HCO

Product Code	Data Sheet	Attributes
HCO 60 +10 to -5 600	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 60 Tolerance: +10% to -5% Voltage Rating - AC: 600V Operating Temperature: -40 °C to +70 °C ESR: 3.8 mOhms Vsurge: 1290 ISurge: 3.1 IPeak: 0.3 Irms (Arms): 14 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 6.000" H x 3.346" D Dimension mm: 152.0mm x 85.0mm ESR kHz: 60Hz
HCO 60 10 600	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 60 Tolerance: ±10% Voltage Rating - AC: 600V Operating Temperature: -40 °C to +70 °C ESR: 3.8 mOhms Vsurge: 1290 ISurge: 3.1 IPeak: 0.3 Irms (Arms): 14 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 6.000" H x 3.346" D Dimension mm: 152.0mm x 85.0mm ESR kHz: 60Hz
HCO 60 3 600	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 60 Tolerance: ±3% Voltage Rating - AC: 600V Operating Temperature: -40 °C to +70 °C ESR: 3.8 mOhms Vsurge: 1290 ISurge: 3.1 IPeak: 0.3 Irms (Arms): 14 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 6.000" H x 3.346" D Dimension mm: 152.0mm x 85.0mm ESR kHz: 60Hz
HCO 60 5 600	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 60 Tolerance: ±5% Voltage Rating - AC: 600V Operating Temperature: -40 °C to +70 °C ESR: 3.8 mOhms Vsurge: 1290 ISurge: 3.1 IPeak: 0.3 Irms (Arms): 14 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 6.000" H x 3.346" D Dimension mm: 152.0mm x 85.0mm ESR kHz: 60Hz
HCO 600 +10 to -5 250	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 600 Tolerance: +10% to -5% Voltage Rating - AC: 250V Operating Temperature: -40 °C to +70 °C ESR: 2.1 mOhms Vsurge: 538 ISurge: 5 IPeak: 1.1 Irms (Arms): 56 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 7.000" H x 3.937" D Dimension mm: 178.0mm x 100.0mm ESR kHz: 60Hz
HCO 600 10 250	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 600 Tolerance: ±10% Voltage Rating - AC: 250V Operating Temperature: -40 °C to +70 °C ESR: 2.1 mOhms Vsurge: 538 ISurge: 5 IPeak: 1.1 Irms (Arms): 56 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 7.000" H x 3.937" D Dimension mm: 178.0mm x 100.0mm ESR kHz: 60Hz
HCO 600 3 250	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 600 Tolerance: ±3% Voltage Rating - AC: 250V Operating Temperature: -40 °C to +70 °C ESR: 2.1 mOhms Vsurge: 538 ISurge: 5 IPeak: 1.1 Irms (Arms): 56 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 7.000" H x 3.937" D Dimension mm: 178.0mm x 100.0mm ESR kHz: 60Hz
HCO 600 5 250	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 600 Tolerance: ±5% Voltage Rating - AC: 250V Operating Temperature: -40 °C to +70 °C ESR: 2.1 mOhms Vsurge: 538 ISurge: 5 IPeak: 1.1 Irms (Arms): 56 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 7.000" H x 3.937" D Dimension mm: 178.0mm x 100.0mm ESR kHz: 60Hz
HCO 65 +10 to -5 400	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 65 Tolerance: +10% to -5% Voltage Rating - AC: 400V Operating Temperature: -40 °C to +70 °C ESR: 7.6 mOhms Vsurge: 860 ISurge: 2 IPeak: 0.2 Irms (Arms): 10 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 4.250" H x 2.953" D Dimension mm: 108.0mm x 75.0mm ESR kHz: 60Hz
HCO 65 10 400	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 65 Tolerance: ±10% Voltage Rating - AC: 400V Operating Temperature: -40 °C to +70 °C ESR: 7.6 mOhms Vsurge: 860 ISurge: 2 IPeak: 0.2 Irms (Arms): 10 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 4.250" H x 2.953" D Dimension mm: 108.0mm x 75.0mm ESR kHz: 60Hz
HCO 65 3 400	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 65 Tolerance: ±3% Voltage Rating - AC: 400V Operating Temperature: -40 °C to +70 °C ESR: 7.6 mOhms Vsurge: 860 ISurge: 2 IPeak: 0.2 Irms (Arms): 10 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 4.250" H x 2.953" D Dimension mm: 108.0mm x 75.0mm ESR kHz: 60Hz
HCO 65 5 400	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 65 Tolerance: ±5% Voltage Rating - AC: 400V Operating Temperature: -40 °C to +70 °C ESR: 7.6 mOhms Vsurge: 860 ISurge: 2 IPeak: 0.2 Irms (Arms): 10 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 4.250" H x 2.953" D Dimension mm: 108.0mm x 75.0mm ESR kHz: 60Hz
