HCO

Product Code	Data Sheet	Attributes
HCO 340 +10 to -5 480	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 340 Tolerance: +10% to -5% Voltage Rating - AC: 480V Operating Temperature: -40 °C to +70 °C ESR: 3.3 mOhms Vsurge: 1023 ISurge: 5 IPeak: 1.2 Irms (Arms): 62 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 8.000" H x 4.567" D Dimension mm: 203.0mm x 116.0mm ESR kHz: 60Hz
HCO 340 +10 to -5 525	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 340 Tolerance: +10% to -5% Voltage Rating - AC: 525V Operating Temperature: -40 °C to +70 °C ESR: 4.1 mOhms Vsurge: 1129 ISurge: 4.5 IPeak: 1.4 Irms (Arms): 68 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 9.650" H x 5.354" D Dimension mm: 245.0mm x 136.0mm ESR kHz: 60Hz
HCO 340 10 480	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 340 Tolerance: ±10% Voltage Rating - AC: 480V Operating Temperature: -40 °C to +70 °C ESR: 3.3 mOhms Vsurge: 1023 ISurge: 5 IPeak: 1.2 Irms (Arms): 62 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 8.000" H x 4.567" D Dimension mm: 203.0mm x 116.0mm ESR kHz: 60Hz
HCO 340 10 525	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 340 Tolerance: ±10% Voltage Rating - AC: 525V Operating Temperature: -40 °C to +70 °C ESR: 4.1 mOhms Vsurge: 1129 ISurge: 4.5 IPeak: 1.4 Irms (Arms): 68 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 9.650" H x 5.354" D Dimension mm: 245.0mm x 136.0mm ESR kHz: 60Hz
HCO 340 3 480	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 340 Tolerance: ±3% Voltage Rating - AC: 480V Operating Temperature: -40 °C to +70 °C ESR: 3.3 mOhms Vsurge: 1023 ISurge: 5 IPeak: 1.2 Irms (Arms): 62 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 8.000" H x 4.567" D Dimension mm: 203.0mm x 116.0mm ESR kHz: 60Hz
HCO 340 3 525	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 340 Tolerance: ±3% Voltage Rating - AC: 525V Operating Temperature: -40 °C to +70 °C ESR: 4.1 mOhms Vsurge: 1129 ISurge: 4.5 IPeak: 1.4 Irms (Arms): 68 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 9.650" H x 5.354" D Dimension mm: 245.0mm x 136.0mm ESR kHz: 60Hz
HCO 340 5 480	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 340 Tolerance: ±5% Voltage Rating - AC: 480V Operating Temperature: -40 °C to +70 °C ESR: 3.3 mOhms Vsurge: 1023 ISurge: 5 IPeak: 1.2 Irms (Arms): 62 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 8.000" H x 4.567" D Dimension mm: 203.0mm x 116.0mm ESR kHz: 60Hz
HCO 340 5 525	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 340 Tolerance: ±5% Voltage Rating - AC: 525V Operating Temperature: -40 °C to +70 °C ESR: 4.1 mOhms Vsurge: 1129 ISurge: 4.5 IPeak: 1.4 Irms (Arms): 68 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 9.650" H x 5.354" D Dimension mm: 245.0mm x 136.0mm ESR kHz: 60Hz
HCO 38 +10 to -5 525	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 38 Tolerance: +10% to -5% Voltage Rating - AC: 525V Operating Temperature: -40 °C to +70 °C ESR: 12 mOhms Vsurge: 1129 ISurge: 1.6 IPeak: 0.2 Irms (Arms): 7.6 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 4.250" H x 2.953" D Dimension mm: 108.0mm x 75.0mm ESR kHz: 60Hz
HCO 38 10 525	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 38 Tolerance: ±10% Voltage Rating - AC: 525V Operating Temperature: -40 °C to +70 °C ESR: 12 mOhms Vsurge: 1129 ISurge: 1.6 IPeak: 0.2 Irms (Arms): 7.6 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 4.250" H x 2.953" D Dimension mm: 108.0mm x 75.0mm ESR kHz: 60Hz
HCO 38 3 525	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 38 Tolerance: ±3% Voltage Rating - AC: 525V Operating Temperature: -40 °C to +70 °C ESR: 12 mOhms Vsurge: 1129 ISurge: 1.6 IPeak: 0.2 Irms (Arms): 7.6 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 4.250" H x 2.953" D Dimension mm: 108.0mm x 75.0mm ESR kHz: 60Hz
HCO 38 5 525	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 38 Tolerance: ±5% Voltage Rating - AC: 525V Operating Temperature: -40 °C to +70 °C ESR: 12 mOhms Vsurge: 1129 ISurge: 1.6 IPeak: 0.2 Irms (Arms): 7.6 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 4.250" H x 2.953" D Dimension mm: 108.0mm x 75.0mm ESR kHz: 60Hz
