HCG

Product Code	Data Sheet	Attributes
HCG 290 +10 to -5 480	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 290 Tolerance: +10% to -5% Voltage Rating - AC: 480V Operating Temperature: -40 °C to +70 °C ESR: 2 mOhms Vsurge: 1023 ISurge: 5 IPeak: 1.1 Irms (Arms): 53 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Gel Termination: Threaded Stud/Insert Dimension inches: 8.000" H x 4.567" D Dimension mm: 203.0mm x 116.0mm ESR kHz: 60Hz
HCG 290 10 480	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 290 Tolerance: ±10% Voltage Rating - AC: 480V Operating Temperature: -40 °C to +70 °C ESR: 2 mOhms Vsurge: 1023 ISurge: 5 IPeak: 1.1 Irms (Arms): 53 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Gel Termination: Threaded Stud/Insert Dimension inches: 8.000" H x 4.567" D Dimension mm: 203.0mm x 116.0mm ESR kHz: 60Hz
HCG 290 3 480	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 290 Tolerance: ±3% Voltage Rating - AC: 480V Operating Temperature: -40 °C to +70 °C ESR: 2 mOhms Vsurge: 1023 ISurge: 5 IPeak: 1.1 Irms (Arms): 53 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Gel Termination: Threaded Stud/Insert Dimension inches: 8.000" H x 4.567" D Dimension mm: 203.0mm x 116.0mm ESR kHz: 60Hz
HCG 290 5 480	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 290 Tolerance: ±5% Voltage Rating - AC: 480V Operating Temperature: -40 °C to +70 °C ESR: 2 mOhms Vsurge: 1023 ISurge: 5 IPeak: 1.1 Irms (Arms): 53 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Gel Termination: Threaded Stud/Insert Dimension inches: 8.000" H x 4.567" D Dimension mm: 203.0mm x 116.0mm ESR kHz: 60Hz
HCG 300 +10 to -5 600	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 300 Tolerance: +10% to -5% Voltage Rating - AC: 600V Operating Temperature: -40 °C to +70 °C ESR: 1.8 mOhms Vsurge: 1290 ISurge: 5 IPeak: 1.4 Irms (Arms): 68 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Gel Termination: Threaded Stud/Insert Dimension inches: 9.650" H x 5.354" D Dimension mm: 245.0mm x 136.0mm ESR kHz: 60Hz
HCG 300 10 600	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 300 Tolerance: ±10% Voltage Rating - AC: 600V Operating Temperature: -40 °C to +70 °C ESR: 1.8 mOhms Vsurge: 1290 ISurge: 5 IPeak: 1.4 Irms (Arms): 68 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Gel Termination: Threaded Stud/Insert Dimension inches: 9.650" H x 5.354" D Dimension mm: 245.0mm x 136.0mm ESR kHz: 60Hz
HCG 300 3 600	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 300 Tolerance: ±3% Voltage Rating - AC: 600V Operating Temperature: -40 °C to +70 °C ESR: 1.8 mOhms Vsurge: 1290 ISurge: 5 IPeak: 1.4 Irms (Arms): 68 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Gel Termination: Threaded Stud/Insert Dimension inches: 9.650" H x 5.354" D Dimension mm: 245.0mm x 136.0mm ESR kHz: 60Hz
HCG 300 5 600	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 300 Tolerance: ±5% Voltage Rating - AC: 600V Operating Temperature: -40 °C to +70 °C ESR: 1.8 mOhms Vsurge: 1290 ISurge: 5 IPeak: 1.4 Irms (Arms): 68 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Gel Termination: Threaded Stud/Insert Dimension inches: 9.650" H x 5.354" D Dimension mm: 245.0mm x 136.0mm ESR kHz: 60Hz
HCG 32 +10 to -5 525	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 32 Tolerance: +10% to -5% Voltage Rating - AC: 525V Operating Temperature: -40 °C to +70 °C ESR: 10.6 mOhms Vsurge: 1129 ISurge: 1.3 IPeak: 0.1 Irms (Arms): 7 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Gel Termination: Threaded Stud/Insert Dimension inches: 4.250" H x 2.953" D Dimension mm: 108.0mm x 75.0mm ESR kHz: 60Hz
HCG 32 10 525	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 32 Tolerance: ±10% Voltage Rating - AC: 525V Operating Temperature: -40 °C to +70 °C ESR: 10.6 mOhms Vsurge: 1129 ISurge: 1.3 IPeak: 0.1 Irms (Arms): 7 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Gel Termination: Threaded Stud/Insert Dimension inches: 4.250" H x 2.953" D Dimension mm: 108.0mm x 75.0mm ESR kHz: 60Hz
HCG 32 3 525	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 32 Tolerance: ±3% Voltage Rating - AC: 525V Operating Temperature: -40 °C to +70 °C ESR: 10.6 mOhms Vsurge: 1129 ISurge: 1.3 IPeak: 0.1 Irms (Arms): 7 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Gel Termination: Threaded Stud/Insert Dimension inches: 4.250" H x 2.953" D Dimension mm: 108.0mm x 75.0mm ESR kHz: 60Hz
HCG 32 5 525	Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 32 Tolerance: ±5% Voltage Rating - AC: 525V Operating Temperature: -40 °C to +70 °C ESR: 10.6 mOhms Vsurge: 1129 ISurge: 1.3 IPeak: 0.1 Irms (Arms): 7 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Gel Termination: Threaded Stud/Insert Dimension inches: 4.250" H x 2.953" D Dimension mm: 108.0mm x 75.0mm ESR kHz: 60Hz
