X335

Product Code	Image	Data Sheet	Attributes
X335 30 2 63		Data Sheet: X335	Application: Power Supply, Pulse Current Capacitance (µF): 30 Tolerance: ±2% Voltage Rating - DC: 100V Voltage Rating - AC: 63V Operating Temperature: -55 °C to +90 °C ESR: 8 mOhms IPeak: 78 Irms (Arms): Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 2.344" H x 1.325" D Dimension mm: 59.5mm x 33.7mm ESR kHz: 100kHz
X335 30 20 63		Data Sheet: X335	Application: Power Supply, Pulse Current Capacitance (µF): 30 Tolerance: ±20% Voltage Rating - DC: 100V Voltage Rating - AC: 63V Operating Temperature: -55 °C to +90 °C ESR: 8 mOhms IPeak: 78 Irms (Arms): Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 2.344" H x 1.325" D Dimension mm: 59.5mm x 33.7mm ESR kHz: 100kHz
X335 30 5 63		Data Sheet: X335	Application: Power Supply, Pulse Current Capacitance (µF): 30 Tolerance: ±5% Voltage Rating - DC: 100V Voltage Rating - AC: 63V Operating Temperature: -55 °C to +90 °C ESR: 8 mOhms IPeak: 78 Irms (Arms): Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 2.344" H x 1.325" D Dimension mm: 59.5mm x 33.7mm ESR kHz: 100kHz
X335 5 1 135		Data Sheet: X335	Application: Power Supply, Pulse Current Capacitance (µF): 5 Tolerance: ±1% Voltage Rating - DC: 200V Voltage Rating - AC: 135V Operating Temperature: -55 °C to +90 °C ESR: 13 mOhms IPeak: 26 Irms (Arms): Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.844" H x 0.969" D Dimension mm: 46.8mm x 24.6mm ESR kHz: 100kHz
X335 5 1 240		Data Sheet: X335	Application: Power Supply, Pulse Current Capacitance (µF): 5 Tolerance: ±1% Voltage Rating - DC: 400V Voltage Rating - AC: 240V Operating Temperature: -55 °C to +90 °C ESR: 13 mOhms IPeak: 7 Irms (Arms): Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 2.344" H x 1.109" D Dimension mm: 59.5mm x 28.2mm ESR kHz: 100kHz
X335 5 1 63		Data Sheet: X335	Application: Power Supply, Pulse Current Capacitance (µF): 5 Tolerance: ±1% Voltage Rating - DC: 100V Voltage Rating - AC: 63V Operating Temperature: -55 °C to +90 °C ESR: 13 mOhms IPeak: 25 Irms (Arms): Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.344" H x 0.809" D Dimension mm: 34.1mm x 20.5mm ESR kHz: 100kHz
X335 5 10 135		Data Sheet: X335	Application: Power Supply, Pulse Current Capacitance (µF): 5 Tolerance: ±10% Voltage Rating - DC: 200V Voltage Rating - AC: 135V Operating Temperature: -55 °C to +90 °C ESR: 13 mOhms IPeak: 26 Irms (Arms): Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.844" H x 0.969" D Dimension mm: 46.8mm x 24.6mm ESR kHz: 100kHz
X335 5 10 240		Data Sheet: X335	Application: Power Supply, Pulse Current Capacitance (µF): 5 Tolerance: ±10% Voltage Rating - DC: 400V Voltage Rating - AC: 240V Operating Temperature: -55 °C to +90 °C ESR: 13 mOhms IPeak: 7 Irms (Arms): Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 2.344" H x 1.109" D Dimension mm: 59.5mm x 28.2mm ESR kHz: 100kHz
X335 5 10 63		Data Sheet: X335	Application: Power Supply, Pulse Current Capacitance (µF): 5 Tolerance: ±10% Voltage Rating - DC: 100V Voltage Rating - AC: 63V Operating Temperature: -55 °C to +90 °C ESR: 13 mOhms IPeak: 25 Irms (Arms): Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.344" H x 0.809" D Dimension mm: 34.1mm x 20.5mm ESR kHz: 100kHz
X335 5 2 135		Data Sheet: X335	Application: Power Supply, Pulse Current Capacitance (µF): 5 Tolerance: ±2% Voltage Rating - DC: 200V Voltage Rating - AC: 135V Operating Temperature: -55 °C to +90 °C ESR: 13 mOhms IPeak: 26 Irms (Arms): Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.844" H x 0.969" D Dimension mm: 46.8mm x 24.6mm ESR kHz: 100kHz
X335 5 2 240		Data Sheet: X335	Application: Power Supply, Pulse Current Capacitance (µF): 5 Tolerance: ±2% Voltage Rating - DC: 400V Voltage Rating - AC: 240V Operating Temperature: -55 °C to +90 °C ESR: 13 mOhms IPeak: 7 Irms (Arms): Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 2.344" H x 1.109" D Dimension mm: 59.5mm x 28.2mm ESR kHz: 100kHz
X335 5 2 63		Data Sheet: X335	Application: Power Supply, Pulse Current Capacitance (µF): 5 Tolerance: ±2% Voltage Rating - DC: 100V Voltage Rating - AC: 63V Operating Temperature: -55 °C to +90 °C ESR: 13 mOhms IPeak: 25 Irms (Arms): Lifecycle @ Rated Temp & Voltage: 30,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Tape Wrap and Epoxy Fill Termination: Solid Wire Dimension inches: 1.344" H x 0.809" D Dimension mm: 34.1mm x 20.5mm ESR kHz: 100kHz

Showing 73–84 of 90 results
