HCG

Product Code	Data Sheet	Attributes
HCG 325 +10 to -5 250	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 325 Tolerance: +10% to -5% Voltage Rating - AC: 250V Operating Temperature: -40 °C to +70 °C ESR: 2.9 mOhms Vsurge: 538 ISurge: 5 IPeak: 0.6 Irms (Arms): 31 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Gel Termination: Threaded Stud/Insert Dimension inches: 6.000" H x 3.346" D Dimension mm: 152.0mm x 85.0mm ESR kHz: 60Hz
HCG 325 10 250	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 325 Tolerance: ±10% Voltage Rating - AC: 250V Operating Temperature: -40 °C to +70 °C ESR: 2.9 mOhms Vsurge: 538 ISurge: 5 IPeak: 0.6 Irms (Arms): 31 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Gel Termination: Threaded Stud/Insert Dimension inches: 6.000" H x 3.346" D Dimension mm: 152.0mm x 85.0mm ESR kHz: 60Hz
HCG 325 3 250	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 325 Tolerance: ±3% Voltage Rating - AC: 250V Operating Temperature: -40 °C to +70 °C ESR: 2.9 mOhms Vsurge: 538 ISurge: 5 IPeak: 0.6 Irms (Arms): 31 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Gel Termination: Threaded Stud/Insert Dimension inches: 6.000" H x 3.346" D Dimension mm: 152.0mm x 85.0mm ESR kHz: 60Hz
HCG 325 5 250	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 325 Tolerance: ±5% Voltage Rating - AC: 250V Operating Temperature: -40 °C to +70 °C ESR: 2.9 mOhms Vsurge: 538 ISurge: 5 IPeak: 0.6 Irms (Arms): 31 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Gel Termination: Threaded Stud/Insert Dimension inches: 6.000" H x 3.346" D Dimension mm: 152.0mm x 85.0mm ESR kHz: 60Hz
HCG 340 +10 to -5 525	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 340 Tolerance: +10% to -5% Voltage Rating - AC: 525V Operating Temperature: -40 °C to +70 °C ESR: 1.7 mOhms Vsurge: 1129 ISurge: 5 IPeak: 1.4 Irms (Arms): 68 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Gel Termination: Threaded Stud/Insert Dimension inches: 9.650" H x 5.354" D Dimension mm: 245.0mm x 136.0mm ESR kHz: 60Hz
HCG 340 10 525	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 340 Tolerance: ±10% Voltage Rating - AC: 525V Operating Temperature: -40 °C to +70 °C ESR: 1.7 mOhms Vsurge: 1129 ISurge: 5 IPeak: 1.4 Irms (Arms): 68 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Gel Termination: Threaded Stud/Insert Dimension inches: 9.650" H x 5.354" D Dimension mm: 245.0mm x 136.0mm ESR kHz: 60Hz
HCG 340 3 525	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 340 Tolerance: ±3% Voltage Rating - AC: 525V Operating Temperature: -40 °C to +70 °C ESR: 1.7 mOhms Vsurge: 1129 ISurge: 5 IPeak: 1.4 Irms (Arms): 68 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Gel Termination: Threaded Stud/Insert Dimension inches: 9.650" H x 5.354" D Dimension mm: 245.0mm x 136.0mm ESR kHz: 60Hz
HCG 340 5 525	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 340 Tolerance: ±5% Voltage Rating - AC: 525V Operating Temperature: -40 °C to +70 °C ESR: 1.7 mOhms Vsurge: 1129 ISurge: 5 IPeak: 1.4 Irms (Arms): 68 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Gel Termination: Threaded Stud/Insert Dimension inches: 9.650" H x 5.354" D Dimension mm: 245.0mm x 136.0mm ESR kHz: 60Hz
HCG 375 +10 to -5 480	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 375 Tolerance: +10% to -5% Voltage Rating - AC: 480V Operating Temperature: -40 °C to +70 °C ESR: 1.6 mOhms Vsurge: 1023 ISurge: 5 IPeak: 1.4 Irms (Arms): 68 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Gel Termination: Threaded Stud/Insert Dimension inches: 9.650" H x 5.354" D Dimension mm: 245.0mm x 136.0mm ESR kHz: 60Hz
HCG 375 10 480	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 375 Tolerance: ±10% Voltage Rating - AC: 480V Operating Temperature: -40 °C to +70 °C ESR: 1.6 mOhms Vsurge: 1023 ISurge: 5 IPeak: 1.4 Irms (Arms): 68 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Gel Termination: Threaded Stud/Insert Dimension inches: 9.650" H x 5.354" D Dimension mm: 245.0mm x 136.0mm ESR kHz: 60Hz
HCG 375 3 480	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 375 Tolerance: ±3% Voltage Rating - AC: 480V Operating Temperature: -40 °C to +70 °C ESR: 1.6 mOhms Vsurge: 1023 ISurge: 5 IPeak: 1.4 Irms (Arms): 68 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Gel Termination: Threaded Stud/Insert Dimension inches: 9.650" H x 5.354" D Dimension mm: 245.0mm x 136.0mm ESR kHz: 60Hz
HCG 375 5 480	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 375 Tolerance: ±5% Voltage Rating - AC: 480V Operating Temperature: -40 °C to +70 °C ESR: 1.6 mOhms Vsurge: 1023 ISurge: 5 IPeak: 1.4 Irms (Arms): 68 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Gel Termination: Threaded Stud/Insert Dimension inches: 9.650" H x 5.354" D Dimension mm: 245.0mm x 136.0mm ESR kHz: 60Hz
