HCO

Product Code	Data Sheet	Attributes
HCO 40 +10 to -5 690	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 40 Tolerance: +10% to -5% Voltage Rating - AC: 690V Operating Temperature: -40 °C to +70 °C ESR: 5.3 mOhms Vsurge: 1484 ISurge: 1.4 IPeak: 0.2 Irms (Arms): 11 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 6.000" H x 3.346" D Dimension mm: 152.0mm x 85.0mm ESR kHz: 60Hz
HCO 40 10 690	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 40 Tolerance: ±10% Voltage Rating - AC: 690V Operating Temperature: -40 °C to +70 °C ESR: 5.3 mOhms Vsurge: 1484 ISurge: 1.4 IPeak: 0.2 Irms (Arms): 11 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 6.000" H x 3.346" D Dimension mm: 152.0mm x 85.0mm ESR kHz: 60Hz
HCO 40 3 690	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 40 Tolerance: ±3% Voltage Rating - AC: 690V Operating Temperature: -40 °C to +70 °C ESR: 5.3 mOhms Vsurge: 1484 ISurge: 1.4 IPeak: 0.2 Irms (Arms): 11 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 6.000" H x 3.346" D Dimension mm: 152.0mm x 85.0mm ESR kHz: 60Hz
HCO 40 5 690	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 40 Tolerance: ±5% Voltage Rating - AC: 690V Operating Temperature: -40 °C to +70 °C ESR: 5.3 mOhms Vsurge: 1484 ISurge: 1.4 IPeak: 0.2 Irms (Arms): 11 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 6.000" H x 3.346" D Dimension mm: 152.0mm x 85.0mm ESR kHz: 60Hz
HCO 450 +10 to -5 400	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 450 Tolerance: +10% to -5% Voltage Rating - AC: 400V Operating Temperature: -40 °C to +70 °C ESR: 2.7 mOhms Vsurge: 860 ISurge: 5 IPeak: 1.4 Irms (Arms): 70 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 8.000" H x 4.567" D Dimension mm: 203.0mm x 116.0mm ESR kHz: 60Hz
HCO 450 10 400	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 450 Tolerance: ±10% Voltage Rating - AC: 400V Operating Temperature: -40 °C to +70 °C ESR: 2.7 mOhms Vsurge: 860 ISurge: 5 IPeak: 1.4 Irms (Arms): 70 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 8.000" H x 4.567" D Dimension mm: 203.0mm x 116.0mm ESR kHz: 60Hz
HCO 450 3 400	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 450 Tolerance: ±3% Voltage Rating - AC: 400V Operating Temperature: -40 °C to +70 °C ESR: 2.7 mOhms Vsurge: 860 ISurge: 5 IPeak: 1.4 Irms (Arms): 70 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 8.000" H x 4.567" D Dimension mm: 203.0mm x 116.0mm ESR kHz: 60Hz
HCO 450 5 400	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 450 Tolerance: ±5% Voltage Rating - AC: 400V Operating Temperature: -40 °C to +70 °C ESR: 2.7 mOhms Vsurge: 860 ISurge: 5 IPeak: 1.4 Irms (Arms): 70 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 8.000" H x 4.567" D Dimension mm: 203.0mm x 116.0mm ESR kHz: 60Hz
HCO 50 +10 to -5 480	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 50 Tolerance: +10% to -5% Voltage Rating - AC: 480V Operating Temperature: -40 °C to +70 °C ESR: 9.3 mOhms Vsurge: 1023 ISurge: 1.8 IPeak: 0.2 Irms (Arms): 9 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 4.250" H x 2.953" D Dimension mm: 108.0mm x 75.0mm ESR kHz: 60Hz
HCO 50 10 480	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 50 Tolerance: ±10% Voltage Rating - AC: 480V Operating Temperature: -40 °C to +70 °C ESR: 9.3 mOhms Vsurge: 1023 ISurge: 1.8 IPeak: 0.2 Irms (Arms): 9 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 4.250" H x 2.953" D Dimension mm: 108.0mm x 75.0mm ESR kHz: 60Hz
HCO 50 3 480	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 50 Tolerance: ±3% Voltage Rating - AC: 480V Operating Temperature: -40 °C to +70 °C ESR: 9.3 mOhms Vsurge: 1023 ISurge: 1.8 IPeak: 0.2 Irms (Arms): 9 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 4.250" H x 2.953" D Dimension mm: 108.0mm x 75.0mm ESR kHz: 60Hz
HCO 50 5 480	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 50 Tolerance: ±5% Voltage Rating - AC: 480V Operating Temperature: -40 °C to +70 °C ESR: 9.3 mOhms Vsurge: 1023 ISurge: 1.8 IPeak: 0.2 Irms (Arms): 9 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 4.250" H x 2.953" D Dimension mm: 108.0mm x 75.0mm ESR kHz: 60Hz
