X387D

Product Code	Data Sheet	Attributes
X387D 35 5 370	Data Sheet: X387D	Application: Filtering, Lighting, Motor Run Capacitance (µF): 35 Tolerance: ±5% Voltage Rating - AC: 370V Operating Temperature: -40 °C to +70 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Oil Filled, Seamless Can Termination: 4-Tine, Quick Disconnect Dimension inches: 4.750" H x 3.660" D Dimension mm: 120.7mm x 93.0mm CAP (µF) - Secondary: 5
X387D 35 5 440	Data Sheet: X387D	Application: Filtering, Lighting, Motor Run Capacitance (µF): 35 Tolerance: ±5% Voltage Rating - AC: 440V Operating Temperature: -40 °C to +70 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Oil Filled, Seamless Can Termination: 4-Tine, Quick Disconnect Dimension inches: 4.750" H x 3.660" D Dimension mm: 120.7mm x 93.0mm CAP (µF) - Secondary: 5
X387D 35 6 370	Data Sheet: X387D	Application: Filtering, Lighting, Motor Run Capacitance (µF): 35 Tolerance: ±6% Voltage Rating - AC: 370V Operating Temperature: -40 °C to +70 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Oil Filled, Seamless Can Termination: 4-Tine, Quick Disconnect Dimension inches: 4.750" H x 3.660" D Dimension mm: 120.7mm x 93.0mm CAP (µF) - Secondary: 5
X387D 35 6 440	Data Sheet: X387D	Application: Filtering, Lighting, Motor Run Capacitance (µF): 35 Tolerance: ±6% Voltage Rating - AC: 440V Operating Temperature: -40 °C to +70 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Oil Filled, Seamless Can Termination: 4-Tine, Quick Disconnect Dimension inches: 4.750" H x 3.660" D Dimension mm: 120.7mm x 93.0mm CAP (µF) - Secondary: 5
X387D 40 10 370	Data Sheet: X387D	Application: Filtering, Lighting, Motor Run Capacitance (µF): 40 Tolerance: ±10% Voltage Rating - AC: 370V Operating Temperature: -40 °C to +70 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Oil Filled, Seamless Can Termination: 4-Tine, Quick Disconnect Dimension inches: 4.750" H x 3.660" D Dimension mm: 120.7mm x 93.0mm CAP (µF) - Secondary: 5
X387D 40 3 370	Data Sheet: X387D	Application: Filtering, Lighting, Motor Run Capacitance (µF): 40 Tolerance: ±3% Voltage Rating - AC: 370V Operating Temperature: -40 °C to +70 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Oil Filled, Seamless Can Termination: 4-Tine, Quick Disconnect Dimension inches: 4.750" H x 3.660" D Dimension mm: 120.7mm x 93.0mm CAP (µF) - Secondary: 5
X387D 40 5 370	Data Sheet: X387D	Application: Filtering, Lighting, Motor Run Capacitance (µF): 40 Tolerance: ±5% Voltage Rating - AC: 370V Operating Temperature: -40 °C to +70 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Oil Filled, Seamless Can Termination: 4-Tine, Quick Disconnect Dimension inches: 4.750" H x 3.660" D Dimension mm: 120.7mm x 93.0mm CAP (µF) - Secondary: 5
X387D 40 6 370	Data Sheet: X387D	Application: Filtering, Lighting, Motor Run Capacitance (µF): 40 Tolerance: ±6% Voltage Rating - AC: 370V Operating Temperature: -40 °C to +70 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Oil Filled, Seamless Can Termination: 4-Tine, Quick Disconnect Dimension inches: 4.750" H x 3.660" D Dimension mm: 120.7mm x 93.0mm CAP (µF) - Secondary: 5
X387D 45 10 370	Data Sheet: X387D	Application: Filtering, Lighting, Motor Run Capacitance (µF): 45 Tolerance: ±10% Voltage Rating - AC: 370V Operating Temperature: -40 °C to +70 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Oil Filled, Seamless Can Termination: 4-Tine, Quick Disconnect Dimension inches: 4.750" H x 3.660" D Dimension mm: 120.7mm x 93.0mm CAP (µF) - Secondary: 5
X387D 45 3 370	Data Sheet: X387D	Application: Filtering, Lighting, Motor Run Capacitance (µF): 45 Tolerance: ±3% Voltage Rating - AC: 370V Operating Temperature: -40 °C to +70 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Oil Filled, Seamless Can Termination: 4-Tine, Quick Disconnect Dimension inches: 4.750" H x 3.660" D Dimension mm: 120.7mm x 93.0mm CAP (µF) - Secondary: 5
X387D 45 5 370	Data Sheet: X387D	Application: Filtering, Lighting, Motor Run Capacitance (µF): 45 Tolerance: ±5% Voltage Rating - AC: 370V Operating Temperature: -40 °C to +70 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Oil Filled, Seamless Can Termination: 4-Tine, Quick Disconnect Dimension inches: 4.750" H x 3.660" D Dimension mm: 120.7mm x 93.0mm CAP (µF) - Secondary: 5
X387D 45 6 370	Data Sheet: X387D	Application: Filtering, Lighting, Motor Run Capacitance (µF): 45 Tolerance: ±6% Voltage Rating - AC: 370V Operating Temperature: -40 °C to +70 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Oil Filled, Seamless Can Termination: 4-Tine, Quick Disconnect Dimension inches: 4.750" H x 3.660" D Dimension mm: 120.7mm x 93.0mm CAP (µF) - Secondary: 5
