (µF): 3 Tolerance: ±5% Voltage Rating - AC: 250V Operating Temperature: -55 °C to +85 °C IPeak: 15 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polyester film Dielectric Material: Polyester – Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.564" T x 1.354" H x 0.873" L Dimension mm: 14.3mm x 1.354" x 22.2mm
X637 4 10 220		Data Sheet: X637	Application: Power Supply, Pulse Current Capacitance (µF): 4 Tolerance: ±10% Voltage Rating - AC: 220V Operating Temperature: -55 °C to +85 °C IPeak: 16.8 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polyester film Dielectric Material: Polyester – Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.539" T x 1.354" H x 0.848" L Dimension mm: 13.7mm x 1.354" x 21.5mm
X637 4 10 250		Data Sheet: X637	Application: Power Supply, Pulse Current Capacitance (µF): 4 Tolerance: ±10% Voltage Rating - AC: 250V Operating Temperature: -55 °C to +85 °C IPeak: 20 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polyester film Dielectric Material: Polyester – Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.637" T x 1.354" H x 1.008" L Dimension mm: 16.2mm x 1.354" x 25.6mm
X637 4 20 220		Data Sheet: X637	Application: Power Supply, Pulse Current Capacitance (µF): 4 Tolerance: ±20% Voltage Rating - AC: 220V Operating Temperature: -55 °C to +85 °C IPeak: 16.8 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polyester film Dielectric Material: Polyester – Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.539" T x 1.354" H x 0.848" L Dimension mm: 13.7mm x 1.354" x 21.5mm
X637 4 20 250		Data Sheet: X637	Application: Power Supply, Pulse Current Capacitance (µF): 4 Tolerance: ±20% Voltage Rating - AC: 250V Operating Temperature: -55 °C to +85 °C IPeak: 20 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polyester film Dielectric Material: Polyester – Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.637" T x 1.354" H x 1.008" L Dimension mm: 16.2mm x 1.354" x 25.6mm
X637 4 5 220		Data Sheet: X637	Application: Power Supply, Pulse Current Capacitance (µF): 4 Tolerance: ±5% Voltage Rating - AC: 220V Operating Temperature: -55 °C to +85 °C IPeak: 16.8 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polyester film Dielectric Material: Polyester – Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.539" T x 1.354" H x 0.848" L Dimension mm: 13.7mm x 1.354" x 21.5mm
X637 4 5 250		Data Sheet: X637	Application: Power Supply, Pulse Current Capacitance (µF): 4 Tolerance: ±5% Voltage Rating - AC: 250V Operating Temperature: -55 °C to +85 °C IPeak: 20 Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polyester film Dielectric Material: Polyester – Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 0.637" T x 1.354" H x 1.008" L Dimension mm: 16.2mm x 1.354" x 25.6mm

Showing 109–120 of 150 results
