HCG

Product Code	Image	Data Sheet	Attributes
HCG 85 3 480		Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 85 Tolerance: ±3% Voltage Rating - AC: 480V Operating Temperature: -40 °C to +70 °C ESR: 6.5 mOhms Vsurge: 1023 ISurge: 3.2 IPeak: 0.3 Irms (Arms): 16 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Gel Termination: Threaded Stud/Insert Dimension inches: 6.000" H x 3.346" D Dimension mm: 152.0mm x 85.0mm ESR kHz: 60Hz
HCG 85 3 690		Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 85 Tolerance: ±3% Voltage Rating - AC: 690V Operating Temperature: -40 °C to +70 °C ESR: 3.1 mOhms Vsurge: 1484 ISurge: 2.5 IPeak: 0.5 Irms (Arms): 22 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Gel Termination: Threaded Stud/Insert Dimension inches: 7.000" H x 3.937" D Dimension mm: 178.0mm x 100.0mm ESR kHz: 60Hz
HCG 85 5 480		Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 85 Tolerance: ±5% Voltage Rating - AC: 480V Operating Temperature: -40 °C to +70 °C ESR: 6.5 mOhms Vsurge: 1023 ISurge: 3.2 IPeak: 0.3 Irms (Arms): 16 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Gel Termination: Threaded Stud/Insert Dimension inches: 6.000" H x 3.346" D Dimension mm: 152.0mm x 85.0mm ESR kHz: 60Hz
HCG 85 5 690		Data Sheet: HCO-HCG	Application: AC Harmonic Filtering, Power Factor Correction Capacitance (µF): 85 Tolerance: ±5% Voltage Rating - AC: 690V Operating Temperature: -40 °C to +70 °C ESR: 3.1 mOhms Vsurge: 1484 ISurge: 2.5 IPeak: 0.5 Irms (Arms): 22 Lifecycle @ Rated Temp & Voltage: 100,000 hrs Construction: very high quality metallized polypropylene film Mounting Type: Oil - Upright, Gel - Any position Dielectric Material: Polypropylene - Metallized Case: Aluminum Can with Gel Termination: Threaded Stud/Insert Dimension inches: 7.000" H x 3.937" D Dimension mm: 178.0mm x 100.0mm ESR kHz: 60Hz

Showing 109–112 of 112 results
