X300

Product Code	Data Sheet	Attributes
X300 17 10 200	Data Sheet: X300	Application: Power Supply Capacitance (µF): 17 Tolerance: ±10% Voltage Rating - DC: 200V Voltage Rating - AC: Operating Temperature: -55 °C to +85 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Self-Encased w/ PP or PE Termination: Solid Wire Dimension inches: 1.574" H x 1.374" D Dimension mm: 40.0mm x 34.9mm
X300 17 20 200	Data Sheet: X300	Application: Power Supply Capacitance (µF): 17 Tolerance: ±20% Voltage Rating - DC: 200V Voltage Rating - AC: Operating Temperature: -55 °C to +85 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Self-Encased w/ PP or PE Termination: Solid Wire Dimension inches: 1.574" H x 1.374" D Dimension mm: 40.0mm x 34.9mm
X300 17 5 200	Data Sheet: X300	Application: Power Supply Capacitance (µF): 17 Tolerance: ±5% Voltage Rating - DC: 200V Voltage Rating - AC: Operating Temperature: -55 °C to +85 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Self-Encased w/ PP or PE Termination: Solid Wire Dimension inches: 1.574" H x 1.374" D Dimension mm: 40.0mm x 34.9mm
X300 18 10 200	Data Sheet: X300	Application: Power Supply Capacitance (µF): 18 Tolerance: ±10% Voltage Rating - DC: 200V Voltage Rating - AC: Operating Temperature: -55 °C to +85 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Self-Encased w/ PP or PE Termination: Solid Wire Dimension inches: 1.574" H x 1.412" D Dimension mm: 40.0mm x 35.9mm
X300 18 20 200	Data Sheet: X300	Application: Power Supply Capacitance (µF): 18 Tolerance: ±20% Voltage Rating - DC: 200V Voltage Rating - AC: Operating Temperature: -55 °C to +85 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Self-Encased w/ PP or PE Termination: Solid Wire Dimension inches: 1.574" H x 1.412" D Dimension mm: 40.0mm x 35.9mm
X300 18 5 200	Data Sheet: X300	Application: Power Supply Capacitance (µF): 18 Tolerance: ±5% Voltage Rating - DC: 200V Voltage Rating - AC: Operating Temperature: -55 °C to +85 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Self-Encased w/ PP or PE Termination: Solid Wire Dimension inches: 1.574" H x 1.412" D Dimension mm: 40.0mm x 35.9mm
X300 19 10 200	Data Sheet: X300	Application: Power Supply Capacitance (µF): 19 Tolerance: ±10% Voltage Rating - DC: 200V Voltage Rating - AC: Operating Temperature: -55 °C to +85 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Self-Encased w/ PP or PE Termination: Solid Wire Dimension inches: 1.574" H x 1.450" D Dimension mm: 40.0mm x 36.8mm
X300 19 20 200	Data Sheet: X300	Application: Power Supply Capacitance (µF): 19 Tolerance: ±20% Voltage Rating - DC: 200V Voltage Rating - AC: Operating Temperature: -55 °C to +85 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Self-Encased w/ PP or PE Termination: Solid Wire Dimension inches: 1.574" H x 1.450" D Dimension mm: 40.0mm x 36.8mm
X300 19 5 200	Data Sheet: X300	Application: Power Supply Capacitance (µF): 19 Tolerance: ±5% Voltage Rating - DC: 200V Voltage Rating - AC: Operating Temperature: -55 °C to +85 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Self-Encased w/ PP or PE Termination: Solid Wire Dimension inches: 1.574" H x 1.450" D Dimension mm: 40.0mm x 36.8mm
X300 2 10 200	Data Sheet: X300	Application: Power Supply Capacitance (µF): 2 Tolerance: ±10% Voltage Rating - DC: 200V Voltage Rating - AC: Operating Temperature: -55 °C to +85 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Self-Encased w/ PP or PE Termination: Solid Wire Dimension inches: 1.574" H x 0.538" D Dimension mm: 40.0mm x 13.7mm
X300 2 20 200	Data Sheet: X300	Application: Power Supply Capacitance (µF): 2 Tolerance: ±20% Voltage Rating - DC: 200V Voltage Rating - AC: Operating Temperature: -55 °C to +85 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Self-Encased w/ PP or PE Termination: Solid Wire Dimension inches: 1.574" H x 0.538" D Dimension mm: 40.0mm x 13.7mm
X300 2 5 200	Data Sheet: X300	Application: Power Supply Capacitance (µF): 2 Tolerance: ±5% Voltage Rating - DC: 200V Voltage Rating - AC: Operating Temperature: -55 °C to +85 °C Lifecycle @ Rated Temp & Voltage: 60,000 hrs Construction: non-inductive wound metallized polypropylene film Dielectric Material: Polypropylene - Metallized Case: Self-Encased w/ PP or PE Termination: Solid Wire Dimension inches: 1.574" H x 0.538" D Dimension mm: 40.0mm x 13.7mm
