HCO

Product Code	Data Sheet	Attributes
HCO 265 +10 to -5 525	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 265 Tolerance: +10% to -5% Voltage Rating - AC: 525V Operating Temperature: -40 °C to +70 °C ESR: 4 mOhms Vsurge: 1129 ISurge: 4.5 IPeak: 1 Irms (Arms): 52 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 8.000" H x 4.567" D Dimension mm: 203.0mm x 116.0mm ESR kHz: 60Hz
HCO 265 10 525	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 265 Tolerance: ±10% Voltage Rating - AC: 525V Operating Temperature: -40 °C to +70 °C ESR: 4 mOhms Vsurge: 1129 ISurge: 4.5 IPeak: 1 Irms (Arms): 52 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 8.000" H x 4.567" D Dimension mm: 203.0mm x 116.0mm ESR kHz: 60Hz
HCO 265 3 525	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 265 Tolerance: ±3% Voltage Rating - AC: 525V Operating Temperature: -40 °C to +70 °C ESR: 4 mOhms Vsurge: 1129 ISurge: 4.5 IPeak: 1 Irms (Arms): 52 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 8.000" H x 4.567" D Dimension mm: 203.0mm x 116.0mm ESR kHz: 60Hz
HCO 265 5 525	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 265 Tolerance: ±5% Voltage Rating - AC: 525V Operating Temperature: -40 °C to +70 °C ESR: 4 mOhms Vsurge: 1129 ISurge: 4.5 IPeak: 1 Irms (Arms): 52 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 8.000" H x 4.567" D Dimension mm: 203.0mm x 116.0mm ESR kHz: 60Hz
HCO 300 +10 to -5 600	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 300 Tolerance: +10% to -5% Voltage Rating - AC: 600V Operating Temperature: -40 °C to +70 °C ESR: 1.8 mOhms Vsurge: 1290 ISurge: 5 IPeak: 1.4 Irms (Arms): 68 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 9.650" H x 5.354" D Dimension mm: 245.0mm x 136.0mm ESR kHz: 60Hz
HCO 300 10 600	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 300 Tolerance: ±10% Voltage Rating - AC: 600V Operating Temperature: -40 °C to +70 °C ESR: 1.8 mOhms Vsurge: 1290 ISurge: 5 IPeak: 1.4 Irms (Arms): 68 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 9.650" H x 5.354" D Dimension mm: 245.0mm x 136.0mm ESR kHz: 60Hz
HCO 300 3 600	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 300 Tolerance: ±3% Voltage Rating - AC: 600V Operating Temperature: -40 °C to +70 °C ESR: 1.8 mOhms Vsurge: 1290 ISurge: 5 IPeak: 1.4 Irms (Arms): 68 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 9.650" H x 5.354" D Dimension mm: 245.0mm x 136.0mm ESR kHz: 60Hz
HCO 300 5 600	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 300 Tolerance: ±5% Voltage Rating - AC: 600V Operating Temperature: -40 °C to +70 °C ESR: 1.8 mOhms Vsurge: 1290 ISurge: 5 IPeak: 1.4 Irms (Arms): 68 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 9.650" H x 5.354" D Dimension mm: 245.0mm x 136.0mm ESR kHz: 60Hz
HCO 325 +10 to -5 250	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 325 Tolerance: +10% to -5% Voltage Rating - AC: 250V Operating Temperature: -40 °C to +70 °C ESR: 2.9 mOhms Vsurge: 538 ISurge: 5 IPeak: 0.6 Irms (Arms): 31 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 6.000" H x 3.346" D Dimension mm: 152.0mm x 85.0mm ESR kHz: 60Hz
HCO 325 10 250	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 325 Tolerance: ±10% Voltage Rating - AC: 250V Operating Temperature: -40 °C to +70 °C ESR: 2.9 mOhms Vsurge: 538 ISurge: 5 IPeak: 0.6 Irms (Arms): 31 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 6.000" H x 3.346" D Dimension mm: 152.0mm x 85.0mm ESR kHz: 60Hz
HCO 325 3 250	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 325 Tolerance: ±3% Voltage Rating - AC: 250V Operating Temperature: -40 °C to +70 °C ESR: 2.9 mOhms Vsurge: 538 ISurge: 5 IPeak: 0.6 Irms (Arms): 31 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 6.000" H x 3.346" D Dimension mm: 152.0mm x 85.0mm ESR kHz: 60Hz
HCO 325 5 250	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 325 Tolerance: ±5% Voltage Rating - AC: 250V Operating Temperature: -40 °C to +70 °C ESR: 2.9 mOhms Vsurge: 538 ISurge: 5 IPeak: 0.6 Irms (Arms): 31 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Oil Termination: Threaded Stud/Insert Dimension inches: 6.000" H x 3.346" D Dimension mm: 152.0mm x 85.0mm ESR kHz: 60Hz
